Configuring
3
the ADSL Barricade
This section provides instructions on how to use the Auto Setup
utility for configuration of the ADSL Barricade
1. Insert the Installation utility and Documentation CD into
your CD drive.
2. Browse to the location of your CD drive and run AutoSetup.exe.
This will start the Auto Setup utility, which provides an easy
way to configure the ADSL Barricade
3. Click [Yes, I agree] to accept terms of license agreement
and continue with the setup.
17
TM
TM for your ISP.
TM for your ISP.
4. Select your country from the drop down list, then click [Next]
to continue. If your country is not listed, click [Custom] and
skip to section Custom.
5. Select your ISP/Network provider from the drop down list, then
click [Next] to continue. If your ISP/Network Provider is not
listed, click [Custom] and skip to section Custom.
6. Enter the Username and password supplied by your ISP, then
click [Next] to continue.
Note: You will only be required to enter a username and password if
your ISP uses protocol PPPoA or PPPoE. If your ISP uses
RFC1483 Bridging no further input is required, simply click
[Next] to continue.
If your ISP uses RFC1483 Routed after clicking [Next] you
will be required to enter the IP address, Netmask, Gateway
address, Primary and Secondary DNS address supplied by
your ISP. Click [Next].
18
