PROFESSIONAL SOUND SPEAKER SYSTEM
General description
The Toa F-5 is a full-range, bass-reflex type speaker having a 4-inch
(10 cm) speaker with 10-watt power handling capacity. Small in size,
it can be easily mounted on the wall. Push terminals are provided on
the rear panel for high impedance applications. By changing the in-
ternal wire connection this speaker can also be used for low impe-
dance
applications.
[Operating Instruction]
Model F-5 us
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Toa F-5 US
Summary of Contents for Toa F-5 US
-
Page 1: General Description
Model F-5 us General description The Toa F-5 is a full-range, bass-reflex type speaker having a 4-inch (10 cm) speaker with 10-watt power handling capacity. Small in size, it can be easily mounted on the wall. Push terminals are provided on the rear panel for high impedance applications. -
Page 2: Specifications
(1W/1m in anechoic chamber, 1/3 octave pink noise) Speaker: 4" (10 cm) dynamic speaker Ambient temperature: –4°Fto +131°F (–20°C to +55°C) Material: Polypropylene Dimensions: 7.76(W)×5.43(H)×5.98(D) inches 197(W)×138(H)×152(D) mm Weight: 3.5 Ibs 1.6 kg Toa Electric Co., Ltd. KOBE, JAPAN 133-01-279-60...
