airIDEAL
3P™
Traceability
solution
User manual
for RUID remote control
SICAP Electronique
Z.A de la Lande
50290 Coudeville-sur-Mer
France
Distributed by:
bioMérieux S.A. 69280 Marcy l'Étoile / France
RCS Lyon 673 620 399
Tel: +33 (0)4 78 87 20 00 - Fax: +33 (0)4 78 87 20 90
http://www.biomerieux.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the air IDEAL 3P and is the answer not in the manual?

Questions and answers

Related Manuals for bioMerieux air IDEAL 3P

Summary of Contents for bioMerieux air IDEAL 3P

  • Page 1 RUID remote control SICAP Electronique Z.A de la Lande 50290 Coudeville-sur-Mer France Distributed by: bioMérieux S.A. 69280 Marcy l'Étoile / France RCS Lyon 673 620 399 Tel: +33 (0)4 78 87 20 00 - Fax: +33 (0)4 78 87 20 90 http://www.biomerieux.com...
  • Page 2 W a r n i n g The content of this manual is based on the Software release version 4.1. This manual is periodically updated. The updates shall be included in the new releases of the Software. Information supplied in this manual may be subject to modifications before the products described become available.
  • Page 3 R e v i s i o n s The list of revisions below summarizes replacements or additional pages in your User Manual. Date of Version Modifications Page (s) modified printing 2010/11 Creation Addition of regulatory information in 2011/01 conformity with Industry Canada User manual for RUID remote control Revisions-1...

  • Page 5: Table Of Contents

    T a b l e o f c o n t e n t s 1 How to use this manual Finding topics and procedures ........................ 1-1 Typographical conventions ........................1-2 2 Description of functions Introduction ............................. 2-1 ® How the airIDEAL 3P™...
  • Page 6 Table of contents Action bar ............................4-12 Sampling campaign flow chart ......................4-14 Starting a sampling campaign.......................4-15 Before starting ..........................4-15 Management of sample collections to launch..................4-15 Launching a sample collection in "Label for Petri dishes and sampling location" mode ("Launching wizard")........................4-16 Launch a sample collection in "Label for Petri dishes" mode only...........4-19 Launch a sample collection in "no labels"...
  • Page 7 L i s t o f f i g u r e s Description of functions Figure 2-1: Overview ....................2-2 Figure 2-2: Front view....................2-3 Figure 2-3: Barcode reader..................2-4 Figure 2-4: Connections....................2-4 Figure 2-5: Device identification.................. 2-5 Installation Figure 3-1: RUID in box ....................

  • Page 9: How To Use This Manual

    H o w t o u s e t h i s m a n u a l IMPORTANT! Before using the RUID for the first time, please read the "General safety and regulatory and information" booklet that is provided with the ABC. F i n d i n g t o p i c s a n d p r o c e d u r e s This manual has 7 chapters.

  • Page 10: Typographical Conventions

    How to use this manual Typographical conventions T y p o g r a p h i c a l c o n v e n t i o n s The following conventions are used in the chapters of the manual. •...

  • Page 11: Description Of Functions

    D e s c r i p t i o n o f f u n c t i o n s I n t r o d u c t i o n RUID remote control that communicates with ®...

  • Page 12: How The Airideal ® 3P™ Traceability Solution Works

    Description of functions Introduction ® H o w t h e a i r I D E AL 3 P ™ T r a c e a b i l i t y s o l u t i o n w o r k s Figure 2-1: Overview ®...

  • Page 13: Description

    Description of functions Description D e s c r i p t i o n The RUID is delivered in a box (see Unpacking, page 3-1). F r o n t Screen Function keys Navigation keys and barcode reader activation Alphanumeric keypad Figure 2-2: Front view User manual for RUID remote control...

  • Page 14: Front End

    Description of functions Description F r o n t e n d DATAMATRIX reader Figure 2-3: Barcode reader C o n n e c t i o n s Remove the protective cover to access the connection ports Charger connection USB connection (USB B mini) for data transfer to PC (length <...

  • Page 15: Underside - Device Identification

    Description of functions Description U n d e r s i d e – d e vi c e i d e n t i f i c a t i o n Identification label on underside of remote control Figure 2-5: Device identification User manual for RUID remote control...

  • Page 16: General Features

    Description of functions General features G e n e r a l f e a t u r e s T e c h n i c a l f e a t u r e s a n d s p e c i f i c a t i o n s PARAMETERS VALUES Dimensions...

  • Page 17: Electrical Specifications

    Description of functions General features E l e c t r i c a l s p e c i f i c a t i o n s R e m o t e c o n t r o l The remote control is powered by a DC-DC converter.
  • Page 18 Description of functions General features WARNING! The user’s manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. In cases where the manual is provided only in a form other than paper, such as on a computer disk or over the Internet, the information required by this section may be included in the manual in that alternative form, provided the...

  • Page 19: Installation

    I n s t a l l a t i o n CAUTION! Make sure that the box and equipment have not been damaged during transit. If damage has occurred, contact your bioMérieux representative. U n p a c k i n g •...

  • Page 20: Initial Battery Charge

    Installation Installation I n s t a l l a t i o n CAUTION! Avoid exposing the device to direct sunlight, excessive heat, humidity or dust. Avoid using the device near sources of powerful electromagnetic interference. I n i t i a l b a t t e r y c h a r g e See Initial charging/recharging of battery, page 5-3.
  • Page 21 U s e E r g o n o m i c s On/Off Screen − Resolution: 240 x 320 pixels - 64000 colors − Actual display size: 42.2 mm x 57.6 mm − Display in English only Status bar Action bar Keypad Barcode reader on front of remote control:...

  • Page 22: Use Ergonomics

    Ergonomics K e y s a n d s y m b o l s Function On/Off "Navigation" mode "Navigation" mode means that, on a particular screen, the cursor can be moved between fields, lines or menus using the following keys. Navigation within a drop-down menu or list: Previous line...

  • Page 23: Powering On

    Powering on P o w e r i n g o n IMPORTANT! When using the device for the first time, charge the RUID battery; (see Initial charging/recharging of battery, page 5-3). Press − The software starts up. − The charging screen is displayed.

  • Page 24: Transferring Data From The Software To The Remote Control

    Transferring data from the software to the remote control T r a n s f e r r i n g d a t a f r o m t h e s o f t w a r e t o t h e r e m o t e c o n t r o l ®...

  • Page 25: Opening A Session

    Opening a session O p e n i n g a s e s s i o n The "Login" screen contains a drop-down menu containing a predetermined list of users ("User"). Each user is identified with a trigram. Press to display a list of user trigrams.

  • Page 26: Session Management

    Session management S e s s i o n m a n a g e m e n t C h a n g i n g a u s e r d u r i n g a s e s s i o n •...

  • Page 27: Figure 4-4: Main Screen

    User interface U s e r i n t e r f a c e M a i n s c r e e n Status bar Screen title Menus Action bar Figure 4-4: Main screen The status bar is common to all screens. Battery charge level Number of active sample collections (included in the list of “Samplings in progress”)

  • Page 28: User Interface

    User interface S c r e e n d e t a i l s M e n u s c r e e n • Press to move between menus. The selected menu is highlighted in yellow. • Press to confirm the Figure 4-5: Example of main menu selection.

  • Page 29: Figure 4-7: Example Screen Detail Display

    User interface Example screen detail display It is possible to display details about a piece of information if the action bar suggests this display option. Select a piece of information. Press the key that corresponds to the option. The detail screen is displayed. Figure 4-7: Example screen detail display User manual for RUID remote control...

  • Page 30: Figure 4-8: Example Of Information Dialog Box

    User interface D i a l o g b o x s c r e e n Status bar Symbol and heading of dialog box: − Information dialog box: − Warning dialog box: − Error dialog box: Information about and/or description of possible action to take Action bar (see page 4-12) Figure 4-8: Example of information dialog box 4-10...

  • Page 31: Figure 4-9: Wizard Example: "Launching Wizard

    User interface W i z a r d Status bar Title of wizard followed by the number of current step and total number of steps in this wizard (step 2/5 in the following example). Display/data entry zone Action bar (see page 4-12) Display of instructions Figure 4-9: Wizard example: "Launching wizard"...
  • Page 32 User interface Ac t i o n b a r The action bar displayed depends on the selected submenu. Possible actions (see table below) Key for selecting an action Depending on which mode is activated ("navigation" or "action"), the same key will carry out different actions.
  • Page 33 User interface Action Description Sampling detail Cancels or deletes a sample collection Possible actions in navigation mode with wizard activated Select previous wizard screen Cancel wizard Select next wizard screen User manual for RUID remote control 4-13...

  • Page 34: Figure 4-10: Sampling Campaign Flow Chart

    Sampling campaign flow chart S a m p l i n g c a m p a i g n f l o w c h a r t Figure 4-10: Sampling campaign flow chart Note: The operator can use menus or digital reading of labels, or can combine both methods, when carrying out a sampling campaign (software configuration).
  • Page 35 Starting a sampling campaign S t a r t i n g a s a m p l i n g c a m p a i g n B e f o r e s t a r t i n g −...
  • Page 36 Starting a sampling campaign L a u n c h i n g a s a m p l e c o l l e c t i o n i n " L a b e l f o r P e t r i d i s h e s a n d s a m p l i n g l o c a t i o n " m o d e ( "...
  • Page 37 Starting a sampling campaign After sampling is launched, the LED on the ABC should turn green and flash (if it does not, please refer to the AeroBioCollector manual). Press to exit the menu. IMPORTANT! Sample collection launched on a target ABC can only start after the previous sample collection on that ABC has closed.

  • Page 38: Figure 4-11: Example Of A Sample Collection In "Label For Petri Dishes And Sampling Location" Mode ("Launching Wizard")

    Starting a sampling campaign Figure 4-11: Example of a sample collection in "Label for Petri dishes and sampling location" mode ("Launching wizard") 4-18 User manual for RUID remote control...
