Installation

The Nature Fusion system must be installed downstream from the fi ltering
2
system and any eventual heating system (heat pump, heat exchanger,
electric warmer...).
• For pools fi tted with a heating system where the Nature
to be installed downstream on the same bypass, leave a minimum distance
of at least 1 metre between the two appliances. Install a check valve
between the two appliances if the distance is less.
Nature Fusion must be placed fl at on the ground or on a horizontal and
2
stable support.
• If the Nature Fusion system is installed in a technical room, it should be
2
ventilated and/or well aired.
It is recommended to install the Nature
in «parallel»). The maximum permitted fl ow in the diffuser is 25 m
installing the system on a bypass is COMPULSORY for fl ows exceeding this
value (on the contrary an in-line installation is possible below the maximum
permitted fl ow).
The minimum fl ow for correct operation of the appliance is of 6.5 m
• Special case for above-ground pools:
If the Nature Fusion system is installed on an above ground pool fi tted
2
with fl exible ringed piping, use the supplied above ground connection kit.
It has two adapters for 32 or 38 mm pipes that are to be glued into the
DN50/63 mm diffuser joints.
For all gluing (rigid pipes for in ground pools and adapters for above ground
pools) use «blue» PVC adhesive (sand the surfaces manually before applying
adhesive to the parts to be assembled).
Standard
installation
diagram:
!
IMPORTANT!! Nature
water fi rst passes through the Nature
the chlorinator.
Make sure you follow the water fl ow direction as indicated on the body of
the diffuser:
➤ INLET = water intake (Nature
➤ OUTLET = water outlet (chlorinator side).
20
Fusion system on a bypass (or
2
Fusion must be installed in the right direction: the
2
Fusion cartridge and then through
2
Fusion cartridge side)
2
Fusion system is
2
3 /hr;
/hr.
3
