Technical Manual Evolution Hopper Standard Interface Model (EV01000)

4. Installation

Important: Shut-off the power from the host machine until any installation work is completed.

4.1 Baseplate

1. Secure the base-plate in position using the six fixing holes. The hole positions are shown in
Figure 8: Base plate dimensions.
2. Wire up the base-plate connector to the host machine see Figure 2: Connector pin-out for connector
details and for interfacing recommendations.
NOTE: The wire to be used should have a maximum length of 3 metres and must be capable of
handling the maximum Currents and Voltages specified in Table 5: Electrical Interface.
3. Slide the hopper into the base-plate and ensure that the two halves of the connector are securely
mated.
4. Turn on the power.

4.2 Safety

1. Do not put a hand into the hopper while the motor is running.
2. Static. It is possible for coins paid out to have a static charge on them.
3. Coins should be discharged to earth before being presented to the user.
Page 9 of 22 22-10-07
