Command Descriptions - Laird RM024 User Manual

RM024
User Guide
Parameter Range:

Command Descriptions

Read Temperature
The OEM host issues this command to read the onboard temperature sensor.
Note: The temperature sensor is uncalibrated and has a tolerance of ±3ºC. For calibration instructions,
contact Laird technical support.
Command:
Number of Bytes Returned:
Response:
Parameter Range:
Change Channel
The OEM host issues this command to set a new RF channel number.
Command:
Number of Bytes Returned:
Response:
Parameter Range:
Change Server/Client
The OEM host issues this command to set the module as a server or a client on-the-fly.
Command:
Number of Bytes Returned:
Response:
Parameter Range:
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/ramp
<Control> = 0x00= Turn Bin Analyzer Off
0x01= Turn Bin Analyzer On
<NumRuns> = 0x00= Continuous
0x01- 0xFF= Number of runs [bins]
<Bin#> = Bin# from 0 to max bin number according to the selected RF Profile
<RSSI_1> = How strongly the remote radio heard the local radio's bin request.
<RSSI_2> = How strongly the local radio heard the remote radio's response
Note: RSSI 1 and RSSI 2 range from 0x80 to 0x7F.
<0xCC> <0xA4>
2
0xCC <Temp.>
<Temp.> = Temperature (Celsius) in two's complement format
<0xCC> <0x02> <Channel>
2
<0xCC> <Channel>
For 43-channel hop mode, range is 0x00 to 0x29.
For 79-channel hop mode, range is 0x00 to 0x4D.
<Channel> = RF Channel to switch to, in the range 0x00 to 0x29
<0xCC> <0x03><Data>
3
<0xCC> <Firmware Version><Status>
<Data> 0x02 = Server
0x03 = Client
<Firmware> = Radio Firmware version
<Status> = 0x02: Server
= 0x03: Clients In Range
= 0x01: Client not In Range
35
