Alpha Data FMC-CAMERALINK User Manual

Compliant single width lpc fmc module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FMC-CAMERALINK
User Manual
Document Revision: 2.7
5th February 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FMC-CAMERALINK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alpha Data FMC-CAMERALINK

Summary of Contents for Alpha Data FMC-CAMERALINK

  • Page 1 FMC-CAMERALINK User Manual Document Revision: 2.7 5th February 2019...
  • Page 2 FMC-CAMERALINK User Manual V2.7 - 5th February 2019 © 2019 Copyright Alpha Data Parallel Systems Ltd. All rights reserved. This publication is protected by Copyright Law, with all rights reserved. No part of this publication may be reproduced, in any shape or form, without prior written consent from Alpha Data Parallel Systems Ltd.

  • Page 3: Table Of Contents

    Notes ............................15 RS232 Electrical Specifications ....................16 List of Tables Table 1 FMC-CAMERALINK board features ....................2 Table 2 Camera Link Connector 1 (Dual Base Input Configuration) .............. 5 Table 3 Camera Link Connector 2 (Dual Base Input Configuration) .............. 6 Table 4 Camera Link Connector 1 (Base/Medium/Full Input Configuration) ..........
  • Page 4 FMC-CAMERALINK User Manual V2.7 - 5th February 2019 Figure 1 FMC-CAMERALINK Block Diagram ....................1 Figure 2 FMC-CAMERALINK .......................... 2...

  • Page 5: Introduction

    The FMC-CAMERALINK provides support for 2 Base configuration inputs or one Medium or Full configuration input. In addition to being able to be used for image capture, the FMC-CAMERALINK may also be used for emulation of either up to two Base format cameras or one Medium / Full format camera.

  • Page 6: Specification

    V2.7 - 5th February 2019 2 Specification 2.1 IO Voltage The FMC-CAMERALINK requires the host board to provide VADJ in the range 1.8V to 3.3V. 2.2 Connectors Camera Link: SDR connector 3M; part number 12226-8250-00FR Auxiliary Serial: 0.1"/2.54mm pitch 3 pin right angle header.

  • Page 7: Installation

    V2.7 - 5th February 2019 3 Installation The FMC-CAMERALINK is designed to plug in to the FMC front panel connector on a compatible carrier. The retaining screws should be tightened to secure the FMC. Note:This operation should not be performed while the host PMC, XMC or PCI(e) card is powered up.

  • Page 8: Order Code

    V2.7 - 5th February 2019 4 Order Code 4.1 FMC-CAMERALINK The FMC does not support providing power over the Camera Link Connection. 4.2 FMC-CAMERALINK/PoCL Power can be provided by the FMC-CAMERALINK over the Camera Link connection(s) to attached camera(s). Page 4 Order Code ad-ug-1249_v2_7_FMC-CAMERALINK_User_Manual.pdf...

  • Page 9: Pin-Out

    FMC-CAMERALINK User Manual V2.7 - 5th February 2019 5 Pin-out 5.1 Camera Link Pin-out Note: In some configurations FMC pin have the N/P pairs swapped (signals marked with '*' in the tables below). These signals will need re-inverting in the connected FPGA design.

  • Page 10: Camera Link Connector 2 (Dual Base Input Configuration)

    FMC-CAMERALINK User Manual V2.7 - 5th February 2019 Signal Name Direction FMC pin SDR pin (Con. 2) xclk_p LA_P_01 xclk_n LA_N_01 x_p<0> LA_P_06 x_n<0> LA_N_06 x_p<1> LA_P_07 x_n<1> LA_N_07 x_p<2> LA_P_08 x_n<2> LA_N_08 x_p<3> LA_P_09 x_n<3> LA_N_09 cc_p<1> LA_P_11 cc_n<1>...

  • Page 11: Base/Medium/Full Input Configuration

    FMC-CAMERALINK User Manual V2.7 - 5th February 2019 5.1.2 Base/Medium/Full Input Configuration The following tables show the pin usage for attaching one Base/Medium or Full camera to an FPGA design. Signal Name Direction FMC pin SDR pin (Con. 1) xclk_p...

  • Page 12: Camera Link Connector 2 (Base/Medium/Full Input Configuration)

    FMC-CAMERALINK User Manual V2.7 - 5th February 2019 Signal Name Direction FMC pin SDR pin (Con. 2) yclk_p LA_P_01 yclk_n LA_N_01 y_p<0> LA_P_06 y_n<0> LA_N_06 y_p<1> LA_P_07 y_n<1> LA_N_07 y_p<2> LA_P_08 y_n<2> LA_N_08 y_p<3> LA_P_09 y_n<3> LA_N_09 zclk_p LA_P_17 zclk_n LA_N_17 z_p<0>...

  • Page 13: Dual Base Output Configuration

    FMC-CAMERALINK User Manual V2.7 - 5th February 2019 5.1.3 Dual Base Output Configuration The following tables show the pin usage for emulating two Base cameras from an FPGA design. Signal Name Direction FMC pin SDR pin (Con. 1) xclk_p LA_N_18*...

  • Page 14: Camera Link Connector 2 (Dual Base Output Configuration)

    FMC-CAMERALINK User Manual V2.7 - 5th February 2019 Signal Name Direction FMC pin SDR pin (Con. 2) xclk_p LA_N_11* xclk_n LA_P_11* x_p<0> LA_N_13* x_n<0> LA_P_13* x_p<1> LA_N_17* x_n<1> LA_P_17* x_p<2> LA_N_12* x_n<2> LA_P_12* x_p<3> LA_N_10* x_n<3> LA_P_10* cc_p<1> LA_N_01* cc_n<1>...

  • Page 15: Base/Medium/Full Output Configuration

    FMC-CAMERALINK User Manual V2.7 - 5th February 2019 5.1.4 Base/Medium/Full Output Configuration The following tables show the pin usage for emulating a Base/Medium or Full camera from an FPGA design. Signal Name Direction FMC pin SDR pin (Con. 1) xclk_p...

  • Page 16: Camera Link Connector 2 (Base/Medium/Full Output Configuration)

    FMC-CAMERALINK User Manual V2.7 - 5th February 2019 Signal Name Direction FMC pin SDR pin (Con. 2) yclk_p LA_N_11* yclk_n LA_P_11* y_p<0> LA_N_13* y_n<0> LA_P_13* y_p<1> LA_N_17* y_n<1> LA_P_17* y_p<2> LA_N_12* y_n<2> LA_P_12* y_p<3> LA_N_10* y_n<3> LA_P_10* zclk_p LA_N_07* zclk_n LA_P_07* z_p<0>...

  • Page 17: Additional Features Pin-Out

    FMC-CAMERALINK User Manual V2.7 - 5th February 2019 5.2 Additional Features Pin-out 5.2.1 UFL connectors The FMC-CAMERALINK provides four LEDs that can be controlled by an attached FPGA design. Signal Name Direction FMC pin Notes Drive high to led<0> LA_P_25...

  • Page 18: Table 13 Rs232 External

    FMC-CAMERALINK User Manual V2.7 - 5th February 2019 Signal Name Direction FMC pin Notes Legacy. Has invalid_l LA_P_33 behaviour matching 'ready'. Table 12 : RS232 Interface Signal Name Direction JP1 pin Notes RS232 compatible txmon output Ground RS232 compatible rxmon...

  • Page 19: Pocl

    Table 14 : PoCL Control and Status pin-out 6.1 Current limit The FMC-CAMERALINK limits each Camera Link connector to providing up to 400mA. When the current limit is reached the supply will be disabled until the corresponding pocl_en_[a/b]_l signal is driven high.

  • Page 20: Rs232 Electrical Specifications

    FMC-CAMERALINK User Manual V2.7 - 5th February 2019 7 RS232 Electrical Specifications The tables below show the electrical characteristics of the RS232 connection (JP1) under typical operating conditions. RX Inputs Units Input Voltage Range Input Threshold Low Input Threshold High...

  • Page 21: Table

    FMC-CAMERALINK User Manual V2.7 - 5th February 2019 Revision History Date Revision Nature of Change Initial Release 25th Mar. 2014 Removed un-needed configuration section referencing SW1 26th Mar. 2014 on the Rev. 1 PCB. Added documentation for /PoCL Builds 18th Apr. 2014 Clarified PoCL and auxiliary serial functionality.
  • Page 22 FMC-CAMERALINK User Manual V2.7 - 5th February 2019 Page Intentionally left blank Address: 4 West Silvermills Lane Address: 611 Corporate Circle, Suite H Edinburgh, EH3 5BD, UK Golden, CO 80401 Telephone: +44 131 558 2600 Telephone: (303) 954 8768 Fax:...
