Simplex TrueAlert 4906-9207 Instructions page 3

Ceiling Mount V/O and Guard Installation Reference
Single gang box (Wiremold V5744S)
2-1/4" (57 mm) deep, supplied by others
Address setting DIPswitch is behind strobe
assembly, select address and strobe
candela setting before inserting into housing
Bottom view
LED indicator
TrueAlert Amber Strobe and IDNAC SLC Controller Compatibility Reference
Compatible Controller
4100ES with EPS+ or EPS Power Supply
4009 IDNAC Repeater
Specifications
Common Specifications
Environmental 32° to 122° F (0° to 50° C); 10% to 93%, non-condensing at 100° F (38° C)
Connections Terminal blocks for 18 AWG to 12 AWG (0.82 mm
Installation Instructions 579-828
Strobe Specifications
Typical Operating Voltage Range
Flash Rate and Synchronized SLC Loading
23 VRMS Current Ratings,
for connection to IDNAC
Addressable SLCs
TrueAlert Strobe LEGACY Compatibility Reference
Compatible Controller
4100ES or 4100U with TrueAlert Power Supply
4009 TPS, Remote TrueAlert Power Supply
TrueAlert Addressable Controller (4009T)
Electrical Ratings Difference for Retrofit Applications
17 VRMS Current Ratings,
use when connected to
TrueAlert Addressable SLCs
per above
Magnetic
test location
Data Sheet
Reference
S4100-0100
S4009-0004
(see page 2 for appliance dimensions)
23 VRMS to 31 VRMS, Special Application (see below for 17 VRMS rating)
1 Hz; with up to 46 synchronized strobes maximum per NAC; maximum 30 Ω
resistance between appliances
Candela Setting
60 mA
Data Sheet
Reference
S4100-0031
S4100-0037
S4009-0003
Voltage Range 17 VRMS to 31 VRMS, Special Application
Candela Setting
Handy box, 1-1/2" ( 38 mm) deep (RACO 650 or
equal) or single gang box, 2-1/2" (64 mm) deep
(RACO 519 or equal) supplied by others
Also can be attached to boxes mounted to drop
ceiling T-bar with clips (ERICO No. 512 or equal)
4905-9910 Adapter Plate, required for surface
mount with handy box unless using the 4905-9926
wire guard
Controller
Output
IDNAC SLC
2
to 3.31 mm
15 cd 30 cd
92 mA
Controller
Output
TrueAlert
Addressable SLC
15 cd 30 cd
76 mA 128 mA
3
Ceiling mount strobe
Optional 4905-9926 wire
guard with mounting plate
Strobe intensity viewing slot
Intensity selection plug,
accessible only from rear of lens
housing; factory setting is FACP,
controlled by panel
IDNAC SLC Appliance Voltage
Output Voltage Design Reference
29 VRMS
(regulated) (with 6 VRMS drop)
2
); two wires per terminal for in/out wiring
75 cd
180 mA
Available Strobe
Intensity Voltage Minimum
15, 30, 75, and
110 cd
75 cd
242 mA
S4906-0007-7 8/2014
23 VRMS
110 cd
240 mA
Appliance
17 VRMS
110 cd
328 mA
