US Robotics USR5420 User Manual page 6

Adapter. The Configuration Utility icon will be colored to indicate the status of your
wireless network: red for disconnected and green for connected with good quality.
Double-click the Configuration Utility icon. When the Configuration Utility launches,
you can either scan for a network to connect to or enter the information for a
specific network.
To scan for a network, click the Available Networks tab. Locate the network you
want to connect to in the list, select it, and then click Connect . If you do not see the
network in the list, click Refresh to scan for the network.
If security is enabled in the wireless network you want to connect to or if you want
to manually enter the network information, you will need to set up a profile. For
information about how to do this, refer to the
Navigating the Wireless
section of this User Guide.
Configuration Utility
When you have connected to an existing wireless network, click the Link
Information tab. You will see a picture with a computer, a wireless device in the
middle, and an icon representing the Internet. If you see a moving graphic of ones
and zeroes moving between all three icons, you are connected to the wireless
network and to the Internet. If you only see ones and zeroes moving between the
computer and the middle wireless device, you are connected to the wireless
network, but not to the Internet.
If you can't connect to a network or if that network has security enabled, refer to the
User Guide on the installation CD-Rom for Configuration and Troubleshooting
information.
Congratulations!
You have finished installing the 802.11g Wireless USB
Adapter.
For troubleshooting and technical support information, refer to the Troubleshooting
section in this guide or to the U.S. Robotics Web site at www.usr.com
Register your product
• At the Installation CD-ROM interface, click the Support link. Click Registration
and Warranty and then click http://www.usr.com/productreg If the Installation
CD-ROM interface does not run automatically, click Windows Start and then click
Run . In the "Run" dialog box, type D:\setup.exe . If your CD-ROM drive uses a
different letter, type that letter in place of "D."
• Or register your product online at http://www.usr.com/productreg
