ICP DAS USA M-7000 series Quick Start Manual

M-7000 series
Digital Input/Output Data Acquisition Module,
Communicable over RS-485, Modbus RTU protocol
Quick Start Guide
Product Website:
http://www.icpdas-usa.com/m7000_analog_digital.php
http://www.icpdas-usa.com/dcon_utility_pro.html
Introduction
The M-7000 series is a family of network data acquisition and control modules,
providing analog-to-digital, digital-to-analog, digital input/output, timer/counter and other
functions. The modules can be remotely controlled using a set of commands, which we
call the DCON protocol. Communication between the module and the host is in ASCII
format via an RS-485 bidirectional serial bus standard. Baud Rates are software
programmable and transmission speeds of up to 115.2 Kbps can be selected.
The functionality of the M-7000 series is the same as I- 7000 series, with the exception
that the M-7000 series offers extended support for the Modbus RTU protocol.
The M-7000 DIO modules support TTL signal, photo-isolated digital input, AC voltage
digital input, relay contact output, solid-state relay output, photoMOS output and open-
collector output.
1. Downloading DCON Utility Pro
1. The required installation file for windows can be downloaded from:
http://www.icpdas-usa.com/software/dcon-utility-pro-windows.zip
More information related to about version numbers and the latest supported
modules can be obtained from
http://www.icpdas-usa.com/dcon_utility_pro.html
M-7000 DIO DAQ Module - QuickStart (Feb/2016)
