OTTAWA DRESSING TABLE _STOOL SET - ASSEMBLY INSTRUCTIONS
Fittings (to scale)
Code
Cam Bolt
A
(35mm overall)
B Cam Lock
Dowel (8x30mm)
C
Screw for Fitting Runner
E and Anti-tilt Strap
(3x12mm)
Bolt for Fitting Handle
F
(M4x18mm)
Screw for Fitting
G
Mirror (3.5x28mm)
Screw for Drawer Part
H
(3.5x40mm)
Fittings (not to scale)
Code
Outer Drawer
J
Runner - Right
Outer Drawer
K
Runner - Left
Inner Drawer
L
Runner - Right
Inner Drawer
M
Runner - Left
Handle
N
S Anti-tilt Strap
Item Quantity
30
30
8
9
2
8
4
Item Quantity
1
1
1
1
1
1
Batch No. 250417
10 20 30
Page 5 of 12
40 50 60 70
R
R
L
80
L
