IDNAC SLC Operation Advantage (Cont'd)
Reducing Installation and Testing Time. With
separate controls on the same two-wire SLC, installation
time and expense for both retrofit and new construction
can be significantly reduced. When Class B wiring is
used, wiring can be "T" tapped, allowing more savings in
distance, wire, conduit (size and utilization), and overall
installation efficiency. Use of the magnet test feature
improves installation efficiency. TrueAlert device reports
conveniently identify information about each connected
appliance.
TrueAlert Addressable Wiring Isolator
Isolator Model 4905-9929 is available for remote
mounting on TrueAlert addressable circuits to isolate
short circuited wiring from functioning wiring. (Refer to
data sheet S4905-0001 for additional information.)
Product Selection
Multi-Candela Ceiling Mount Addressable Strobe
Housing
Model
Color
4906-9202 Red
4906-9204 White
V/O Adapters (see diagram on page 3)
Model Description
Ceiling Mount, Surface Mount Adapter Plate, zinc plated; required for
4905-9910
ceiling surface mount
Wire Guards (see diagram on page 3)
Model Description
Ceiling Mount Red wire guard with mounting plate, compatible with
4905-9926*
semi-flush or surface mounted boxes
* UL listed by Space Age Electronics Inc.
TrueAlert Device Reports Reference
Service Port
REPORT 5 : TrueAlert Device Report
POINT ID CUSTOM LABEL
T14-1-1 Location Label . . . up to 40 characters
T14-1-2 Break Room 5
T14-1-3 Boiler Room
T14-1-4 Elec. Room 7
"FIRE" Lettering
White
4 ¾" x 2
(121 mm x 75 mm x 67 mm)
Red
TrueAlert Addressable Diagnostics
Test Features. Controllers can be selected to pulse each
appliance's LED when it receives a supervision poll.
When the controller is selected for diagnostic mode, the
appliance magnet test feature provides a response at the
individual appliance being tested.
Silent Appliance Magnet Test. In this test mode, in
response to the magnet test, the appliance LED pulses
sequentially to conveniently indicate the appliance's
address.
Operational Appliance Testing. In this test mode,
after the address is indicated by pulsing the appliance
LED, the strobe will briefly flash to indicate proper
operation.
TrueStart Instrument Two (TSIT). The 2nd
generation of the Simplex TrueStart Test Instrument adds
testing of IDNAC SLC wiring and TrueAlert (and
TrueAlert ES) appliances to its ability to test IDCs,
NACs, and IDNet communications before connection to
the control panel. Please contact your local Simplex
representative for additional information.
Dimensions Description
Multi-Candela Addressable Strobe;
5
⁄ " x 2 ⅝" D
16
intensity selectable as: 15, 30, 75, or
110 candela
DEVICE
TYPE
V/O
A/V
A/V
A/V
2
Dimensions
4 ⅞" x 3 ⅛" (124 mm x 79 mm)
Dimensions
6 ⅛" x 4 ⅜" x 2 ⅞"
(156 mm x 111 mm x 73 mm)
Page 1
12:34:56am MON 20-May-13
CANDELA
15
110
75
30
S4906-0004-3 5/2013
