Cable Specifications

Cable
1000BASE-SX 50/125 or 62.5/125
1000BASE-LX 9/125 micron core
Fiber Diameter
62.5/125 micron MMF 160 MHz/km
50/125 micron MMF
Cable Types and Specifications
Type
micron core multimode
fiber (MMF)
single-mode fiber (SMF)
1000BASE-SX Fiber Specifications
Fiber Bandwidth
200 MHz/km
400 MHz/km
500 MHz/km
C
Max. Length
See the following
table
5 km (16,404 ft)
Cable Length Range
2 - 220 m (7 - 722 ft)
2 - 275 m (7 - 902 ft)
2 - 500 m (7 - 1641 ft)
2 - 550 m (7 - 1805 ft)
ABLES
Connector
SC or ST
SC
