- Page 1 INSTALLATION OPERATING MANUAL RHBDA-454.7/467.5-0.1/8W-55-A RACK MOUNTABLE BI-DIRECTIONAL AMPLIFIER...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PARAGRAPH PAGE NO RHBDA OVERVIEW RHBDA BLOCK DIAGRAM DESCRIPTION RHBDA BLOCK DIAGRAM DRAWING (Figure 1) ELECTRICAL SPECIFICATIONS MECHANICAL SPECIFICATIONS ENVIRONMENTAL CONDITIONS RF EXPOSURE WARNING RHBDA CONNECTIONS MECHANICAL OUTLINE DRAWING (Figure 2 & 2a) RHBDA INSTALLATION RHBDA OPERATION FRONT PANEL (Figure 3) BACK PANEL (Figure 4) DIAGNOSTICS GUIDE... -
Page 3: Rhbda Overview
RHBDA OVERVIEW: The RHBDA assembly enhances the coverage area of radio communications in buildings and RF shielded environments. The RHBDA has dual RF paths (Forward/Reverse) to improve coverage in two distinct frequency bands. The unit features low noise figure and wide dynamic range. It is based on a dual duplexed path configuration with sharp out of band attenuation allowing improved isolation between the receiving and transmitting paths. -
Page 4: Rhbda Block Diagram Drawing (Figure 1)
Figure 1 RHBDA BLOCK DIAGRAM RHBDA-454.7/467.5-0.1/8W-55-A 1. Input Downlink Diplexer – has low bandpass insertion loss and high selectivity for two distinct Downlink frequency bands. 2. Downlink Pre-amp’s – are low noise amplifiers that drive the Downlink PA’s and offer 25dB Gain. -
Page 5: Electrical Specifications
ELECTRICAL SPECIFICATIONS: Frequency Range : UL 451.7-452.7 & 460.5-464.6MHz DL 456.7-457.7 & 465.5-469.6MHz Pass band Gain @ min attenuation : 55 dB (Min.) Variable Step Attenuator Range : 0-30 dB (2-dB steps) Pass band Ripple : ±2.0 dB (Typ.) Noise Figure (Uplink) : 6.0 dB (Typ.) @+25°C at max gain 3rd Order Intercept point... -
Page 6: Mechanical Specifications
MECHANICAL SPECIFICATIONS: Size : 19.0 x 13.0 x 7.0 inch : (482.2 x 330.2 x 178 mm) RF Connectors : N-type Female Weight : 36.0 Lbs. (16.4 kg.) approx. ENVIRONMENTAL CONDITIONS: The unit is designed for indoor applications: Operating temperature: - 20°C to + 55°C Storage temperature: - 50°C to + 90°C RF EXPOSURE WARNING In order to satisfy the FCC RF exposure requirements, the RHBDA/antenna installation must... -
Page 7: Rhbda Connections
RHBDA CONNECTIONS The RHBDA Remote AC power is accepted through a standard 3-wire male plug (IEC-320) with phase, neutral and ground leads (See Figure 3). The AC power is wired to a high efficiency DC switching power supply which is CE and UL approved. The Remote power supply runs the amplifiers, the Power ON lamp, and Fiber Optic Transceiver. -
Page 8: Mechanical Outline Drawing (Figure 2 & 2A)
Figure 2 RHBDA Mechanical Outline DL-IN UL-OUT MOBILE POWER 0...30 dB Gain Adjustment 0...30 dB UPLINK Gain Adjustment 460.5-464.6 MHz UPLINK 451.7-452.7 MHz Dual Band Bi-Directional Amplifier 0...30 dB Gain Adjustment 0...30 dB DOWNLINK Gain Adjustment 465.5-469.6 MHz DOWNLINK 456.7-457.7 MHz Figure 2a (Relay Shown in Conditions for Optional Alarm... -
Page 9: Rhbda Installation
RHBDA INSTALLATION DO NOT APPLY A.C. POWER TO THE RHBDA UNTIL CABLES ARE CONNECTED TO BOTH PORTS OF THE RHBDA AND THE ANTENNAS. 1. Side the RHBDA into the 19” accessible rack. Mount the RHBDA to the rack. Using appropriate screws, attach the RHBDA to the rack at the four mounting holes on the Front panel. -
Page 10: Rhbda Operation
Uplink will depend on minimum and maximum distance from the mobile to server antennas. The level indicator is accurate to +/- 0.4 dB of the ALC set point. Operation of RHBDA-454.7/467.5-0.1/8W-55-A at minimum attenuation with greater than -30 dBm average power incident on the MOBILE port may cause damage to the RHBDA. -
Page 11: Front Panel (Figure 3)
Figure 3 Front Panel Adjustment Downlink ALC Uplink ALC Downlink Alarm Uplink Alarm DOWNLINK UPLINK Power Switch Figure 4 Back Panel Downlink IN Connector Uplink OUT AC Outlet Connector Mobile Connector Alarm Connector Page 11... -
Page 12: Diagnostics Guide
DIAGNOSTICS GUIDE The RHBDA provides long term, care-free operation and requires no periodic maintenance. There are no user-serviceable components inside the RHBDA. This section covers possible problems that may be related to the installation or operating environment. a. Gain Reduction Possible causes: Bad RF cables and RF connections to antennas, damaged antennae.
