- Page 1 Operating instructions Pneumatic High Pressure Controller, Model CPC7000 Pneumatic High Pressure Controller, Model CPC7000...
- Page 2 Mensor is a registered trademark of Mensor, LP. All other brand and product names are trademarks or registered trademarks of their respective companies. Prior to starting any work, read the operating instructions! Keep for later use! WIKA operating instructions pneumatic high pressure controller, model CPC7000...
-
Page 3: Table Of Contents
Setup Applications ......21 WIKA operating instructions pneumatic high pressure controller, model CPC7000... - Page 4 Service Application ......53 WIKA operating instructions pneumatic high pressure controller, model CPC7000...
- Page 5 Units Command Syntax for Measurement Units ....66 7.11.2 CPC7000 Error Codes ......67 7.11.3 SCPI Commands and Queries .
- Page 6 13.4 Conversion Factors, Pascal ......92 Declarations of conformity can be found online at www.wika.com. WIKA operating instructions pneumatic high pressure controller, model CPC7000...
-
Page 7: General Information
1. General information 1. General Information The CPC7000 pneumatic high pressure controller described in the operating instructions has been designed and manufactured ■ using state-of-the-art technology. All components are subject to stringent quality and environmental criteria during production. Our management systems are certified to ISO 9001 and ISO 14001. -
Page 8: Radio Frequency Emission Notices
Certifications and Accreditations Mensor is registered to ISO 9001:2008. The calibration program at Mensor is accredited by A2LA, as complying with both the ISO/ IEC 17025:2005 and the ANSI/NCSL Z540-1-1994 standards. WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 9: Short Overview
The CPC7000 can have up to three internal pressure reference transducers and an optional barometric reference for gauge or absolute emulation. The CPC7000 is available as a desktop or a rack mountable instrument. -
Page 10: Turning On
Turning On You can confirm that your CPC7000 is operational right now. Apply power to the power connector on the rear of the instrument with the included power cord, remove any plastic plugs from the rear panel pressure ports, and press the power switch to ON. The... -
Page 11: Front Panel
Front Panel The CPC7000 front panel includes an 8.9” color LCD display with touch screen. Operator input is accomplished by pressing the words or symbols and the App icons presented on the display. There is a single discrete on/off button and a USB on the right hand side. -
Page 12: Display
Settings Apps Buttons, Labels and Windows: The CPC7000 touch screen has many buttons with relevant graphic icons or text which, when touched, will open a related window where changes can be made or information viewed. Some of these buttons will toggle from one state to another, others present choices or display a numerical data entry screen. -
Page 13: Safety
... points out useful tips, recommendations and information for efficient and trouble-free operation. Intended Use The CPC7000 pneumatic high pressure controller is designed to automate the testing and calibration of pressure devices and instruments for pressures up to 10,000 psi. Up to three removable / interchangeable pressure transducers are available in full scale (FS) ranges from 1500 to 10,000 psi (100 to 700 bar) gauge or absolute. -
Page 14: Improper Use
■ that personal protective equipment is available. ■ WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 15: Personnel Qualification
Special knowledge for working with instruments for hazardous areas: The skilled (electrical) personnel must have knowledge of ignition protection types, regulations and provisions for equipment in hazardous areas. WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 16: Personal Protective Equipment
This marking on the instruments indicates that they must not be disposed of in domestic waste. The disposal is carried out by return to the manufacturer or by the corresponding municipal authorities (see EU directive 2012/19/ WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 17: Warnings And Cautions
Detachable main power supply cord delivered with inadequate ratings should not be used, it is recommended to use the power cord delivered with the instrument. See Section 11 Specifications for power ratings. Additional Warning and Caution notices are found throughout this manual. WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 18: Transport, Packaging And Storage
4. Transport, Packaging and Storage Transport Check the pneumatic high pressure controller model CPC7000 for any damage that may have been caused by transport. Obvious damage must be reported immediately. CAUTION! Damage through improper transport With improper transport, a high level of damage to property can occur. -
Page 19: Installation
The correct use of grounded working surfaces and personal armbands is required. Mounting The instrument can be set up on a desk top or it can be rack-mounted. Rack mount hardware is optional on the CPC7000 (see Section Specifications11 and Section 12 Options and Accessories). -
Page 20: Supply Port
Do not position the equipment so that it is difficult to remove the power cord. The instrument is not intended for connection of long-distance lines, i.e. lines within a building that are longer than 30 m, or that leave the building (including lines of outdoor installations). WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 21: Operation
(Peak, Rate, Rate Setpoint,Uncertainty, Units, Digital I/O and Source Pressure) will appear in the Home App if activated. All of the CPC7000 screen features are described in more detail throughout this manual. The active App is represented with a light gray background color compared to the other Apps. -
Page 22: Initial Setup
Germany French France Spanish Spain Italian Italy Japanese Japan Chinese China Korean Korea English Great Britain English Canada French Canada Spanish Latin America Polish Poland Portuguese Portugal Portuguese Brasil Russian Russia WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 23: Application Selection And Parameter Inputs
] above the input area. The purpose and use of each selection and menu is intuitively apparent and will become second nature with minimal exposure to the menu structure. Menu Button Input Title App Title WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 24: Applications
Mode button, described below, will toggle from Gauge to Absolute mode when pressed. Figure 6.4.1-A Basic Home App Figure 6.4.1-B Home App with Auxiliary Display Figure 6.4.1-C Pressure Units WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 25: Range Hold/ Autorange
“Setpoint” button and the various setpoint entry methods can be navigated with the Next Page [ ] and Previous Page [ ] buttons. Setpoint button Figure 6.4.1.2 Setpoint Button WIKA operating instructions pneumatic high pressure controller, model CPC7000... - Page 26 ] button is pressed the newly entered value will register as a new setpoint value on the Home Screen rather than a step value. Figure 6.4.1.2.2 Numeric Keypad with Step Increments WIKA operating instructions pneumatic high pressure controller, model CPC7000...
- Page 27 Each digit of the setpoint can then be increased or decreased by pressing the Up [ ] or Down [ ] button. Figure 6.4.1.2.4 Digital Step Entry WIKA operating instructions pneumatic high pressure controller, model CPC7000...
-
Page 28: Units And Pressure Type
Program Data Entry The fifth entry method is through the automated Programs stored in the CPC7000 memory. The Program Player allows the user to select one of the stored Programs and use it for setpoint entry. A Program can be chosen by using the Up [ ] or Down [ buttons. -
Page 29: Auxiliary Displays
Figure 6.4.1.6 shows the zero cal function been enabled for instrument. The background color of the zero button will momentarily change to a lighter color as the zero calibration is performed then will revert back to a darker color when complete. The screen on the right shows this. WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 30: Tare Button
Pressing the tare button again will deactivate the tare and change the pressure indication back to the reading corresponding to the calibrated output of the transducer. An active tare will revert to a deactivated state after a power cycle. WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 31: Operating Mode Selection
Operating Mode Selection The operating modes are permanently displayed on bottom of the Home App. The CPC7000 has three operating modes: Measure, Control and Vent. After the system has switched on, the instrument will automatically be placed in Vent mode. The user can switch from one mode to the other by using the mode selection keys. -
Page 32: Languages
After the setting is made and your finger is removed from the screen the menu will show the brightness percent selected and revert back to the main settings menu. Figure 6.4.2.2 Brightness WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 33: Volume
Unit multiplier. When set this way, and the user unit has been chosen from the main screen, then the user unit will now display the Special unit as derived. Figure 6.4.2.4 User base units/ Base units multiplier WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 34: Barometer Units
To reload a saved configuration at a later time, go to Settings-Configuration and press the numbered configuration button corresponding to the saved configuration and then press the “Load” button. Figure 6.4.2.6 Configuration The instrument default configuration can be activated simply by pressing the “Default” Button. WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 35: Control Settings Application
Figure 6.4.3.1 shows the data entry keyboard to enter the limits. Note that the keyboard displays the maximum value that can be entered. Figure 6.4.3.1Control limit setting WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 36: Stability Parameters
Rate Setpoint The Rate Setpoint button allows the user to set the rate of pressure change when the CPC7000 is controlling up or down to a setpoint (Figure 6.4.3.3). The rate is limited from 1 bar/second to 10% of span of active range of the transducer / second upto a maximum of 10 bar/second. -
Page 37: Rate Stability Parameters
Figure 6.4.3.5 displays the vent rate setting. The maximum allowable rate of vent is 60 bar/second and the minimum vent rate is limited to 1 bar/second. Figure 6.4.3.5 Vent Rate WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 38: Vent Limit
The Control Volume button in the Control Settings App allows the user to set the control pressure volume in cubic centimeters (cc) between 0 ... 50 cc. By default this is set to 25 cc. Figure 6.4.3.7 displays the control volume setting for the instrument. Figure 6.4.3.7 Control Volume WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 39: Display Settings Application
Turn off the Filter by selecting “Off”, select varying degrees of filtering for the current units by selecting “Low”, “Normal” or “High”. Figure 6.4.4.1 Reading Filter WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 40: Reading Resolution
] in the Home App. The Tare button and the Zero Button cannot appear on the screen at the same time. See Section 6.4.1.6 and 7.4.1.7 for operation of the Zero and Tare buttons in the Home App (main screen). Figure 6.4.4 Cal Function WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 41: Remote Application
Remote Command Set The remote command set parameter provides a choice of the Mensor command set or the WIKA SCPI command set (Figure 6.4.5.1-A). All sets of commands are listed in Section 8, Remote Operation. The termination character sets the output termination character for all remote communication command sets (Figure 6.4.5.1-B). -
Page 42: Remote Communication Settings
Setting the Ethernet DHCP to yes will have a short delay while the DHCP server is contacted. If a DHCP server is not found, an error will be indicated. If DHCP is enabled, the IP address, Netmask and Gateway are greyed out and locked, these are controlled by the DHCP server. WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 43: Step Settings Application
To enter the minimum and maximum range of the DUT select the DUT Maximum Range and DUT Minimum Range buttons (Figure 6.4.6-A) and enter the values. These ranges should be within the maximum range of the primary transducer. CPC7000 automatically switch between Pressure units and Percent of DUT Range values by pressing the units button or the percent button (Figure7.4.6 - B). -
Page 44: Preset Steps
The user can enter any percentage between 0 and 100. The desired value can then be chosen by checking the box [ ] beside the Percentage button. Figure 6.4.6.1-A 5 Preset Steps Figure 6.4.6.1-B Percentage Value Added - 90% WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 45: Programs Application
The Programs Application is used to create, view and edit programs that are used to automatically run a sequence of commands within the CPC7000. The Programs App screen displays the contents of the first written program in read only mode by default (Figure 6.4.7-A). User can load, edit and delete other saved and predefined programs by clicking on the title of the current program and then selecting the desired program sequence from the sidebar (Figure 6.4.7-B). - Page 46 Sets the rate setpoint in current units (Numerical Entry) SEQZERO Set the zero for the current active transducer SEQSTART Starts the sequence from the beginning (None) RUNITS Sets the rate denominator time unit (min or sec) WIKA operating instructions pneumatic high pressure controller, model CPC7000...
-
Page 47: Favorites Application
Model number, serial number and operating software version. ■ Regulator model number, serial number and software version. ■ Transducer model numbers, serial number, range and software version. ■ Figure 6.4.9 Information App WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 48: Troubleshooting Application
] will appear in all screens (Figure 6.4.10-A) of the instrument. Pressing this error button from any screen will open the Troubleshoot application where the error can be viewed. Figure 6.4.10-A Error Indication Figure 6.4.10-B Troubleshoot Screen WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 49: Digital I/O Application
The logic of the switch can be reversed by pressing the Invert Logic (Yes/No) button. When a digital signal (switch closure) is sent to either of the input terminal on the back panel of the CPC7000, the instrument will perform actions based on the options assigned to the input. -
Page 50: Leak Test Application
Otherwise it will return a green status indication showing that the delta was not exceeded for the Dwell Time, indicating a “passed” test. See Figure 6.4.12-A for examples of a failed and a passed test. Figure 6.4.12 Leak Test App Figure 6.4.12-A Leak Test Fail (left) and Pass (right) WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 51: Switch Test Application
Slow Rate: The rate at which the controller will control between the Low Point and the High point. ■ The Switch Test is initiated by pressing the start button. Figure 6.4.13 Switch Test App – Power Supply Figure 6.4.13-A Switch Test connections on Digital I/O Connector 1 WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 52: Burst Test Application
The burst test is initiated by pressing the Start button. Figure 6.4.14-A and 7.4.14-B show the different status messages during a burst test. Figure 6.4.14-A Burst Test App Figure 6.4.14-B Burst Test Complete (No Burst) WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 53: Service Application
123456. Enter 123456 and press the check mark [ ] to unlock the Service Application. Figure 6.4.15-B Service App (Enter Password) Note: The default password is 123456. After entering this for the first time, the password can be changed. WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 54: Unlocked Service Application
The Unlocked Service Application is the access point to all calibration screens described in Section 9 of this manual. Note: Recommended calibration setup and explanation of calibration screen applications is covered in Section 9 of this manual. WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 55: Remote Operation
Connector Pin Out designation corresponds to numbers on the connector: 1 – Ground 2 – Input #1 3 – Input #2 4 – Input #3 5 – Ground 6 – Output #1 7 – Output #2 8 – Output #3 WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 56: Remote Operating Parameters
IP addresses. The Ethernet communication port allows the CPC7000 to communicate with computers using 10/100Based-T specifications. Before using Ethernet communication, four parameters must be set up: IP, Netmask, Gateway, and Port. -
Page 57: Serial
These parameters should be set to match your host computer. Default settings are: 9600 baud, 8 data bits, 1 stop bit, no parity, and no echo. If echo is ON, the CPC7000 will immediately echo back characters sent over the serial port. The Serial function allows the user to set the RS-232 serial port settings by selecting from the choices provided: Baud ■... -
Page 58: Mensor Command Set
This Mensor command set is the default on the CPC7000. For queries (ending with a ?), the Data column represents the response of the CPC7000. All response strings begin with a space character or an “E” representing that there is an error in the error queue. -
Page 59: Cpc7000 Commands And Queries
7.11 CPC7000 Commands and Queries Table 8.11 lists all of the current CPC7000 commands and queries. Optional emulation modes are available in which a CPC7000 can emulate remote functions of different brands of pressure gauges. Please contact Mensor for more details. - Page 60 DOC? <sp>mm/dd/yyyy<cr><lf> Returns the date of cal for the active transducer. DOM? <sp>mm/dd/yyyy<cr><lf> Returns the date of manufacture Error? <sp> text description <cr><lf> Returns the next error in the error queue WIKA operating instructions pneumatic high pressure controller, model CPC7000...
- Page 61 ,2,min,max; TER,1,min,max,2,min,max <cr><lf> Listsensorinfo? <sp>PRI,SN,PTYPE,ACCURACY,1,min,max,2,min,- Returns the serial number, pressure type, accuracy, max;SEC,SN,PTYPE,ACCURACY,1,min,max,2,min,- and ranges of the installed transducers max; TER,SN,PTYPE,ACCURACY,1,min,max- ,2,min,max Localgravity Value in ft/s^2 Sets the local gravity in feet/sec^2 WIKA operating instructions pneumatic high pressure controller, model CPC7000...
- Page 62 Value in % Sets the % of the rate filter Rfilter? <sp>n.nnnnnE+nn<cr><lf> Returns the rate filter. Rsetpt Value in current units Sets the rate setpoint Rsetpt? <sp>n.nnnnnE+nn<cr><lf> Returns the rate setpoint WIKA operating instructions pneumatic high pressure controller, model CPC7000...
- Page 63 Value inside upper/lower limits and inside the range Sets the control step size for the instrument of the active transducer. Step- Jogs the setpoint down one step Step+ Jogs the setpoint up one step WIKA operating instructions pneumatic high pressure controller, model CPC7000...
- Page 64 Sets the user 1 unit mulitplier Unitfact1? <sp>n.nnnnnE+nn<cr><lf> Returns the user 1 unit multiplier Unitfact2 Multiplier factor Sets the user 2 unit mulitplier Unitfact2? <sp>n.nnnnnE+nn<cr><lf> Returns the user 2 unit multiplier WIKA operating instructions pneumatic high pressure controller, model CPC7000...
- Page 65 Returns the exponential filter window for the active transducer Zero Desired pressure or ? Sets zero to set pressure or for ?, clears previous value. CALDISABLE must be OFF/NO. Zero? <sp>n.nnnnnE+nn<cr><lf> Returns zero offset for active transducer WIKA operating instructions pneumatic high pressure controller, model CPC7000...
-
Page 66: Units Command Syntax For Measurement Units
@ 0°C Metric hectapascals Metric megapascals Metric millimeters of water @ 20°C MMH2O Metric centimeters of water @ 20C CMH2O Metric meters of water @ 20°C MH2O Metric WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 67: Cpc7000 Error Codes
EGPIB SYNTAX ERROR: String that was sent 7.11.3 SCPI Commands and Queries The WIKA SCPI command is compatible with older WIKA instruments such as the original CPC8000 Notes: 1. Note that WIKA and Ruska 7010 Emulation return slightly different responses to some queries. - Page 68 Returns status of digital output <n> :RELay<n> ON | OFF Turns the digital output on or off <n> UNIT :[PRESsure] bar | mbar | Pa | psi Sets the pressure units :[PRESsure]? Returns the pressure units WIKA operating instructions pneumatic high pressure controller, model CPC7000...
- Page 69 Autovent is always true on CPC7000 :AUTOvent? Returns the state of the Vent mode :AUTORange ON | OFF | 1 | 0 Turns autorange on or off :AUTORange? Returns “ON” or “OFF” [SOURce] :PRESsure WIKA operating instructions pneumatic high pressure controller, model CPC7000...
-
Page 70: Scpi Commands Error Messages And Error Codes
7.11.4 SCPI Commands Error Messages and Error Codes All remote commands sent to the CPC7000 are shown in the Trouble Shooting App, under the “Remote” button. If there is a syntax error, an error message will appear below the errant command. Local errors and remote command errors will appear under the “Error”... -
Page 71: Faults
Figure 8.1 Fuse location Figure 8.2 Fuse replacement If you need help or assistance, contact Mensor at Phone: 1-512-396-4200 or 1-800-984-4200 (USA only) ■ Fax: 512-396-1820 ■ Website: www.mensor.com ■ Email: sales@mensor.com ■ tech.support@mensor.com WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 72: Maintenance And Recalibration
We use this knowledge in our continuing effort to design better and more robust instruments. • Repair or replacement of the CPC7000 chassis, module and measurement transducers will be available up to 7 years after the production life cycle of the product, pending external vender parts or equivalent parts availability. The production life cycle is defined as the time from the product series launch to the announcement of discontinuation (typically 8 to 10 years). - Page 73 Do not risk voiding the warranty. Higher level repairs must be carried out exclusively by Mensor authorized personnel, or under Mensor supervision. Servicing of electrical, electronic or pneumatic equipment must be performed by qualified and authorized technical staff, observing all relevant safety regulations. WIKA operating instructions pneumatic high pressure controller, model CPC7000...
-
Page 74: Barometric Sensor (Optional) Removal
Barometric Sensor (optional) Removal To remove the optional Barometric reference sensor, first turn off the CPC7000 and loosen the Phillips head screws that secure the door. The barometric reference sensor is positioned behind the front door next to the primary transducer in the pressure controller (Figure 9.1.3). -
Page 75: Recalibration
15-45°C. The process is referred to as dynamic compensation because each reading is so adjusted before it is output to the display or to a communication bus. Thus, a calibrated CPC7000 operated within its temperature band, and with proper zero and span adjustments, will provide accurate pressure measurements. -
Page 76: Setup
LINE REGULATOR Computer (optional) METERING VENT VALVE SHUT-OFF VALVE VOLUME CONTROLLER RS232, IEEE488, Ethernet, or USB MEASURE/CONTROL PORT PRESSURE PRESS CPC7000 PRESSURE REFERENCE PORT STANDARD REFERENCE ATMOSPHERE Figure 9.2.5 Calibration Setup WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 77: Calibration Data
600 mTorr absolute and 20% of the active transducer’s span to the Measure/Control port of the CPC7000, press the “New Value” button and then enter the reference pressure (known true pressure) using the keypad. -
Page 78: Two Point Cal Application
Select a Transducer to calibrate by pressing the Range button at the top of the screen. To calibrate the “Low Point”: 1. The Measure/Control port of the CPC7000 being calibrated should be supplied with a suitable, “Low point” pressure (see section 5.4 - Rear Panel for the port location). -
Page 79: Linearization
These values can be changed to reflect the values generated by the reference standard and the corresponding readings taken from the CPC7000. Each value from the reference standard can be entered under the reference column, corresponding Upscale and Downscale readings from the instrument can be entered in the “Actual”... -
Page 80: Head Pressure
The four parameters are used to calculate the pressure that is a result of the different elevations. It should not be used when calibrating CPC7000 transducers. The Head height should be set at zero before calibrating the transducers of the CPC7000. - Page 81 The Head Pressure should not be active when calibrating CPC7000 transducers. The Head height should be set at zero before calibrating the transducers of the CPC7000. Difference in height between the laboratory standard and the CPC7000 during calibration should be factored into the uncertainty analysis.
-
Page 82: Dismounting, Return And Disposal
▶ Observe the information in the material safety data sheet for the corresponding medium. ▶ Only disconnect the pressure measuring instrument/measuring assembly/test and calibration installations once the system has been depressurised. WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 83: Return
10. Dismounting, Return and Disposal 10.2 Return Strictly observe the following when shipping the instrument: All instruments delivered to WIKA must be free from any kind of hazardous substances (acids, bases, solutions, etc.) and must therefore be cleaned before being returned. WARNING! Physical injuries and damage to property and the environment through residual media Residual media in the dismounted instrument can result in a risk to persons, the environment and equipment. -
Page 84: Specifications
Standard: 5 ports with M16 x 1.5 female with sealing cone Optional: 2 ports with 9/16-18 UNF female Optional barometer: M12 x 1 female thread Filter elements The instrument has a 20-micron filters on all pressure ports. WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 85: Approvals And Certificates
5) Regarding a 10% FS pressure increase in 25 ml test volume 11.3 Approvals and Certificates Certificate Calibration Standard: 3.1 factory calibration certificate Option: DKD/DAkkS calibration certificate 6) Calibration in a horizontal position/operating position. WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 86: Dimensions In Mm (In)
11. Specifications 11.4 Dimensions in mm (in) 11.4.1 Desktop 11.4.2 19” Rackmount WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 87: Accessories
12.1 Barometric Reference Sensor The CPC7000 can be ordered with a barometric reference sensor. It is a very stable, absolute pressure transducer, used to accurately measure local atmospheric pressure. It is used to display the barometric pressure (reading appears on the bottom right side of the display) or as a barometric reference for gauge or absolute emulation. -
Page 88: 19" Rackmount
12.3 19” Rackmount A rack mount kit allows the customer to install a CPC7000 into a standard 19” instrument rack. It includes mounting tabs to the front panel of the instrument to secure it in the rack mount as shown in Section 11.4.2. -
Page 89: Appendix
@ 20°C mm H2O 20°C centimeter of water @ 20°C cm H2O 20°C meters of water @ 20°C m H2O 20°C User Units 1 User defined WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 90: Conversion Factors, Psi
1.462303 0.0625 0.006944444 0.072 13.88889 µHg 0°C 51715.08 0.00001933672 0.0005 2000 mHg 0°C 0.05171508 19.33672 68.94757 0.01450377 0.006894757 145.0377 mmH2O 20°C 704.336 0.001419777 cmH2O 20°C 70.4336 0.01419777 MH2O 20°C 0.704336 1.419777 WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 91: Conversion Factors, Millitorr
0.00001322347 75623.11663 0.0003093875 3232.1992 0.002784488 359.132477 0.000001392244 718265.0575 µHg 0°C 1.000000000 0.00000000966836 103430160.00 0.000001 1000000.00 0.001333220 750.0636259 0.0000001333220 7500636.259 mmH2O 20°C 0.01361955 73.42388114 cmH2O 20°C 0.001361955 734.2388114 MH2O 20°C 0.00001361955 73423.88114 WIKA operating instructions pneumatic high pressure controller, model CPC7000... -
Page 92: Conversion Factors, Pascal
4.309223E+02 2.088543E-02 4.788025E+01 1.044271E-05 9.576052E+04 µHg 0°C 7.500636E+00 1.333220E-01 7.251885E-08 1.378951E+07 mHg 0°C 7.500636E-06 1.333220E+05 1.00000E-02 1.00000E+02 1.00000E-06 1.00000E+06 mmH2O 20°C 1.021553E-01 9.789017E+00 cmH2O 20°C 1.021553E-02 9.789017E+01 MH2O 20°C 1.021553E-04 9.789017E+03 WIKA operating instructions pneumatic high pressure controller, model CPC7000... - Page 93 San Marcos, TX 78666 • USA 63911 Klingenberg • Germany Tel. (+1) 512 3964200-15 Tel. +49 9372 132-0 Fax (+1) 512 3961820 Fax +49 9372 132-406 E-Mail sales@mensor.com info@wika.de www.mensor.com www.wika.de WIKA operating instructions pneumatic high pressure controller, model CPC7000...
