Simplex TrueAlert 4906-9208 Instructions page 2

IDNAC SLC Operation Advantage
TrueAlert V/O Appliances with Addressable
Strobes on IDNAC SLCs provide visible notification
using a single two-wire circuit that also confirms
connection to the individual notification appliance's
electronic circuit. This operation increases circuit
supervision integrity by providing supervision that
extends beyond the appliance wiring connections.
Reduced current allows efficient IDNAC SLC
operation. With IDNAC SLCs, a constant 29 VRMS
source voltage is maintained, even during battery standby,
allowing strobes to operate at higher voltage with lower
current and ensuring a consistent current draw and voltage
drop margin under both primary power and secondary
battery standby. Efficiencies include wiring distances up to
2 to 3 times farther than with conventional notification, or
support for more appliances per IDNAC SLC, or use of
smaller gauge wiring, or combinations of these benefits, all
providing installation and maintenance savings with high
assurance that appliances that operate during normal system
testing will operate during worst case alarm conditions.
Reducing Installation and Testing Time. With
separate controls on the same two-wire SLC, installation
time and expense for both retrofit and new construction
can be significantly reduced. When Class B wiring is
used, wiring can be "T" tapped, allowing more savings in
distance, wire, conduit (size and utilization), and overall
installation efficiency. Use of the magnet test feature
improves installation efficiency. TrueAlert device reports
conveniently identify information about each connected
appliance.
By providing an amber lens strobe with a clear lens
strobe, the combination strobe assembly allows a single
electrical installation to provide both types of visible
notification.
Product Selection
Housing
Model Description
Color
Multi-Candela Addressable Combination Strobe assembly with
4906-9208 Red
amber lens, ALERT strobe on top and clear lens, FIRE strobe
4906-9211 White
on bottom; intensity selectable as: 15, 30, 75, or 110 candela
4905-9837 Red
Surface Mount Adapter Skirt, use to cover surface mounted
electrical boxes
4905-9847 White
Adapter Plate for mounting to installed Simplex Model
4905-9840 Red
2975-9145 box; for flush mounted boxes only
TrueAlert Device Reports Reference
Service Port
REPORT 5 : TrueAlert Device Report
POINT ID CUSTOM LABEL
T14-1-1 Location Label . . . up to 40 characters
T14-1-2 Break Room 5
T14-1-3 Boiler Room Fire
T14-1-4 Boiler Room Alert
TrueAlert Addressable Diagnostics
Test Features. Controllers can be selected to pulse each
appliance's LED when it receives a supervision poll. When
the controller is selected for diagnostic mode, the appliance
magnet test feature provides a response at the individual
appliance being tested.
Silent Appliance Magnet Test. In this test mode, in
response to the magnet test, the appliance LED pulses
sequentially to conveniently indicate the appliance's
address.
Operational Appliance Testing. In this test mode, after
the address is indicated by pulsing the appliance LED, the
strobe will briefly flash to indicate proper operation.
TrueStart Instrument Two (TSIT). The 2nd generation
of the Simplex TrueStart Test Instrument adds testing of
IDNAC SLC wiring and TrueAlert (and TrueAlert ES)
appliances to its ability to test IDCs, NACs, and IDNet
communications before connection to the control panel.
Please contact your local Simplex representative for
additional information.
TrueAlert Addressable Wiring Isolator
Isolator Model 4905-9929 is available for remote
mounting on TrueAlert addressable circuits to isolate short
circuited wiring from functioning wiring. (Refer to data
sheet S4905-0001 for additional information.)
TrueAlert Device Reports
and location per appliance (see sample below, amber lens
type is AMB).
Dimensions
10 ¾" H x 5 ⅛" W x 3
(273 mm x 130 mm x 100 mm)
10 ½" H x 5 ¼" W x 1 ¾" D
(267 mm x 133 mm x 44 mm)
Total depth with strobe assembly
= 5 ⅝" (143 mm)
12
(313 mm x 146 mm x 1.5 mm)
DEVICE
TYPE
V/O
A/V
A/V
AMB
2
detail type, candela rating,
15
⁄ " D
16
5
⁄ " H x 5 ¾" W x 0.06 thick
16
Page 1
12:34:56am MON 17-Mar-14
CANDELA
15
110
75
75
