Summary of Contents for FAVI BLED3TPPWM3HD100-BH
- Page 1 User Manual Product specification and user manual is subject to change without prior notice due to engineering improvement. Color and appearance of product and icons in user manual may vary from that of actual product.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Product Registration Warranties Important Safety Notes Safety Maintenance Power Projector Turn ON Projector Turn OFF Projector Projector Overview Focus Adjustment Input Panel Layout Keystone Adjustment Top Control Panel Layout Remote Overview Installation Image Adjustment Installation Methods Menu Setting Main Menu Overview Settings Menu Sound Menu... -
Page 3: Product Registration
Product Registration allows us to send you important updates, service information and helpful hints. It will also make it easier should you ever need to contact our Support Team. FAVI values your privacy and will never share your information with other companies. -
Page 4: Warranties
FAVI Entertainment will pay round trip shipping for warranty claims within the USA. Excludes: HI, AK, APO, USA Territories, and international orders. -
Page 5: Important Safety Notes
IMPORTANT SAFETY NOTES Before you use this projector, please read this manual carefully. SAFETY • Do not stare directly into the light of projector’s lens. • Do not expose projector to water or other sources of moisture to avoid electrical shock. •... -
Page 6: Power Projector
POWER PROJECTOR Starting up your projector for the first time: Step 1: Insert two AAA batteries into the remote control. Step 2: Press the power button on the remote or on the projector. Note: The projector lamp should light up within a few seconds. The focus and keystone correction may need to be adjusted. -
Page 7: Projector Overview
PROJECTOR OVERVIEW The following diagrams point out the features of your projector: FRONT 1 – Ventilation 2 – Lens Focus Adjustment Rotate the lens clockwise or counter clockwise to adjust the focus. Rotate clockwise for a Rotate counter clockwise larger picture. for a smaller picture. -
Page 8: Input Panel Layout
PROJECTOR OVERVIEW HDMI BACK 1 – USB input 2 – HDMI input 3 – AV input 4 – Remote IR Sensor 5 – VGA input 6 – Power input 7 – Keystone adjustment 8 – Audio output 9 – Ventilation Slot... -
Page 9: Keystone Adjustment
PROJECTOR OVERVIEW Keystone Adjustment After setting up your projector and powering it on, the image may look trapezoid shaped. 1) If the projector is not properly positioned as shown in the diagram, reposition the projector. Screen Height Projector HDMI Projector Height Screen Height-Feet... -
Page 10: Top Control Panel Layout
PROJECTOR OVERVIEW 1 – Indicator Light 2- Power Button Top Control Panel Layout... -
Page 11: Remote Overview
REMOTE OVERVIEW 1. Power 2. Mute 3. Rewind 4. Fast Forward AUD.LANG 5. Previous Source 6. Next 7. Play 8. Stop 9. Audio Language Menu Exit 10. Source 11. Select / OK 12. Directional keys 13. Menu 14. Exit - /- - 15. -
Page 12: Installation
INSTALLATION Your projector can be installed in a wide variety of configurations. It supports both front and rear screen projection. Below is a sample diagram featuring a basic front screen projection setup: For best results regardless of your configuration, the projector should be used in a darkened room, and should be used with screen sizes ranging from 50 to 120 inches. -
Page 13: Image Adjustment
INSTALLATION Image Adjustment For best image results, the projector should be directly facing the screen. Adjustment to the focus and keystone controls will help to improve the picture. Please see the diagram below for examples of correct and incorrect setup. The projector is angled The projector is set up The projector is angled... -
Page 14: Installation Methods
Front projection table mount Rear projection table mount Note: FAVI recommends that a professional installer be contacted to install a ceiling mount for your projector. If installing a ceiling mount yourself, please follow the instructions that came with your mount. This projector must be installed in an... -
Page 15: Menu Setting
MENU SETTING Main Menu Overview To display Main Menu, press “Menu” Use the “ ” keys to navigate through the sub menus: Setting, Picture, Sound, and Time Use the “ ” keys to move up and down the list of items within the sub menus Press “OK”... -
Page 16: Sound Menu
MENU SETTING Sound Menu Sound Menu Adjust projector setting. Mode Music / Movie / Sport / User / Standard Balance (-50 ~ 50) Auto-Volume OFF / ON Surround Sound OFF / SURROUND Balance (120/500/1.5K/5K/10K) 50 Hz Time Menu Time Menu Adjust projector time setting. -
Page 17: Picture Menu
MENU SETTING Picture Menu Picture Menu Adjust projector setting. Mode Standard / Warm / User (Appendix 1) / Dynamic Color Temp Standard / Warm / Cool Aspect Auto / 4:3 / 16:9 (Appendix 2) Noise Reduction OFF / LOW / MID / HIGH Flip Horizon OFF / ON Flip Vertical... -
Page 18: Multimedia Menu
MENU SETTING Multimedia Menu Multimedia Search, view, and play Menu media files. Picture View photo gallery Music Play music Movie Watch movies Text Read document Supported Multimedia Format Task Format Video Decode Audio Decode MOVIE .AVI DivX, Xvid, MPEG-4 .MPG MPEG-1, MPEG-2 .DAT MPEG-1... -
Page 19: Troubleshooting
TROUBLESHOOTING If you have any issues with using your projector, please refer to the following solution below. If issues persist, contact our technical support team at: techsupport@favientertainment.com Problem Solution Projector will not power • Check the power cord and power outlet. •...
