Technical Manual Evolution Hopper Standard Interface Model (EV01000)

3.4 Coin Sizes

Track type
Standard
(€2, €1, €0.50, €0.20)
Euro
(€2, €1, €0.50, €0.20, €0.10, €0.05)
Euro small
(€0.10, €0.05, €0.02, €0.01)

Table 2: Coin size Vs Track type

3.5 Base-plate

The base-plate offers the easy slide in and out function with a pre-fitted connector that can simply be
removed for fitting it in a cable-harness.
The base-plate is standard supplied with the Evolution Hopper.
See Figure 8: Base plate dimensions.
Coin sizes
21.01 – 30.00 mm x 1.25 – 3.30 mm
19.00 – 26.40 mm x 1.50 – 2.50 mm
16.25 – 20.90 mm x 1.00 – 3.10 mm
Page 8 of 22
Color Part. nr.
Red EV0050
Yellow EV0050-3
Green EV0050-4
22-10-07
