REVISION B
Form No. 3310434.034 09/16
(French 3310439.033_B)
©2016 Dometic Corporation
LaGrange, IN 46761
OASIS MANUAL
976 SERIES
AWNING SYSTEM
976(XX)48.000(#)
976(XX)48.100(#)
976(XX)56.000(#)
976(XX)56.100(#)
Read these instructions carefully. These
instructions MUST stay with this product.
USA
SERVICE OFFICE
Dometic Corporation
1120 North Main Street
Elkhart, IN 46514
RECORD THIS INFORMATION FOR FUTURE
REFERENCE:
Model Number
Serial Number
Date Purchased
Retailer / Qualified Installer
RV DOOR
CANADA
Dometic Corporation
46 Zatonski, Unit 3
Brantford, ON N3T 5L8
CANADA
SERVICE CENTER &
DEALER LOCATIONS
Please Visit:
www.eDometic.com
