Technical Manual Evolution Hopper Standard Interface Model (EV01000)

8. Technical Specifications

8.1 Coin Sizes

Track type
Standard
(€2, €1, €0.50, €0.20)
Euro
(€2, €1, €0.50, €0.20, €0.10, €0.05)
Euro small
(€0.10, €0.05, €0.02, €0.01)

Table 4: Coin size vs Track type

8.2 Capacity

Capacity = Hopper volume / Coin volume =

8.3 Connector

Figure 4: Connector pinout

8.4 Electrical Interface

Electrical Interface
Voltage: nominal
minimum
maximum
Current (typical):
idle
empty
full
surge

Table 5: Electrical Interface

Coin sizes
21.01 – 30.00 mm x 1.25 – 3.30 mm
19.00 – 26.40 mm x 1.50 – 2.50 mm
16.25 – 20.90 mm x 1.00 – 3.10 mm
1,200,000
π x D
4
Pin Description
1 Motor Supply 0 Vdc
2 Logic Supply 0 Vdc
3 Coin Exit Output
4 IN1
5 Security Output
6 High or Top level Sense Output
7 Low level Sense Output
8 IN2
9 Motor Supply 24Vdc
10 Logic Supply 12 - 24Vdc
11 Coin Exit Output
12 IN3
Parallel Serial
24 VDC 24 VDC
18 VDC 20 VDC
26 VDC 26 VDC
40 mA 40 mA
0.2 A 0.2 A
0.7 A 0.7 A
2.5 A 2.5 A
Page 16 of 22
Color
Red
Yellow
Green
D = Coin diameter (mm)
2 T = Coin thickness (mm)
x T
Part. nr.
EV0050
EV0050-3
EV0050-4
