2. Damage or malfunction of the SRS/SIPS bag/IC system. Work involving the SRS/SIPS bag/IC systems or other components in the vehicle that may affect the SRS/SIPS bag/IC systems must always be performed by an authorized Volvo workshop. In case of doubt, consult the SRS and SIPS bag/IC service manual.
Table of Contents 1:2 Vehicles with SRS (Airbag)/SIPS bag/ Emission control, 5-cyl Turbo........51 IC (Inflatable Curtain)............. 2 Abbreviations ..............5 Group 26 Cooling system How to use the wiring diagrams 1:2....... 6 Cooling fan..............52 Electrical distribution 1:2..........8 Group 27 Engine control Fuses Cruise control, 4-cyl.
Page 4
Table of Contents 2:2 Group 37 Wiring and fuses Power driver’s seat with memory function, RHD ..124 Power passenger seat with memory function, LHD ... 125 Diagnostics system............87 Power passenger seat with memory function, RHD .. 126 12V outlet ..............88 Power driver’s seat, LHD ...........
Explanations Abbreviations Groups Other Group 23 = Fuel system AUTO = Automatic transmission Group 26 = Cooling system = CAN communication Group 27 = Engine controls = Display Group 32 = Alternator and voltage regulator = Electronic climate control system Group 33 = Starting system = Engine throttle body...
How to use the wiring diagrams 1:2 The descriptions below apply in general to all wiring diagram manuals, although not all sections are necessarily con- tained in this manual. A. Component designation B. Branching points Every component has a component designation that The wiring diagrams contain numbered junction consists of two parts.
How to use the wiring diagrams 2:2 List of symbols = System voltage 4/28 AUTO 3/156 = Ground connection via 64/90 64/111 15/31 3/155 WH-RD WH-RD wiring = Ground connection on 4/56 component/chassis E:22 RD-BU E:21 RD-YE = Screened wire 2/80 D:14 D:15...
Fuses Engine compartment distribution box F1-F8 F24 F21 F20 F22 F14 F12 F10 F28 F27 F26 F23 15/31 Engine compartment distribution box Fuse function 4/71 Cooling fan control module 6/71 Electrical Power Steering Module (EPS) 2/193 Relay, comfort functions Fuse in the Central Electronic Module (CEM) 2/193 F48-F49 Fuses in the Central Electronic Module (CEM) 2/193...
Fuses Engine compartment distribution box F9-F18 F24 F21 F20 F22 F14 F12 F10 F28 F27 F26 F23 15/31 Engine compartment distribution box Fuse function 2/32 Main relay, engine management system F32-F36 Fuses in the engine compartment distribution box 2/32 4/31 Fan control module 6/104 Pump, high pressure headlight washer...
Fuses Central Electronic Module (CEM) F57-F69 4/56 Central Electronic Module (CEM) Fuse function 4/46 Engine Control Module (ECM), 5-cyl. 2,4l 4/56 Central Electronic Module (CEM) 17/13 Data link connector 2/64 Relay, auxiliary lights (accessory) 3/60 4/113 Control module, gas discharge lamp slave, right 10/2 Lamp housing, front right 4/112...
Fuses Battery PF1-PF2 1/1 Battery Fuse function 6/25 Starter motor 6/26 Alternator F1-F14 Fuses in the engine compartment distribution box F16-F18 Fuses in the engine compartment distribution box F20-F21 Fuses in the engine compartment distribution box F23-F24 Fuses in the engine compartment distribution box F26-F27 Fuses in the engine compartment distribution box F29-F31 Fuses in the engine compartment distribution box TP3992202 C70 (06-) 2006...
Relays Ignition switch and relays Position Terminal Key Out Relays, general The diagram indicates two or three different designations for the relay’s position. This is described below. A = Corresponds to the position on the back of the relay box (wiring side) B = Corresponds to the position on the relay C = An old designation that may be found on 1(86)
Relays Distribution box in engine compartment R1-R14 15/31 Engine compartment distribution box Relay function 2/17 Relay, horn 2/34 Relay, front fog lights 2/142 Relay, preheater, fuel filter 2/182 Relay, headlight washer motor 2/82 Relay, heated rear window 2/22 Relay, climate control system 2/35 Relay, starter motor 2/32...
Control modules Accessory Electronic Module (AEM) B:26 B:50 B:25 Function Type Electrical distribution Ground Electrical distribution Feed CAN communication Input/output signals CAN communication Input/output signals Electric engine heater Steering, alternating current feed B:11 Handsfree, mute of audio Input signal B:15 Alarm signal Output signal B:16...
Group 32 Alternator and voltage regulator Power supply, 4-cyl 31/4 31/3 6/25 15/31 4/56 G:13 64/90 6/26 4/46.5 VOLT. REG. B:15 B:20 1.8 L TP3992202 C70 (06-) 2006...
Group 35 Lighting High and low beam 3/254 15/31 RD-BU RD-YE 4/56 B:31 E:22 E:21 E:25 E:37 2/63 E:27 E:11 A:28 10/1 10/2 HIGH PARK TURN TURN PARK HIGH LOW GN-OG GN-BK GN-WH 63/109 63/121 GN-VT 3/111 63/25 LIGHTS ON 1 = ST.
Group 35 Lighting High and low beam (Bi-Xenon) 3/111 3/254 15/31 LIGHTS ON 1 = ST. LAMPS FF = FRONT FOG SEARCH DIMMER FUEL LID SWITCH 2 = LOW BEAM RF = REAR FOG ILL. 4/56 B:31 E:22 E:21 A:40 BK-GN BK-BU E:37...
Group 35 Lighting Fog lights RD-GN RD-OG RD-OG 15/31 2/34 GN-WH GN-WH 4/56 E:21 E:22 3/111 LIGHTS ON 1 = ST. LAMPS FF = FRONT FOG SEARCH DIMMER FUEL LID SWITCH 2 = LOW BEAM RF = REAR FOG ILL. A:32 GN-BU B:23...
Group 35 Lighting Fog lights LHD, Japan RD-GN RD-OG RD-OG 15/31 2/34 GN-WH GN-WH 4/56 E:21 E:22 3/111 LIGHTS ON 1 = ST. LAMPS FF = FRONT FOG SEARCH DIMMER FUEL LID SWITCH 2 = LOW BEAM RF = REAR FOG ILL.
Group 35 Lighting Instrument and control illumination 15/31 3/126 3/127 D:12 A:12 A:13 A:13 E:22 4/56 E:21 2/89 F:15 3/111 F:30 LIGHTS ON 1 = ST. LAMPS FF = FRONT FOG SEARCH DIMMER FUEL LID SWITCH 2 = LOW BEAM RF = REAR FOG ILL.
Group 83 Doors and openings Central locking, fuel filler flap 15/31 4/56 E:21 E:22 A:28 63/25 A:14 63/12 A:34 BK-WH 3/111 LIGHTS ON 1 = ST. LAMPS FF = FRONT FOG SEARCH DIMMER FUEL LID SWITCH 2 = LOW BEAM RF = REAR FOG ILL.
Group 87 Climate control system Climate control system PTC element 15/31 64/111 64/861 4/56 A:17 E:22 E:21 9/41 GN-OG WH-BK 64/862 31/112 TP3992202 C70 (06-) 2006...
Connectors 64/10B - 64/25G 64/10B 6-pin gray Roof harness Floor harness 4/56H:21 Central Electronic Module 63/218 Branching point OG-YE OG-YE (CEM) 4/56H:17 Central Electronic Module 63/217 Branching point WH-RD WH-RD (CEM) 64/25G 10-pin gray Dashboard harness Tunnel harness 4/56A:23 Central Electronic Module 9/1:1 Front 12V outlet (CEM)
Page 146
Connectors 64/30:1-14 64/30 20-pin black Floor harness Driver’s seat harness 63/171 Branching point, RHD 9/12A:1 Seat Heating Module (SHM), 63/172 Branching point driver’s side 4/56C:43 Central Electronic Module 9/12A:4 Seat Heating Module (SHM), GN-BK (CEM) driver’s side 64/112:6 Connector, RHD 9/12A:2 Seat Heating Module (SHM), 64/112:7...
Page 147
Connectors 64/30:15-20 - 64/31:1-8 64/30 20-pin black Floor harness Driver’s seat harness 4/56C:30 Central Electronic Module 3/26:2 Switch unit, power driver’s OG-YE RD-BU (CEM) seat, LHD 3/26:5 Switch unit, power driver’s seat, RHD 4/52A:1 Power Seat Module (PSM), memory 63/171 Branching point, RHD 3/26:3 Switch unit, power driver’s...
Page 149
Connectors 64/41 64/41 26-pin black Driver’s door harness Floor harness 3/126A:3 Driver Door Module (DDM) 63/220 Branching point GY-RD GY-RD 3/126A:12 Driver Door Module (DDM) 63/221 Branching point BU-RD BU-RD 3/74:4 Lock unit, driver’s door 4/56F:18 Central Electronic Module, 4/56F:19 Central Electronic Module 3/126A:13 Driver Door Module (DDM)
Page 150
Connectors 64/43 64/43 26-pin black Passenger door harness Floor harness 3/127A:3 Passenger Door Module 63/220 Branching point, RHD GY-RD GY-RD (PDM) 63/232 Branching point, LHD 3/75:4 Lock unit, passenger door 4/56F:18 Central Electronic Module (CEM), LHD 4/56F:19 Central Electronic Module (CEM), RHD 3/127A:13 Passenger Door Module...
Page 160
Connectors 64/113 64/113 29-pin black Floor harness Engine compartment harness 64/816:1 Connector 4/16:36 Brake Control Module (BCM) 64/816:2 Connector 4/16:37 Brake Control Module (BCM) 64/817:1 Connector YE-GN 4/16:43 Brake Control Module (BCM) YE-GN 64/817:2 Connector WH-GN 4/16:42 Brake Control Module (BCM) WH-GN 9/2:7 Heated rear window...
Page 161
Connectors 64/114 - 64/233 64/114 2-pin gray Floor harness Engine compartment harness 4/31:1 Fan control module F10:2 Fuse GN-OG GN-OG 4/31:6 Fan control module 63/108 Branching point 64/120 1-pin black Engine harness Starter motor harness 64/90:11 Connector 6/25A:1 Starter motor 64/179G 1-pin gray Floor harness...
Page 162
Connectors 64/245 - 64/322 64/245 3-pin green Floor harness Checking the CRM 63/228 Branching point Low speed = CAN high data signal GY-RD 63/229 Branching point BU-RD Low speed = CAN low data signal 64/246 4-pin gray Floor harness Floor harness 63/184 Branching point 4/59B:1...
Page 163
Connectors 64/425 - 64/545:1-3 64/425 6-pin yellow Dashboard harness SRS passenger side harness 4/9B:1 Supplemental Restraint 8/31:1 Igniter, airbag stage 1, System module (SRS) passenger side 4/9B:2 Supplemental Restraint 8/31:2 Igniter, airbag stage 1, BK-WH BK-WH System module (SRS) passenger side 63/12 Branching point BK-GN...
Page 164
Connectors 64/545:4-6 - 64/600 64/545 6-pin light gray Dashboard harness Climate control system harness 63/25 Branching point 6/48:3 Damper Motor Module (DMM), recirculation 6/96:3 Damper Motor Module (DMM), right-hand side 6/102:3 Damper Motor Module (DMM), defroster 6/103:3 Damper Motor Module (DMM), floor/ventilation 7/159:3 Air Quality Sensor (AQS)
Page 165
Connectors 64/660 - 64/662 64/660 12-pin gray Driver’s door harness, addition Driver’s door harness 16/4:1 Speaker, driver’s door 16/151:6 Crossover filter, left-hand front WH-BU WH-BU door 16/4:2 Speaker, driver’s door 16/151:5 Crossover filter, left-hand front GY-BU WH-BU door 8/137:2 Lock motor, left door compart- WH-BK 64/41:24 Connector...
Page 166
Connectors 64/663 - 64/708 64/663 2-pin yellow/green Driver’s door harness Driver’s door harness, extra 64/43:8 Connector 8/67:1 Igniter, right inflatable curtain 64/43:9 Connector 8/67:2 Igniter, right inflatable curtain BK-BU BK-RD 64/707 6-pin gray, option A Driver’s door harness 63/41 Branching point 64/707:4 Connector 63/40...
Page 167
Connectors 64/708 - 64/862 64/708 6-pin gray, option B Driver’s door harness 63/43 Branching point 16/151:1 Crossover filter, left-hand front door 63/42 Branching point 16/151:2 Crossover filter, left-hand front door 16/4:2 Speaker, passenger door 16/151:3 Crossover filter, left-hand front door 16/4:1 Speaker, passenger door 16/151:4...
Cable harness routing in vehicle Harness, rear side panel, right C70 64/80 Cable harness routing in vehicle Harness, rear side panel, left C70 64/80 TP3992202 C70 (06-) 2006...
Component illustrations 1/1 - 2/64 Battery 2/34 Relay, front fog lights R 9- R 6- R 10- R 7- R 12- R 3- R 1- R 11- R 8- R 5- R 4- R 2- R 14- R 13- P104_1-1 P104_2-34 2/17 Relay, horn...
Page 192
Component illustrations 2/82 - 3/1 2/82 Relay, heated rear window 2/182 Relay, headlight washer motor R 9- R 6- R 9- R 6- R 10- R 7- R 10- R 7- R 12- R 12- R 3- R 1- R 3- R 1- R 11- R 11-...
Page 193
Component illustrations 3/4 - 3/37 Switch unit, cruise control (SWS) 3/25 Switch, power roof P104_3-4 Switch, hazard warning flashers 3/26 Switch unit, power driver’s seat P104_3-6 P104_3-26 Switch, heated rear window/door mirrors 3/27 Switch unit, power passenger seat P104_3-8 P104_3-27 Contact brake light 3/35 Switch, handle, trunk lid/tailgate...
Page 194
Component illustrations 3/39 - 3/81 3/39 Contact clutch pedal, Gasoline 3/74 Lock unit, driver’s door P104_3-39_T,S P104_3-74 3/46 Seat contact, passenger seat 3/75 Lock unit, passenger door P104_3-46 P104_3-75 3/47 Parking brake contact 3/78 Lock unit, trunk lid/tailgate P104_3-47 P104_3-78 3/60 Switch, auxiliary lights 3/80...
Page 195
Component illustrations 3/82 - 3/128 3/82 Switch, central locking passenger door 3/112 Climate Control Module (CCM) P104_3-112 P104_3-82 3/83 Switch, power window passenger door 3/117 Switch unit, ceiling light P104_3-83 P104_3-117 3/93 Belt buckle contact, driver’s seat 3/126 Driver Door Module (DDM) P104_3-93 P104_3-126 3/94...
Page 196
Component illustrations 3/129 - 3/255 3/129 Right Rear Door Module (RDM) 3/174 Switch, reduced alarm P104_3-129 P104_3-174 3/155 Program selector, automatic trans- mission 3/217 Belt buckle contact, left rear P104_3-155 P104_3-217 3/156 Gear Selector Module (GSM) 3/219 Belt buckle contact, right rear P104_3-156 P104_3-219 3/157 Switch, passenger side airbag...
Page 197
Component illustrations 3/256 - 4/9 3/256 Position sensor, passenger seat 3/267 Switch unit, telematics P104_3-256_USA P104_3-267 3/258 Contact, locking front left 3/268 Switch, loading assistance 3/259 Contact, locking, front right 3/271 Contact, immobilizer, clutch pedal P104_3-271 3/262 Contact, unlocking, front left Combustion Preheater Module (CPM) Supplemental Restraint System Module (SRS)
Page 198
Component illustrations 4/16 - 4/59 4/46.3 Engine Control Module (ECM), 5-cyl. 2.4l D 4/16 Brake Control Module (BCM) 4/46.5 Engine Control Module (ECM), 4-cyl. 1.8l 4/28 Transmission Control Module (TCM) P104_4-46 4/31 Fan control module 4/52 Power Seat Module (PSM) P104_4-31 P104_4-52 4/46...
Page 213
Component illustrations 8/45 - 8/66 8/45 Solenoid, variable valve timing, intake 8/56 Igniter, right rear belt tensioner P104_8-55 8/48 Auto-dimming rearview mirror 8/57 Igniter, left anti-roll bar P104_8-48 8/51 Igniter side airbag, driver’s side 8/58 Igniter, right anti-roll bar P104_8-51 8/52 Igniter side airbag, passenger side 8/61...
Page 218
Component illustrations 10/3 - 10/17 10/3 License plate lighting 10/13 Direction indicator, front left P104_10-13 10/5 Fog light, front left 10/14 Direction indicator, front right P104_10-5 P104_10-14 10/15 Direction indicator, rear-view mirror driver’s door 10/6 Fog light, front right P104_10-6 P104_10-15 10/16 Direction indicator, passenger door mirror...
Page 219
Component illustrations 10/18 - 10/45 10/18 Lamp housing, rear left 10/27 Reading light, rear right 10/19 Brake light extra 10/29 Glove compartment lighting P104_10-29 10/22 Ceiling light 10/43 Brake light, right P104_10-22 10/24 Cargo compartment lighting 10/44 Tail light 1, right 10/26 Reading light, rear left 10/45 Tail light 2, right TP3992202 C70 (06-) 2006...
Page 220
Component illustrations 10/46 - 10/64 10/46 Fog light, right rear 10/52 Tail light 2, left 10/47 Direction indicator, right rear 10/53 Fog light, left rear 10/48 Reversing light, right 10/54 Direction indicator, left rear 10/50 Brake light, left 10/55 Reversing light, left 10/51 Tail light 1, left 10/64 High beam, right P104_10-64...
Page 221
Component illustrations 10/65 - 10/148 10/65 Auxiliary light, front right 10/97 Courtesy lighting, left P104_10-97 10/66 Low beam, right 10/102 Courtesy lighting, right P104_10-66 10/68 High beam, left 10/114 Vanity mirror lighting, left P104_10-66 P104_10-114 10/69 Auxiliary light, front left 10/115 Vanity mirror lighting, right P104_10-115 10/148 Lighting, rear-view mirror driver’s...
Page 222
Component illustrations 10/149 - 16/6 10/149 Lighting, rear-view mirror passenger door 16/1.2 Infotainment Control Module (ICM) P104_10-149 10/245 Lock indicator, left door 16/3 Speaker, passenger door 10/246 Lock indicator, right door 16/4 Speaker, driver’s door 15/31 Distribution box in engine compart- ment 16/5 Speaker, rear right...
Page 235
Component illustrations R/no. - 64X/322 R/no. Relay, engine compartment R 9- R 6- R 10- R 7- R 12- R 3- R 1- R 11- R 8- R 14- R 13- R 5- R 4- R 2- P104_215 4X/110 Connector interface, original car 10X/17 Connector interface, original car 10X/18...
List of components 1:5 Battery 3/117 Switch unit, ceiling light 3/126 Driver Door Module (DDM) 2/17 Relay, horn 3/127 Passenger Door Module (PDM) 2/22 Relay, climate control system 3/128 Left Rear Door Module (LDM) 2/23 Relay, fuel pump 3/129 Right Rear Door Module (RDM) 2/32 Main relay, engine management system 3/155...
Page 239
List of components 2:5 Driver Information Module (DIM) Temperature sensor battery Brake fluid level sensor Wiper Motor Module (WMM) Washer fluid level sensor Washer pump Oil pressure monitor, 4-cyl 6/16 Motor driver’s seat, backrest angle Oil pressure monitor, 5-cyl 6/17 Motor driver’s seat, up/down front edge Oil pressure monitor, Turbo 6/18...
Page 240
List of components 3:5 7/131- 8/40 Lock-up solenoid 7/134 Parking assistance sensor 1-4 8/41 Pressure solenoid 7/143 Sensor fuel level, pump side 8/45 Solenoid, variable valve timing, intake 7/149 Rain Sensor Module (RSM) 8/48 Auto-dimming rearview mirror 7/154 Sensor fuel temperature 8/51 Igniter side airbag, driver’s side 7/156...
Page 241
List of components 4:5 10/1 Lamp housing, front left 16/1 Integrated Audio Module (IAM) 10/2 Lamp housing, front right 16/1.2 Infotainment Control Module (ICM) 10/3 License plate lighting 16/3 Speaker, passenger door 10/5 Fog light, front left 16/4 Speaker, driver’s door 10/6 Fog light, front right 16/5...
Page 242
List of components 5:5 18/4 Contact reel 64/80 Connector 64/80A Connector 20/3-7 Spark plug and ignition coil 64/90 Connector 20/22-26 Glow plug 64/111 Connector 64/112 Connector 26/5 DC/AC converter, fuel tank 64/113 Connector 64/114 Connector 31/3 Ground connection, left MacPherson strut 64/120 Connector tower...
Page 243
TP 3992202 (US English). Printed in Gothenburg, Sweden 11-2005...
Page 245
Index 2:2 Relays in the Central Electronic Module (CEM) .... 20 Relays, general ................ 18 Manual beam length adjustment ........62 Reversing lights ............... 69 Memoey function, passenger seat ........125 Memory function driver’s seat ........ 123 Memory function, passenger seat ........126 MOST ..................
Page 246
List of components 1:5 Battery 3/117 Switch unit, ceiling light 3/126 Driver Door Module (DDM) 2/17 Relay, horn 3/127 Passenger Door Module (PDM) 2/22 Relay, climate control system 3/128 Left Rear Door Module (LDM) 2/23 Relay, fuel pump 3/129 Right Rear Door Module (RDM) 2/32 Main relay, engine management system 3/155...
Page 247
List of components 2:5 Driver Information Module (DIM) Temperature sensor battery Brake fluid level sensor Wiper Motor Module (WMM) Washer fluid level sensor Washer pump Oil pressure monitor, 4-cyl 6/16 Motor driver’s seat, backrest angle Oil pressure monitor, 5-cyl 6/17 Motor driver’s seat, up/down front edge Oil pressure monitor, Turbo 6/18...
Page 248
List of components 3:5 7/131- 8/40 Lock-up solenoid 7/134 Parking assistance sensor 1-4 8/41 Pressure solenoid 7/143 Sensor fuel level, pump side 8/45 Solenoid, variable valve timing, intake 7/149 Rain Sensor Module (RSM) 8/48 Auto-dimming rearview mirror 7/154 Sensor fuel temperature 8/51 Igniter side airbag, driver’s side 7/156...
Page 249
List of components 4:5 10/1 Lamp housing, front left 16/1 Integrated Audio Module (IAM) 10/2 Lamp housing, front right 16/1.2 Infotainment Control Module (ICM) 10/3 License plate lighting 16/3 Speaker, passenger door 10/5 Fog light, front left 16/4 Speaker, driver’s door 10/6 Fog light, front right 16/5...
Page 250
List of components 5:5 18/4 Contact reel 64/80 Connector 64/80A Connector 20/3-7 Spark plug and ignition coil 64/90 Connector 20/22-26 Glow plug 64/111 Connector 64/112 Connector 26/5 DC/AC converter, fuel tank 64/113 Connector 64/114 Connector 31/3 Ground connection, left MacPherson strut 64/120 Connector tower...
Page 251
Table of Contents 1:2 Vehicles with SRS (Airbag)/SIPS bag/ Emission control, 5-cyl Turbo........51 IC (Inflatable Curtain)............. 2 Abbreviations ..............5 Group 26 Cooling system How to use the wiring diagrams 1:2....... 6 Cooling fan..............52 Electrical distribution 1:2..........8 Group 27 Engine control Fuses Cruise control, 4-cyl.
Page 252
Table of Contents 2:2 Group 37 Wiring and fuses Power driver’s seat with memory function, RHD ..124 Power passenger seat with memory function, LHD ... 125 Diagnostics system............87 Power passenger seat with memory function, RHD .. 126 12V outlet ..............88 Power driver’s seat, LHD ...........
