- Page 1 HH4-PH Hand Held Digital pH/mV/Temperature Meter Operation and Instruction Manual AMALGAMATED INSTRUMENT CO PTY LTD ACN: 001 589 439 Unit 5, 28 Leighton Place Hornsby Telephone: +61 2 9476 2244 e-mail: sales@aicpl.com.au 2077 AUSTRALIA Facsimile: +61 2 9476 2902 Internet: www.aicpl.com.au...
-
Page 2: Table Of Contents
Table of Contents Introduction ....... . 3 Operation ....... . . 4 Read this first . -
Page 3: Introduction
(for Redox/ORP sensor inputs) and temperature by pressing the front panel keypad. When the HH4-PH is turned on, the display will indicate various power up messages and then settle into the measurement mode. The position of the decimal point allows the user to determine which range is currently selected. -
Page 4: Operation
Operation The HH4-PH digital pH meter is operated by pressing the on/off button. The following display sequence is executed during startup: 8.8.8.8 Display check Company name PHX.X Software version number This sequence will take around eight seconds then the display will indicate the current pH value. -
Page 5: Push Button Location & Function
Temperature electrode (when fitted) socket socket 1 @ 6 5 pH/mV Temp Hold HH4-PH digital pH/mV/temp meter Cal/Hold keypad On/Off keypad use also to enter pH/mV/Temp keypad use also as up setup mode and button when use also as down... -
Page 6: Setting Up And Programming Functions
Setting up and programming functions Setting up and calibrating the HH4-PH is extremely easy, since the functions are changed or viewed by pressing the pushbuttons. Several functions are available to allow the operator to set the operating modes, as follows: 4 .1... -
Page 7: Programming Functions
Note: When the HH4-PH is set to manual, the manually set temperature will be displayed when the display is cycled to read temperature - if the temperature probe is not connected. When the HH4-PH is set to automatic, the manually set temperature will not be displayed. - Page 8 APdt (set Auto Power Down Time) Press the ^ “On/Off” button or the v “pH/mV/Temp” button to select the Automatic Power Down Time (auto turn off time). The time is programmable over the range of 0 to 250 minutes. Note: if continuous operation is required, select 0 to disable the auto turn off function.
-
Page 9: Function Table
Function Table Meaning of Record Your Initial display Next display display Settings pH calibration Value stored OFSt offset in memory pH calibration Value stored gAIN gain in memory pH electrode Value from SLPE slope last calibration Auto or manual com- Auto on or OFF pensation... -
Page 10: Calibration
Calibration pH Calibration - 2 methods The HH4-PH has provision for two methods of pH calibration, a single points may be used for routine calibration, whilst a two point method should be used for initial calibration, critical applications, when the electrode is replaced or for periodical maintenance etc. - Page 11 End followed by FUNCEndand the system gain will be adjusted so that the display will match the corrected value. Two point calibration - see alsp HH4-PH two point calibration procedure example which follows. To enter the calibration mode and gain access to the two point calibration functions a special “power up procedure”...
- Page 12 SECOND CALIBRATION CAL 2 POINT ( 0 pH 14 pH 0 pH 14 pH HH4-PH two point calibration procedure example 1. Enter mode as shown below. 2. Step through the functions by pressing and releasing the button CAL 1 until the function is reached.
- Page 13 pH uncalibration This function sets the instrument calibration back to the factory calibrated value and closely matches that of an ideal electrode. Uncalibrate is useful as a temporary measure when the pH electrode is replaced and on the spot recalibration is difficult or when a calibrating error exists due to incorrect calibration.
-
Page 14: Errors And Status Messages
Errors and Status Messages The status message which represent conditions and errors, are as follows: batt (low battery voltage) Indicates that the battery voltage has reached approximately 6.4V. The unit will continue to operate - a new battery should be fitted as soon as possible. CAL Err (calibration error) If the display is in overrange during calibration and an attempt is made to calibrate, then this message will be displayed. -
Page 15: Specifications
Specifications Technical Specifications pH Input : Any pH electrode where Eo=7 (-2V tp 2V nom): mV Input: -2000mV to 2000mV Temperature Input: LM335 temperature sensor Temperature Range: -50 to 150 Input Resistance: Greater than 10 Ohms (pH & mV) ADC Resolution: 1 in 20,000 Accuracy pH &... -
Page 16: Guarantee And Service
Guarantee and Service The product supplied with this manual is guaranteed against faulty workmanship for a period of 2 years from the date of dispatch. Our obligation assumed under this guarantee is limited to the replacement of parts which, by our examination, are proved to be defective and have not been misused, carelessly handled, defaced or damaged due to incorrect installation.
