PROFESSIONAL SOUND SYSTEM
Speaker Systems
Features
1. The Toa F-505W and the F-505G are 2-way tuned port speaker systems consisting of a 8"
high power woofer and a CD (constant directivity) horn tweeter coupled to a high efficiency
driver.
2. The TOA F-605W and the F-605G are 2-way tuned port speaker systems consisting of a 12"
high power woofer and a CD (constant directivity) horn tweeter coupled to a high efficiency
driver.
3. These highly durable lightweight speakers have been designed with an emphasis on accurate
sound reproduction. They offer ease in both mobility and installation and can be used for a
wide variety of applications.
4. The Constant Directivity (CD) Horn assures a uniform, well controlled dispersion pattern
60° Horizontal × 40° Vertical, within specified frequency response.
5. The modern, compact speaker enclosure is made of a low-foam polypropylene resin that
provides precise acoustic characteristics and is extremely durable.
6. Push-in terminals and phone jacks are provided for inputs. It is also possible to change the
phone jack into an XLR connector.
All manuals and user guides at all-guides.com
Instruction Manual
F-505W F-505G
F-605W F-605G
Advertisement
Related Manuals for Toa F-505W
Summary of Contents for Toa F-505W
- Page 1 F-605W F-605G Speaker Systems Features 1. The Toa F-505W and the F-505G are 2-way tuned port speaker systems consisting of a 8" high power woofer and a CD (constant directivity) horn tweeter coupled to a high efficiency driver. 2. The TOA F-605W and the F-605G are 2-way tuned port speaker systems consisting of a 12"...
-
Page 2: Specifications
3 kHz 2 kHz Input terminals: Input terminals: 1/4" phone jack × 2; also, Push-in terminals 1/4" phone jack x 2; also, Push-in terminals Color: Color: Ivory (F-505W) Ivory (F-605W) Dark Grey (F-505G) Dark Grey (F-605G) Dimensions: Dimensions: 11.1(H)×17.8(W)×9.1(D)inches 15.4(H)×21.7(W)×10.6(D) inches 282(H)×452(W)×231(D)mm... - Page 3 All manuals and user guides at all-guides.com F-505W F-505G F-605W F-605G Please see the reverse side for English manual.
- Page 4 All manuals and user guides at all-guides.com F-505W/F-505G F-605W/F-605G...
