Troubleshooting

5.1 LED indication chart

Overview
Image 5-1
1 Light LED
2 Status LED
3 AV Mute LED
Explanation
Message
Standby State
Power on
(Warm up)
Power on & Laser
diode on
AV mute is off
(Image is displayed)
AV mute is on
(Image is black)
Projector
communication
Firmware upgrade
Laser diode time has
expired
Unit loses over 60%
initial luminance
Error
(Over temperature)
Error
(Fan failure)
Power key of the keypad is in steady red light when the projector enters standby mode.
42 R5910888 /00 G60
1 2 3
Light LED
Orange
Green Red
Steady
Steady
Steady
Steady
Steady
Status LED
Orange
Green Red
Flash-
ing
Steady
Steady
Steady
Flash-
ing
Flash- Flash-
ing ing
Steady
Flash-
ing
AV Mute LED
Orange
Green
Steady
Steady
Steady
Steady
