2 0 0 6
VOLVO
S60
Introduction
Welcome to the world-wide family of Volvo owners. We trust that you will enjoy many years of safe driving in your
Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this
vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and
maintenance requirements/recommendations in this manual. We also urge you and your passengers to wear seat belts
at all times in this (or any other) automobile. And, of course, please do not operate a vehicle if you may be affected by
alcohol, medication or any impairment that could hinder your ability to drive.
Your Volvo is designed to meet all applicable safety and emission standards, as evidenced by the certification labels
attached to the driver's door opening and on the left wheel housing in the engine compartment.
For further information please contact your retailer, or:
In the USA:
Volvo Cars of North America
Customer Care Center
P.O. Box 914
Rockleigh, New Jersey 07647-0914
800-458-1552
http://www.volvocars.us
In Canada:
Volvo Cars of Canada Ltd.
National Customer Service
175 Gordon Baker Road

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2006 S60 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Volvo 2006 S60

Summary of Contents for Volvo 2006 S60

  • Page 1 Introduction Welcome to the world-wide family of Volvo owners. We trust that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and maintenance requirements/recommendations in this manual.
  • Page 2 Please note that some vehicles may be equipped differently, depending on special legal requirements. Optional equipment described in this manual may not be available in all markets. Volvo reserves the right to make model changes at any time, or to change specifications or design without notice and without incurring obligation.
  • Page 3 Volvo and the environment Volvo is committed to the well being of its customers. As a natural part of this commitment, we care about the environment in which we all live. Caring for the environment means an everyday involvement in reducing our environmental impact.

  • Page 4: Table Of Contents

    PremAir is a registered trademark of Engelhard Corporation. Instruments, switches and controls Page 1. Front fog lights 2. Headlights/Parking lights/switch for unlocking fuel filler door 3. Rear fog light 4. Turn signals/High/low beams 5. Cruise control 6. Horn 7. Instrument panel 8.
  • Page 5 20. Odometer/ Trip odometer/Cruise control indicator 21. Speedometer 22. Turn signal indicators 23. Tachometer 24. Ambient temperature/Clock/Selected gear indicator 25. Fuel gauge 26. Indicator and warning symbols 27. - 28. Panel vents 29. Instrument lighting 30. Lighting panel 31. Reading lights 32.
  • Page 6 Wheels and tires Car care Maintenance and service Specifications Audio Index Back Cover Contents Top of Page...
  • Page 7 Volvo Concern for Safety Safety is the Volvo cornerstone. Our concern dates back to 1927 when the first Volvo rolled off the production line. Three-point seat belts (a Volvo invention), safety cages, and energy-absorbing impact zones were designed into Volvo cars long before it was fashionable or required by government regulation.
  • Page 8 Volvo strongly recommends that if your vehicle is covered under a service campaign, safety or emission recall or similar action, it should be completed as soon as possible. Please check with your local retailer or Volvo Cars of North America, LLC if your vehicle is covered under these conditions.
  • Page 9 - Never repair the belt yourself; have this work done by an authorized Volvo service technician only. - Any device used to induce slack into the shoulder belt portion of the three-point belt system will have a detrimental effect on the amount of protection available to you in the event of a collision.
  • Page 10 Supplemental Restraint System (SRS) SRS warning light Supplemental Restraint System As an enhancement to the three-point seat belts, your Volvo is equipped with a Supplemental Restraint System (SRS). Volvo's SRS consists of seat belt tensioners, front airbags, side impact airbags, the occupant weight sensor, and inflatable curtains.

  • Page 11: Front Airbags

    Volvo service technician as soon as possible. - Never try to repair any component or part of the SRS yourself. Any interference in the system could cause malfunction and serious injury. All work on these systems should be performed by an authorized Volvo service technician.
  • Page 12 70% of their total capacity. If the impact is more severe, the dual-stage airbags are triggered at full capacity. Should you have questions about any component in the SRS system, please contact a trained and qualified Volvo...
  • Page 13 Volvo Customer Support: In the USA: Volvo Cars of North America Customer Care Center P.O. Box 914 Rockleigh, New Jersey 07647-0914 800-458-1552 http://www.volvocars.us In Canada: Volvo Cars of Canada Ltd. National Customer Service 175 Gordon Baker Road...
  • Page 14 Disabling the passenger's side front airbag Volvo recommends that ALL occupants (adults and children) shorter than four feet seven inches (140 cm) be seated in the back seat of any vehicle with a front passenger side airbag, and be properly restrained for their size and weight.
  • Page 15 If a fault in the system is detected and indicated as explained on the previous page, be aware that the passenger's side front airbag will not deploy in the event of a collision. In this case, the safety systems and Occupant Weight Sensor should be inspected by an authorized Volvo retailer as soon as possible.
  • Page 16 - Never try to open, remove, or repair any components in the OWS system. This could result in system malfunction. Maintenance or repairs should only be carried out by an authorized Volvo service technician. - The front passenger's seat should not be modified in any way. This could reduce pressure on the seat cushion, which might interfere with the OWS system's function.
  • Page 17 2 0 0 6 VOLVO Instruments and controls pg. 23 Instruments and controls Instrument panel Indicator and warning symbols Switches in the center console Steering wheel adjustment Lighting panel Manually unlocking the fuel filler door Left-side steering wheel lever Right-side steering wheel lever...

  • Page 18: Indicator And Warning Symbols

    on. The text window will provide you with additional information. If the engine temperature remains high, check coolant level - see page 140. 4. Trip odometer The trip odometers are used for measuring shorter distances. The right-hand digit gives tenth of a mile/kilometer. Press the button for more than 2 seconds to reset.
  • Page 19 Anti-lock brake system ABS If the warning light comes on, there is a malfunction of the ABS system (the standard braking system will still function). The vehicle should be driven to a Volvo retailer for inspection. See page 97 for additional information.
  • Page 20 If the fluid level is below the MIN mark in the reservoir or if a "Brake failure - Service urgent" message is displayed in the text window: DO NOT DRIVE. Have the car towed to an authorized Volvo retailer and have the brake system inspected.
  • Page 21 URGENT: Refer to your owner's manual. For additional information, please contact your Volvo retailer. MANUAL: SERVICE Take your car to an authorized Volvo retailer for inspection at your convenience (but preferably before REQUIRED: the next scheduled maintenance service). FIX NEXT Have the system affected inspected at the next scheduled maintenance service.

  • Page 22: Switches In The Center Console

    Check the oil level and top up if necessary. See page 143 LOW - FILL OIL* 2) OIL LEVEL Stop as soon as possible and switch off the engine, check the oil level and top up if necessary. See page LOW - STOP SAFELY*...
  • Page 23 R-models only: The Active Yaw Control function can be deactivated. See page 98 for more information. To help reduce the risk that the SC function is turned off inadvertently, the switch must be held in for at least half a second to disable this function.

  • Page 24: Steering Wheel Adjustment

    This 12 volt socket can be used to plug in certain accessories such as cellular telephones, etc. The ignition key must be in position 1 (or higher) for the auxiliary socket to function. NOTE: The auxiliary sockets can also be used for cigarette lighters, which are available at your Volvo retailer. Front/rear park assist (option/accessory) page 109 for more information on this function.

  • Page 25: Front Fog Lights

    1. Headlight/parking light switch 2. Front fog lights 3. Rear fog light 4. Instrument panel lighting 5. Fuel filler door unlock button Parking lights The front and rear parking lights can be turned on even when the ignition is switched off. Turn switch 1 to position .
  • Page 26 Instrument panel lighting The instrument panel lighting illuminates when the ignition key is in position II and the light switch (1) is in either position Move the thumb wheel (4) up to increase brightness or down to decrease brightness. Unlocking the fuel filler door Press button 5 when the car is at a standstill to unlock the fuel filler door.

  • Page 27: Manually Unlocking The Fuel Filler Door

    pg. 33 Instruments and controls Manually unlocking the fuel filler door at a speed of at least 5 mph (8 km/h), stop the car, and press the button again. See the information to the right on unlocking the fuel filler door manually. Manually unlocking the fuel filler door The electric motor that controls the fuel filler door locking mechanism is located on the inside of the rear fender on the passenger side of the car, just behind the fuel filler door.
  • Page 28 Exit the car and lock the doors. The headlights and parking lights will illuminate and remain on for 30 , 60 or 90 seconds. The time interval can be changed by an authorized Volvo retailer. 1. Factory setting pg. 35 Instruments and controls...
  • Page 29 frequently) or down (the wipers will sweep the windshield less frequently). Activating the rain sensor: 1. Turn the ignition key to at least position I and put the windshield wiper lever in position 0. 2. Press button 2. An LED in the button will light up to indicate that the rain sensor is active. Deactivating the rain sensor: Press button 2.
  • Page 30 Hazard warning flashers The four-way flasher should be used to indicate that the vehicle has become a traffic hazard. To activate the flashers, press the triangular button in the center dash. Press the button again to turn off the flashers. NOTE: Regulations regarding the use of the hazard warning flasher may vary, depending on where you live.

  • Page 31: Cruise Control

    Current speed in mph (Canadian models only) NOTE: Warning messages from the car's monitoring systems will override the trip computer function. If a warning message is displayed in the text window while you are using the trip computer, you must acknowledge the message by pressing button A.

  • Page 32: Instrument Panel

    Cruise control The cruise control panel is located on the left side of the steering wheel hub. Engaging cruise control Press the CRUISE button. CRUISE will be displayed in the information window in the instrument panel. NOTE: This does not set the vehicle's speed. Setting speed Press + or - to set the current speed.

  • Page 33: Parking Brake (Hand Brake)

    instrument panel. pg. 40 Instruments and controls Press the brake pedal. Press "resume" to return to the previously set speed. WARNING! Cruise control should not be used in heavy traffic or when driving on wet or slippery roads. Cruise control may not maintain set speed on steep downgrades.
  • Page 34 NOTE: The cover should be folded down when the auxiliary socket is not in use. Ashtrays Volvo cars in North America do not have an ashtray in the front seat as standard equipment. If you want to have an ashtray in the front seat, please contact your Volvo retailer.
  • Page 35 Cutout switch for rear windows Cutout switch for rear windows The electrically operated rear door windows can be disabled by a switch located on the driver's door (see illustration). If the LED in the switch is OFF: The rear door windows can be raised or lowered with the buttons on the rear door armrests or with the buttons on the driver's door armrest.
  • Page 36 Rearview mirror A Normal position B Night position, reduces glare from following headlights Autodim function (option) The autodim function reacts to headlights from following traffic and automatically reduces glare. NOTE: This function is automatically switched off when the gear selector is placed in the Reverse position. Electrically operated sideview mirrors The mirror control switches are located on the driver's door armrest.
  • Page 37 The sideview mirrors and side door windows can be treated with a water repellent coating. The optional laminated side windows always have this coating. The coating improves vision by causing the water to run off quickly. pg. 45 Instruments and controls Rearview mirror/sideview mirrors (contd) page 131 for information on cleaning this type of glass.
  • Page 38 B. Sliding moonroof Manual open: Pull the switch rearward to position 3 and hold it until the moonroof has opened to the position of your choice. Auto open: Pull the switch as far back as possible (position 4) and release it to automatically slide open the moonroof to the "comfort"* position.

  • Page 39: Climate Control

    Replace the cabin air filter with a new one at the recommended intervals. Please refer to your Warranty and Service Records Information booklet, or consult your Volvo retailer for these intervals. The filter should be replaced more often when driving under dirty and dusty conditions. The filter cannot be cleaned and therefore should always be replaced with a new one.

  • Page 40: Air Distribution

    Volvo service technician. Refrigerant Volvo cares about the environment. The air conditioning system in your car contains a CFC-free refrigerant - R134a(HFC134a). This substance will not deplete the ozone layer. The system contains 2.2 lbs (1000 g) R134a and uses PAG oil.
  • Page 41 Air vents in the door pillars A Open B Closed C Horizontal air flow D Vertical air flow Direct the outer air vents toward the side windows to defrost. In cold weather, close the air vents in the center of the dash to direct as much air as possible toward the windows. pg.
  • Page 42 Rear window and sideview mirror defrosters This function defrosts/de-ices the rear window and sideview mirrors. The LED in the switch will light up to indicate that the heating function is engaged. See page 37 for additional information on this function. Never use ice scrapers made of metal as they can easily scratch the mirror surface.
  • Page 43 The seat heating for the passenger seat should be switched off when the seat is not occupied. A/C - ON/OFF Press the switch to turn the air conditioning on or off. The "ON" or "OFF" LED will light up to indicate if the system is switched on or off.
  • Page 44 When the ECC system is in the AUTO mode, the green LED will be on Operation Press to operate the air quality sensor (normal setting). Select one of the following three functions by pressing 1, 2 or 3 times. 1. The AUT LED lights. The air quality sensor is now activated. 2.

  • Page 45: Front Seats

    2 0 0 6 VOLVO Interior pg. 57 Interior Front seats Interior lighting Floor mats Storage compartments Rear seat and trunk Spare wheel, tools and jack pg. 58 Interior Front seats Manually adjusted front seats 1. Front-rear adjustment: lift the bar and move the seat to the position of your choice.

  • Page 46: Glove Compartment

    pg. 59 Interior Folding the backrests in the front seat The front passenger seat backrest can be folded to a horizontal position to make room for a long load. Fold the backrest as follows: Move the seat as far back as possible. Adjust the backrest to the upright position.
  • Page 47 Passenger seat: The seat can only be adjusted if the ignition key is in position I, II or if the engine is running. Power seat control panel Seat adjustment If your Volvo is equipped with power seats, the following may be adjusted with the two switches at the side of the seat: A - Front edge of seat (raise/lower)

  • Page 48: Interior Lighting

    WARNING! Because the driver's seat can be adjusted with the ignition off, children should never be left unattended in the car. Movement of the seat can be STOPPED at any time by pressing any button on the power seat control panel. Do not adjust the seat while driving.
  • Page 49 You can disconnect the automatic function by pressing the courtesy light button for more than 3 seconds. Briefly pressing the courtesy light button again automatically reconnects the function. The courtesy light timer periods can be changed. Contact your Volvo retailer. Rear reading lights Reading lights - front/rear The reading lights can be switched on or off by pressing the respective buttons.
  • Page 50 Vanity mirror The light comes on when you open the cover. Floor mats Volvo offers floor mats specially manufactured for your car. They must be properly placed and secured in the mat clips. WARNING! An extra mat on the driver's floor can cause the accelerator pedal to catch. Check that the movement of the accelerator pedal is not impeded.

  • Page 51: Keys And Remote Controls

    2 0 0 6 VOLVO Locks and alarm pg. 71 Locks and alarm Keys Remote control Locking and unlocking Child safety lock Alarm pg. 72 Locks and alarm Keys and remote controls Keys Two types of keys are provided with your car; master keys and a service (valet) key. The master key, the remote control, and the central locking button may all be used to lock and unlock all of your car's locks.
  • Page 52 The car will start only with a properly coded key. Each key has a unique code, which your Volvo retailer uses if new keys are required. A maximum of six remote controls/keys can be programmed and used for one car.
  • Page 53 Using the remote control Button 1: Press to extend the key. This button must also be pressed when the key is folded back into the slot in the side of the remote control unit. Button 2(Lock): Press once to lock all doors, and the trunk. Button 3(Approach light): Press this button when approaching the car at night to light up the interior courtesy light, parking lights, license plate lights and the lights in the sideview mirrors.

  • Page 54: Locking And Unlocking

    3. Press the cover back into place. Ensure that the rubber seal is correctly positioned to help keep out moisture. Note: The old battery should be disposed of properly at a recycling center or at your Volvo retailer. pg. 75 Locks and alarm...
  • Page 55 Locking and unlocking the car from the inside The switch on the driver's door armrest can be used to lock or unlock all doors and the trunk, and to set the alarm. Opening/locking the trunk lid with the remote control Do as follows to unlock the trunk lid only: Press the "Open trunk"...

  • Page 56: Child Safety Lock

    Opening the trunk from the inside Opening the trunk from the inside (U.S. models only) The S60 is equipped with a florescent handle on the inside of the trunk lid, which can be used in an emergency situation to open the trunk from the inside. Pull the handle down to release the trunk lid. After use, the handle must be pushed back into its original position before the trunk can be closed.
  • Page 57 Control for child safety lock - right rear door WARNING! Remember, in the event of an accident, the rear seat passengers cannot open the doors from the inside with the buttons in position A. pg. 78 Locks and alarm Alarm Alarm The alarm is automatically armed whenever you lock your car.

  • Page 58: Text Window

    Audible alarm signal An audible alarm signal is given by a battery powered siren. One alarm cycle lasts for 25 seconds. "Panic" button In an emergency situation, this feature can be used to attract attention. Activate the "panic" button by pressing the red button on the remote control (see illustration on page 73) for at least 3 seconds or by pressing this button twice within 3 seconds.
  • Page 59 LED flashes rapidly before the ignition is switched on - the alarm has been triggered Fault in the alarm system: If a fault has been detected in the alarm system, a message will be displayed in the text window. Contact your Volvo retailer. Automatic re-lock/re-arm system If the car is unlocked with the remote, the car will re-lock and the alarm will re-arm after 2 minutes unless a door or the trunk has been opened.
  • Page 60 Fuel requirements Octane rating Volvo engines are designed for optimum performance on unleaded premium gasoline with an AKI octane rating of 91 or above. AKI (ANTI KNOCK INDEX) is an average of the Research Octane Number, RON, and the Motor Octane Number, MON.
  • Page 61 To meet seasonal air quality standards, some areas require the use of "oxygenated" fuel. Volvo allows the use of the following "oxygenated" fuels; however, the octane ratings listed on this page must still be met.
  • Page 62 Use of Additives With the exception of gas line antifreeze during winter months, do not add solvents, thickeners, or other store-bought additives to your car's fuel, cooling, or lubricating systems. Overuse may damage your engine, and some of these additives contain organically volatile chemicals. Do not needlessly expose yourself to these chemicals. WARNING! Never carry a cell phone that is switched on while refueling your vehicle.

  • Page 63: Starting The Car

    * If the fuel filler cap is not closed tightly or if the engine is running when the car is refueled, the Check Engine Light (malfunction indicator lamp) may indicate a fault. However, your vehicle's performance will not be affected. Use only Volvo original or approved fuel filler caps. pg. 85 Starting and driving...
  • Page 64 Selecting P or N when idling at a standstill for prolonged periods of time will help prevent overheating of the automatic transmission fluid. WARNING! Always place the gear selector in Park or in reverse on models with a manual transmission, and apply the parking brake before leaving the vehicle.
  • Page 65 Steering wheel lock The steering wheel lock might be under tension when the car is parked. Turn the steering wheel slightly to free the ignition key. In order to help reduce car theft, make sure the steering wheel lock is engaged before leaving the car. WARNING! Never switch off the ignition (turn the ignition key to position 0) or remove the key from the ignition switch while the car is in motion.

  • Page 66: General Information

    WARNING! Driving with the trunk open: Driving with the trunk open could lead to poisonous exhaust gases entering the passenger compartment. If the trunk must be kept open for any reason, proceed as follows - Close the windows - Set the ventilation system control to air flow to floor, windshield and side windows and blower control to its highest setting.
  • Page 67 5-speed manual transmission Depress the clutch pedal completely when changing gears*. Remove your foot from the clutch pedal while driving. The shift pattern should be followed. Overdrive (5th gear) should be used as often as possible to help improve fuel economy. * Clutch interlock The clutch must be fully depressed before you can start your car.

  • Page 68: Automatic Transmission (Option)

    Engaging reverse gear Never engage R while the car is moving. CAUTION: Be careful to avoid inadvertently engaging reverse while moving forward. pg. 90 Starting and driving Automatic transmission (option) Automatic transmission AW55- 50 (option) P Park Use this position when starting the engine or parking the car. Never use P while the car is in motion.
  • Page 69 The transmission will shift automatically between gears 3, 2 and 1 from this position. The transmission cannot shift up to fourth gear or (D)rive from third gear. L (Low gears) The transmission is locked in gears 1 and 2 when the selector is in this position. NOTE: Gears 4, 3, or L can be used if you are driving in a mountainous area, towing a trailer or to increase engine braking effect.

  • Page 70: Geartronic (Option)

    Kickdown can be used for maximum acceleration or when passing at highway speeds. Cold starts When driving before the engine has reached its normal operating temperature, the transmission will shift up at a slightly higher engine speeds to heat the three-way catalytic converter as quickly as possible. pg.
  • Page 71 Automatic transmission - shift gate positions You can move the gear selector freely between the (MAN)ual and (D)rive positions while driving. Depress the button on the front of the gear selector knob to move between the R, N, D, and P positions. pg.

  • Page 72: All Wheel Drive (Option)

    Tire dimensions Volvo recommends that you always drive on tires of the same brand, size, construction (radial), tread pattern, load-, speed-, traction-, temperature-, and treadwear rating. Never drive on mixed tires, except for brief periods when the temporary spare tire is in use.
  • Page 73 NOTE: The S60 R has a standard FOUR-C system consisting of Comfort, Sport, and Advanced sport modes. The buttons for controlling these driving modes are located in center instrument panel, above the ventilation system panel vents, see the illustration below. These buttons can be pressed at any time to change driving modes. An indicator light in the selected button will come on to indicate the driving mode that is currently selected.

  • Page 74: Brake System

    If the fluid level is below the MIN mark in the reservoir or if a "Brake failure - Service urgent" message is displayed in the text window: DO NOT DRIVE. Have the car towed to a Volvo retailer and have the brake system inspected.
  • Page 75 If the fluid level is below the MIN mark in the reservoir or if a "Brake failure - Service urgent" message is displayed in the text window: DO NOT DRIVE. Have the car towed to a Volvo retailer and have the brake system inspected.
  • Page 76 2 0 0 6 VOLVO Wheels and tires pg. 111 Wheels and tires General information Tire inflation pressure tables Tire Pressure Monitoring System (TPMS) - option on certain U.S. models only Changing tires Tire designations Glossary of tire terminology Vehicle loading...
  • Page 77 WARNING! - The wheel and tire sizes for your Volvo are specified to meet stringent stability and handling requirements. Unapproved wheel/ tire size combinations can negatively affect your vehicle's stability and handling. Approved tire sizes are shown in the Tire inflation pressure tables on page 116.
  • Page 78 Tire wear increases with speed. Correct front wheel alignment is very important. Unbalanced wheels impair tire economy and driving comfort. Tires must maintain the same direction of rotation throughout their lifetime. When replacing tires, the tires with the most tread should be mounted on the rear wheels to reduce the chance of oversteer during hard braking.

  • Page 79: Tire Inflation Pressure Tables

    116 Wheels and tires Tire inflation pressure tables Tire pressures recommended by Volvo for your vehicle. Refer to the tire inflation placard for information specific to the tires installed on your vehicle at the factory.

  • Page 80: Tire Pressure Monitoring System (Tpms) - Option On Certain U.s. Models Only

    a. These weights include the weight of all occupants of the car plus cargo. b. Self supporting run flat tires. See page 118 for more information. Optional tire pressure. These inflation pressures may only be used when the vehicle is not fully loaded. pg.

  • Page 81: Changing Tires

    The TPMS system uses a radio frequency of 315 MHz. Accessory electrical equipment using the same frequency could interfere with TPMS and should not be installed in the vehicle. Please consult your Volvo retailer, a qualified Volvo service technician, or the accessory equipment's supplier for further information.
  • Page 82 moving sensors back and forth between sets of wheels. CAUTION: When inflating tires with TPMS valves, press the pump's mouthpiece straight onto the valve to help avoid bending or otherwise damaging the valve. Self supporting run flat tires (option) Certain models equipped with the Tire Pressure Monitoring System (TPMS) can also be equipped with self supporting run flat tires.

  • Page 83: Glossary Of Tire Terminology

    The following information is listed on the tire sidewall: The tire designation (the following figures are examples of a tire designation): 1. 215: the width of the tire (in millimeters) from sidewall edge to sidewall edge. The larger the number, the wider the tire.

  • Page 84: Vehicle Loading

    This limit is set by the tire manufacturer. Recommended tire inflation pressure: inflation pressure, established by Volvo, which is based on the type of tires that are mounted on a vehicle at the factory. This inflation pressure is affected by the number of occupants in the car, the amount of cargo, and the speed at which the vehicle will be driven for a prolonged period.

  • Page 85: Uniform Tire Quality Grading

    A table listing important weight limits for your vehicle can be found on page 166. Steps for Determining Correct Load Limit (1) Locate the statement "the combined weight of occupants and cargo should never exceed XXX pounds'' on your vehicle's placard. (2) Determine the combined weight of the driver and passengers that will be riding in your vehicle.
  • Page 86 Snow chains can be used on your Volvo with the following restrictions: Snow chains should be installed on front wheels only. Use only Volvo approved snow chains. If accessory, aftermarket or "custom" tires and wheels are installed and are of a size different than the original tires and wheels, chains in some cases CANNOT be used.

  • Page 87: Temporary Spare

    Recommended tire pressure (see the placard on the B-pillar or on the fuel filler door) should be maintained irrespective of which position on the car the temporary spare tire is used on. In the event of damage to this tire, a new one can be purchased from your Volvo retailer. WARNING! Current legislation prohibits the use of the "Temporary Spare"...
  • Page 88 Insert flat end of lug wrench and turn/pull straight out Changing wheels The spare wheel is located under the carpet on the trunk floor. The jack and crank are secured in the wheel recess. There are two jack attachment points on each side of the car (see illustration on next page). To change a wheel: Engage the parking brake.
  • Page 89 Attaching the jack Position the jack correctly on the bar in the attachment (see illustration above) and crank while simultaneously guiding the base of the jack to the ground. The base of the jack must be flat on a level, firm, non-slippery surface. Before raising the car, check that the jack is still correctly positioned in the attachment.
  • Page 90 Block the wheels standing on the ground, use rigid wooden blocks or large stones. The jack should be kept well- greased. pg. 128 This page intentionally left blank. Contents Top of Page...

  • Page 91: Washing And Cleaning The Car

    2 0 0 6 VOLVO Car care pg. 129 Car care Washing and cleaning the car Paint touch up pg. 130 Car care Washing and cleaning the car The car should be washed at regular intervals since dirt, dust, insects and tar spots adhere to the paint and may cause damage.
  • Page 92 Do not polish or wax your car in direct sunlight (the surface of the car should not be warmer than 113° F (45° C). CAUTION: Volvo does not recommend the use of long life or durable paint protection coatings, some of which may claim to prevent pitting, fading, oxidation, etc. These coatings have not been tested by Volvo for compatibility with your vehicle's clear coat.
  • Page 93 Volvo also offers a special leather softener that should be applied after the cleaner and protectant. It leaves leather soft and smooth, and reduces friction between leather and other finishes in the vehicle.

  • Page 94: Paint Touch Up

    Paint repairs require special equipment and skill. Contact your Volvo retailer for any extensive damage. Minor scratches can be repaired by using Volvo touch-up paint. NOTE: When ordering touch-up paint from your Volvo retailer, use the paint code indicated on the model plate. The plate is located in the engine compartment.
  • Page 95 pg. 134 This page intentionally left blank. Contents Top of Page...

  • Page 96: Volvo Service

    The maintenance services contain several checks that require special instruments and tools and therefore must be performed by a qualified technician. Volvo advises you to follow the service program outlined in this booklet. To keep your Volvo in top condition, specify time-tested and proven Genuine Volvo Parts and Accessories.

  • Page 97: Maintaining Your Car

    Wipe driver information displays with a soft cloth. Visually inspect battery terminals for corrosion. Corrosion may indicate a loose terminal connector, or a battery near the end of its useful service life. Consult your Volvo retailer for additional information. As needed: Wash the car, including the undercarriage, to reduce wear that can be caused by a buildup of dirt, and corrosion that can be caused by salt residues.

  • Page 98: Emission Inspection Readiness

    OBD II system to "ready" for inspection. A half-hour trip of mixed stop- and-go/ highway driving is typically needed to allow OBD II to reach readiness. Your Volvo retailer can provide you with more information on planning a trip.
  • Page 99 Never try to repair any part of the SRS or SIPS bag systems yourself. Any interference in the system could cause malfunction and serious injury. Any work should only be performed by an authorized Volvo workshop. pg. 140 Maintenance and service Belt check Check the belt regularly to make sure it is in good condition and is clean.

  • Page 100: Hood And Engine Compartment

    NOTE: Do not top off with water only. This reduces the rust-protective and antifreeze qualities of the coolant and has a lower boiling point. It can also cause damage to the cooling system if it should freeze. Top off with Volvo Genuine Coolant/Antifreeze only (a 50/50 mix of water and antifreeze).

  • Page 101: Engine Oil

    Oil viscosity (stable ambient temperatures) Operation in hot climates When temperatures exceed 86° F (30° C) in your area, Volvo recommends, for the protection of your engine, that you use a heavier weight oil, such as SAE 10W/30. See the viscosity chart.
  • Page 102 Information booklet for information on the oil change intervals. NOTE: Volvo does not recommend the use of oil additives. Synthetic oil is not used when the oil is changed at the normal maintenance intervals except at owner request and at additional charge.
  • Page 103 ENGINE-->SEE MANUAL is displayed, stop safely as soon as possible and add oil (not more than 1.6 qts (1.5 liters). Check the oil level with the dipstick before restarting the engine. If no oil level is visible on the dipstick, do not start the engine. Have the car towed to an authorized Volvo workshop. pg. 144 Maintenance and service...
  • Page 104 NOTE: Do not top off with water only. This reduces the rust-protective and antifreeze qualities of the coolant and has a lower boiling point. It can also cause damage to the cooling system if it should freeze. Top off with Volvo Genuine Coolant/Antifreeze only (a 50/50 mix of water and antifreeze).
  • Page 105 Power steering fluid reservoir The fluid level should always be between the ADD and FULL marks. Fluid type: Volvo synthetic power steering fluid (Pentosin CHF 11S) P/N 1161529 or equivalent. Replace: No fluid change required NOTE: If a problem should occur in the power steering system or if the car has no electrical current and must be towed, it is still possible to steer the car.
  • Page 106 Label information 1 Vehicle Emission Control Information Your Volvo is designed to meet all applicable emission standards, as evidenced by the certification label on the underside of the hood. For further information regarding these regulations, please consult your Volvo retailer.

  • Page 107: Dimensions And Weights

    Your Volvo is designed to meet all applicable safety standards, as evidenced by the certification label on the facing side of the driver's door. For further information regarding these regulations, please consult your Volvo retailer. 7 Child safety latch label 8.
  • Page 108 Max. tongue weight: Trailer weights below 2,650 lbs (1,200 kg) 110 lbs (50 kg) Trailer weights above 2,650 lbs (1,200 kg) 165 lbs (75 kg) See also page 103 for additional information * When driving for prolonged periods at temperatures above 86°F (30°C), the maximum recommended weight is 2000 lbs (900 kg).

  • Page 109: Capacities

    169 Specifications Fluids Transmission Oil grade: Manual: MTF 97309 Automatic: AWD5: WS 3309 TF-80SC (S60R): JWS 3309 Different types of oil should never be mixed. Power steering Grade: Volvo synthetic power steering fluid (Pentosin CHF 11S) P/N 1161529 or equivalent.

  • Page 110: Cooling System

    Fluid type: DOT 4+ boiling point > 536°F (280° C) Cooling system Type Positive pressure, closed system. Coolant Volvo original coolant/antifreeze Volume 9.3 US qts (8.8 liters) The thermostat begins to open at 194°F (90° C). pg. 170 Specifications Three way catalytic converter Three-way catalytic converter cautions Keep your engine properly tuned.

  • Page 111: Electrical System

    SV5.5 WARNING! Bi-Xenon headlights (option) - due to the high voltage used by these headlights, these bulbs should only be replaced by an authorized Volvo service technician. pg. 173 Specifications Electrical system 12-volt system with voltage controlled generator. Single wire system in which the chassis and engine block are used as conductors, grounded on the chassis.

  • Page 112: Engine Specifications

    ** Automatic transmission: 350Nm at 32-100 rps, 258 ft. lbs at 1850-6000 rpm pg. 175 Specifications Volvo On Call Roadside Assistance Your new Volvo comes with a four year ON CALL roadside assistance. Additional information, features, and benefits are described in a separate information package in your glove compartment.
  • Page 113 1-800-263-0475 Technician certification In addition to Volvo factory training, Volvo supports certification by the National Institute for Automotive Service Excellence (A.S.E.). Certified technicians have demonstrated a high degree of competence in specific areas. Besides passing exams, each technician must also have worked in the field for two or more years before a certificate is issued.
  • Page 114 Features: AM/FM radio, integrated 6-disc CD changer, 4x50W or 4x70W output plus 25W Dolby Pro Logic II, eleven speakers. A subwoofer mounted under the floor in the cargo area is available as an option. Consult your Volvo retailer. Compact disc care Keep the discs clean.
  • Page 115 Never attempt to play a disc which is damaged in any way. When not in use, the discs should be stored in their covers. Avoid storing discs in excessive heat, direct sunlight or dusty locations. pg. 179 Audio Audio system HU-650 - overview 1.
  • Page 116 1. On/off - press Volume - turn 2. Buttons for selecting stored radio stations/discs in optional CD changer 3. Bass (press to release control and turn to adjust) 4. Treble (press to release control and turn to adjust) 5. Balance (left/right) - press to release control and turn to adjust 6.
  • Page 117 Volume control - ALARM If a CD is playing when the radio receives an alarm bulletin (available in certain areas only), the CD player enters pause mode. The bulletin is broadcast at the volume selected for this type of message. After the bulletin has been completed, the audio system reverts to the originally selected sound.
  • Page 118 Selecting a sound source The sound source (e.g. AM, FM, etc.) can be selected in two ways: Use the sound source buttons (see the center illustration above). Turn the SOURCE knob (see illustration above) to select a sound source (AM1, AM2, FM1, FM2, FM3, or CD). Press the knob to select the AM or FM band of your choice.
  • Page 119 Storing stations To store a selected station under one of the station setting buttons 1-6: 1. Tune to the desired station. 2. Press the button under which the station is to be stored and keep it depressed. The audio system sound will be interrupted for a few seconds and STORED will appear in the display.
  • Page 120 The RBDS or Radio Broadcast Data System operates in the FM band only, and the information transmitted is supplied exclusively by participating broadcasters. Volvo has no control over the accuracy of the data or information. Coverage by local broadcasters may be limited at this time, but as the technology and benefits grow, you will find the radio in your car is equipped to take advantage of this system.
  • Page 121 PTY OFF News NEWS Current affairs AFFAIRS Information INFO Sports SPORT Education EDUCATION Drama DRAMA Art and culture CULTURE Science SCIENCE Entertainment VARIED Pop music POP M Rock music ROCK M Easy listening EASY M Light classics LIGHT M Classical music CLASSICS Other music OTHER M...
  • Page 122 2 0 0 6 VOLVO Index pg. 197 Index A/C (air conditioning) Adjustable steering wheel Air distribution Air quality sensor Air vents Alarm All Wheel Drive All Wheel Drive - towing Anti-lock Brake System (ABS) Ashtray Audio AUTO (climate control)
  • Page 123 Capacities Capacity weight Carbon Monoxide - Important Warning Catalytic converter Ceiling lighting Central locking system - remote control Changing coolant Changing wheels Check Engine warning light Child restraint anchorages Child safety locks Child seat anchors Cigarette lighter Climate control systems -general information Clock Coat hanger Cold weather precautions...
  • Page 124 Engine specifications Environment Federal Clean Air Act FIX NEXT SERVICE Floor mats Fluids Fog light Fog light, rear Front fog light, changing Front park assist Front seat - backrest Front seats Front seats - heated Front seats - manual adjustment Front seats - power Front suspension Fuel...
  • Page 125 High beam headlights High beam indicator Hoisting the car Home safe lighting HomeLink® Universal Transceiver Hood - opening Ignition switch Immobilizer (start inhibitor) Indicator and warning symbols 24 , 25 Inflation pressure tables Inflation pressure, checking Inspection, preparing for Instrument panel Integrated booster cushion Interior Interior lighting...
  • Page 126 Moonroof Multifilter with air quality sensor Occupant safety Occupant Weight Sensor Octane rating Odometer Oil pressure Oil quality Opening the trunk from the inside Opening/locking the trunk Owner maintenance P Park Paint - color code Park assist Parking brake Parking light bulb, changing Periodic owner-performed maintenance Permissible axle weight Polishing...

  • Page 127: Speedometer

    Reporting safety defects Roadholding Roof racks (load carriers) Run flat tires Safety Safety defects - reporting Seat belt Seat belt reminder SEE MANUAL Self supporting run flat tires Service Service key Service reminder SERVICE REQUIRED SERVICE URGENT Shiftlock Side marker lamp Side marker light, changing Ski hatch Snow chains...
  • Page 128 Temperature control Temperature gauge Text window - messages TIME FOR REGULAR SERVICE Tire designations Tires economy - improving Tires inflation Tire inflation pressure tables Tire inflation pressure, checking Tire pressure monitoring system Tire Pressure Monitoring System (TPMS) Tire terminology, glossary of Tires - tread wear indicators Towing - cars with All Wheel Drive Towing a trailer...
  • Page 129 Vehicle weights VIN (Vehicle Identification Number) Volvo and the environment W - Winter Warning symbol in center of dashboard Warranties Washer fluid reservoir Washing the car Waxing Weight distribution Weights Windshield washer fluid reservoir Windshield wipers Winter/Wet driving mode Contents...
  • Page 130 When used properly and safely, they enrich the driving experience. Improperly used, any of these could cause a distraction. For all of these systems, we want to provide the following warning that reflects the strong Volvo concern for your safety: Never use these devices or any feature of your vehicle in a way that distracts you from the task of driving safely.
  • Page 131 The following should be checked regularly: * 1 Washer fluid reservoir should be filled with water and solvent (wintertime: windshield washer anti-freeze). See page 144. 2 Power steering- When cold, the level must not be above the COLD mark and when hot it must not be above the HOT mark.
  • Page 132 Direction indicator/parking light Low beam High beam Fog light (option) *H3 on R-models Fog light Tail/parking light Brake light Side marker light Direction indicator Backup light pages 149-155 for more information on replacing bulbs. Contents Top of Page...

Table of Contents

Save PDF
