Parker Hannifin Corporation
Porter Instrument
245 Township Line Road
Hatfield, PA 19440
Office 215 723 4000
Fax 215 723 5106
This product complies with the Medical Device Directive (93 / 42 / EEC).
A "Declaration of Conformity" in accordance with the directive has been made and is on file.
European Communities should contact the Authorized Representative listed below regarding any Medical
Device Directive (MDD) inquiries.
Contact Name:
Mailing Address:
Phone:
The Quality System for Porter Instrument is certified to ISO 13485. The scope of our registration is:
"The design, manufacture, distribution and servicing of Nitrous Oxide – Oxygen Sedation Flowmeters, Gas
Scavenging Systems, Gas Distribution Systems and Office Communication Systems for use by a physician, dentist
or licensed healthcare Profession."
Check our website: www.porterinstrument.com for additional information.
To register your product:
To download a User's Manual: www.porterinstrument.com/resources-dental choose Manuals tab
Parker Hannifin Ltd Instrumentation Products Division
Riverside Road, Pottington Business Park
Barnstaple, EX 31 1NP, England
+44 (0) 1271-313131
www.porterinstrument.com/resources-dental
Digital MDM
Operations Manual
Fax: +44 (0) 1271-373636
choose Warranty tab.
10545100-English Rev B
05/2018
