- Page 1 R4952 SELECT wash basin lifter Operation and maintenance manual...
-
Page 2: Table Of Contents
The guarantee covers faults or defects in material or manufacture within a period of 3 years. Pro- ducts are subject to minor technical modifications and design deviations. E. & O.E. Content Symbols used in this manual..........3 General safety . -
Page 3: Symbols Used In This Manual
Symbols used in this manual The following symbols are used in this manual as well as the associated documentation supplied with the product. WARNING WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. -
Page 4: General Safety
• The information in this manual is based on correct fitting of the product in accordance with our Assembly instruction. • Pressalit cannot be held liable if the product is used in any way which differs from that described in the guide. - Page 5 XXX kg XXX lbs XXX lbs XXX lbs ③ ⑯ ④ ⑰ Pressalit A/S • Pressalitvej 1 • DK - 8680 Ry • T: +45 8788 8777 E-mail: pressalit@pressalit.com • Web: www.pressalit.com ⑨ ⑩ ⑪ ⑫ ⑬ ① Production date ②...
- Page 6 ⑦ Maximum power consumption ⑧ IP class ⑨ Duty cycle The motor on height-adjustable products can be used for a maximum of 2 minutes of continuous operation, followed by 18 minutes pause. ⑩ Name and address of manufacturer ⑪ Type B applied part Part of the product in normal use necessarily comes into physical contact with the patient to perform its function The product complies with requirements of IEC 60601-1 to provide protection against electric shock.
-
Page 7: Intended Use
Product label placement Intended use This product is intended for optimum ergonomics at a wash basin, for both seated and standing users with disabilities. Intended operator profile The product can be used by all - adults, children, young and old. Operating environment For indoor use in a wet environment, such as a bathroom or wash room. -
Page 8: Assembly And Installation
Nous nous réservons le droit d’apporter toutes modifications pour l’amélioration de nous produits sans préavis · Wijzigingen voorbehouden Rätten till ändringar förbehålles · Vi forbeholder oss rett til endringer · Salvo variaciones Pressalit Care Telephone: +45 87 88 87 88... -
Page 9: Versions
Versions The wash basin lifter comes in one standard version, but the configuration can be modified with accessories like the hand control. R4952 T4204... -
Page 10: Operating Instructions
Operating instructions The wash basin lifter can be adjusted 300 mm up and down. Max load is 150 kg. Take care to avoid injury to hands when in the vicinity of moving mechanical parts. R4952 The height is adjusted by the lever control. -
Page 11: Safety Stop Function
Safety stop function The wash basin lifter is equipped with a safety stop function. If the wash basin comes in contact with an object when it is being lowered, the motor stops immediately. The wash basin lifter can be used again as soon as the obstruction has been removed. -
Page 12: To Remove Limescale
To remove limescale To remove limescale marks on the aluminium parts, use 3 parts of 30% household vinegar to 7 parts water and afterwards wipe the parts with a cloth wrung out in clean water. In countries with relatively high levels of lime in the water supply, it may be necessary to remove limescale deposits from the aluminium parts using a de-scaling agent such as acetic acid. -
Page 13: Maintenance
Maintenance Expected service life of the wash basin lifter is 10 years, provided that maintenance is carried out as described below: It is recommended on a weekly basis to run the motors on the product to their maximum positions by raising the product to its full height, and then lowering it to its lowest position, so that the internal parts are lubricated. -
Page 14: Technical Data
Technical data Max load 150 kg Materials Powder-laquered stainless steel Aluminium Plastics Dimensions 666 mm x 750 mm x 170 mm (width x height x depth) Weight 28.5 kg IP class IPX6 Power specifications Max consumption 75 W Voltage Mains connection: 230V/120V/100V Frequency 50/60 Hz Current... -
Page 15: Trouble-Shooting
Oil the inner square and down unevenly. tubes are not properly tubes as described under lubricated. ”Maintenance”. Contact Pressalit Care or your dealer if the problem cannot be remedied. Do not attempt to repair the product yourself, as this will invalidate the guarantee. -
Page 16: Disposal And Recycling
Disposal and recycling The unit contains reusable materials. There are no known hazards or risks associated with disposal of the product. All components can be discarded after having been cleaned and disinfected. When disposing of the product, we recommend that it be disassembled and broken down into different waste groups for recycling or combustion. - Page 17 8680 Ry Denmark Tel. : +45 8788 8788 Fax : +45 8788 8789 E-mail : pressalit@pressalit.com www.pressalit.com Visit our website to find your local dealer and get further information about Pres- salit Care and our solutions for bathrooms and kitchens.
