Introduction

The Spectrum type plate

The Spectrum type plate, which consists of the following components, can be found on the back of all netbox products. Please check whether
the printed information is the same as the information on your delivery note. All this information can also be read out by software:
The digitizerNETBOX/generatorNETBOX type, consisting of the abbrevaition for the digitizerNETBOX/generatorNETBOX chassis
type (DN2 in this example), the model type (496) and the number of channels (16)
The MAC address of the device. The MAX address is fixed and cannot be changed by the user. To check the MAC address by
software one can use the integrated web pages of the digitizerNETBOX/generatorNETBOX.
The installed complete data acquisition memory of the digitizerNETBOX/generatorNETBOX. As in our example there are two inter-
nal digitizer modules installed the memory is shared between them. Each digitizer module has 512 MSamples.
The serial number of the digitizerNETBOX/generatorNETBOX itself. This is the serial number also found on the delivery note.
Installed options of the digitizerNETBOX/generatorNETBOX.
The serial number of the first internal digitizer module.
The serial number of the second internal digitizer module.
The hardware version of the digitizerNETBOX/generatorNETBOX. The hardware and firmware versions of the installed
digitizer/generator modules are found using the Spectrum Control Center.
The date of production of the digitizerNETBOX/generatorNETBOX consisting of the calendar week and the year.
Please always supply us with the above information, especially the serial number in case of support request. That
allows us to answer your questions as soon as possible. Thank you.
