Ceiling Mount Speaker Specifications

Specifications
(see page 1 for appliance dimensions)
Environmental
Connections
IDNAC SLC Loading
Installation Instructions

Speaker General Specifications

Input Voltage
Power Taps
Frequency Response
Speaker Output Ratings 25 or 70.7 Vrms @ 10 ft (3 m)
Reverberant Chamber Test, per UL 1480 (dBA)
Anechoic Chamber Test, per ULC-S541 (dBA)*
* Note: Select taps as indicated to satisfy the ULC fire alarm applications requirement of 85 dBA minimum
Polar Dispersion Reference (per ULC-S541 Anechoic Chamber
Testing)

Appliance Specifications

Typical Operating Voltage Range
Current consumption @ 23 VDC on IDNAC Addressable SLC
Supervisory Requirements
Note: Speakers are for connection to compatible fire alarm audio circuits. Anechoic speaker output ratings are typically more representative
of actual installed sound output.

Ceiling Mount Speaker Installation Reference
