Product Specifications Table
MODEL
FLOW RATE @ 30mJ/cm2 (at 1 year)
STANDARD NPT INLET / OUTLET PORTS
CHAMBER MATERIAL
INPUT VOLTAGE
SYSTEM MAX INPUT POWER (Watts)
LAMP MAX ELECTRICAL POWER (Watts)
VISUAL ALARM
AUDIBLE ALARM
AUDIBLE ALARM MUTE
MIN/MAX AMBIENT AIR TEMPERATURE /
MAX HUMIDITY
INLET WATER TEMPERATURE RANGE
MAX WATER PRESSURE
SHIPPING WEIGHT

Dimensions

FRONT
WA002
usgpm 2 gpm
liters/min 7.6 lpm
3/8" NPT-M
18.6
14
32°F (0°C) to 122°F (50°C) / 90% RH (non-condensing)
4.6 lbs (2.1 Kg)
Model
WA002
WA006
WA008
WA012
All dimensions are in inches.
NOTICE
* Allow this end clearance (F*) for the removal of
lamp and quartz sleeve.
SIDE
4
WA006 WA008
6 gpm 8 gpm
22.7 lpm 30.3 lpm
3/4" NPT-M 3/4" NPT-M
304 SS
120 VAC 60 Hz or 230 VAC 50 Hz
26 32
21 29
Green/Red LED
Yes
No
36°F ( 2°C) to 104°F ( 40°C)
100 psi (689 kPa)
6.4 lbs (2.9 Kg) 8 lbs (3.7 Kg)
A Series UV Systems
GPM A B
2 1.1 14.17
6 1.2 22.14
8 1.2 28.06
12 1.35 37.07
WA012
12 gpm
45.4 lpm
1" NPT-M
45
40
11 lbs (5 Kg)
C D E F
17.65 3.83 3.09 14
25.62 3.99 3.09 22
31.54 3.99 3.09 28
40.54 4.01 3.09 39
