SERVICE-MANUAL
NEA ROOM CONTROLLER 230V / 24V
Actuator
Operating voltage
Inrush current
Operating power
Version
Closing and opening times
Actuator travel
Actuator power
Ambient temperature
Degree / class of protection
Housing
Connecting cable
Dimensions W x H x D
© REHAU
Actuator 230 V
230 V, AC +10%... -10%, 50/60 Hz
300 mA for max. 200 ms
Normally closed (NC)
approx. 3 min
4 mm
100 N ±5 %
0 .... 60°C
IP 54/II
Polyamide / grey
2 x 0,75 mm², 1 m
44 mm x 58 mm x 47 mm
Actuator 24 V
24 V, AC, +20% ... - 10%, 0 - 60 Hz
250 mA for max. 2 min
1,8 W
10
