Before operating the awning, carefully review the Owner's Manual.
The manual contains important safety information, detailed operating
instructions, common maintenance procedures and other useful
information.
T
C
ABLE OF
Introduction ........................................................................................................... 2
Operating the Awning ........................................................................................... 2
To Open the Awning: ..................................................................................... 3
Adjusting the Pitch ......................................................................................... 4
Rain Release Setting ..................................................................................... 4
Setting the Arms in the Carport Position........................................................ 4
Closing the Awning ........................................................................................ 5
Awning Care .......................................................................................................... 6
Fabric Care .................................................................................................... 6
Carefree Product Limited Warranty ..................................................................... 7
ONTENTS
P
P
IONEER
A Manual Crank Operated Awning
O
WNER
A
ATIO
WNING
'
M
S
ANUAL
