Terminator I/O System
Terminator I/O is a modular system which combines the functions of terminal blocks
and I/O modules for distributed I/O. Each Terminator I/O system has the following
components: a Power Supply, a Base Controller, and one or more I/O Module(s).
Power Supply
Mini Glossary
Below is a small glossary of terms used in this manual.
Scanner or Master
Controller or Slave
Node Address or MAC ID
DeviceNet
Base
Controller
I/O Module
I/O Base
The DeviceNet Master of which the
T1K–DEVNETS is a slave. This can be either a
PLC module or a card in your PC.
Short for the T1K–DEVNETS Base Controller.
The controller is also referred to as a Network
Interface Module elsewhere.
The unique device address on a DeviceNet
network. There are a maximum of 64 total (0–63).
Usually the scanner is node 0.
