FPS8 Power Steering Module for the NavPilot 700 711 720
Autopilot Installation Information
Compatible with the following pump models: PUMPHRP05-12, PUMPHRP05-24,
PUMPHRP11-12, PUMPHRP11-24, PUMPHRP17-12, PUMPHRP17-24
Table of Contents
Table of Contents
1) Cover
1) Cover
2) Pre-Attachment Preparation
2) Pre-Attachment Preparation
3) Attaching the FPS8 to the HRP Pump
3) Attaching the FPS8 to the HRP Pump
4) Hydraulic Diagram – Single Helm and Single Cylinder
4) Hydraulic Diagram – Single Helm and Single Cylinder
5) Hydraulic Diagram – Dual Helm and Dual Cylinder
5) Hydraulic Diagram – Dual Helm and Dual Cylinder
6) Electrical Connection Diagram
6) Electrical Connection Diagram
