- Page 1 （ ） MSI PC54AG MS-6845 Wireless 11a/b/g PCI Card User’s Guide...
-
Page 2: Fcc Caution
FCC Caution 1. The device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. -
Page 3: Important Safety Precautions
Important Safety Precautions Always read and follow these basic safety precautions carefully when handling any piece of electronic component. 1. Keep this User’s Manual for future reference. 2. Keep this equipment away from humidity. 3. Lay this equipment on a reliable flat surface before setting it up. 4. - Page 5 54, 48, 36, 24, 18, 12, 9, 6 Mbps (IEEE802.11a), 54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, 1 Mbps (IEEE802.11g), or 11, 5.5, 2, 1 Mbps (IEEE802.11b). With PC54AG (MS-6845), you can roam between conference room and office without being disconnected the LAN cables; in addition, sharing files and printers can be easy tasks.
- Page 6 Wireless 11a/b/g PCI Card PC54AGUser’s Guide >>> 1.2 How PC54AG Works Ad-hoc Mode : An Ad-hoc network is a local area network, especially one with wireless or temporary plug-in connections. Therefore, some of the network devices are part of the network only for the duration of a communications session.
- Page 7 Internet, email, file transfer, and printer sharing. The scale and range of the Infrastructure networking are larger and wider than that of the Ad-hoc networking. Access Point PC54AG Wireless 11a/b/g PCI Card...
-
Page 8: Specifications
Wireless 11a/b/g PCI Card PC54AGUser’s Guide >>> 1.3 Specifications General Microsoft ® Windows ® 98 SE/ Operating system 2000/XP - IEEE802.11a/b/g Compliance - WECA Wi-Fi - WHQL (Windows 2000/XP) Operating Temperature0 ~ 50 Operating Humidity 10 ~ 90%, non-condensing Physical 32-bit PCI v2.2 Form Factor Dimensions (WxDxH)122 X 64 X 19 mm... - Page 9 Wireless 11a/b/g PCI Card PC54AGUser’s Guide IEEE802.11b (Auto-Fallback) Data Rate and - CCK @ 5.5 and 11Mbps Modulation Types - DQPSK @ 2Mbps - DBPSK @ 1Mbps IEEE802.11g (Auto-Fallback) - OFDM @ 54/48/36/24/18/12/ 9/6Mbp - CCK @ 5.5 and 11Mbps - DQPSK @ 2Mbps - DBPSK @ 1Mbps IEEE802.11a (Auto-Fallback)
-
Page 10: System Requirements
Wireless 11a/b/g PCI Card PC54AGUser’s Guide >>> 1.4 System Requirements Before installing the PC54AG (MS-6845), your PC should meet the following: Desktop PC with standard PCI slot. Windows ® 98SE/ME/2000/XP operating system. Minimum 5MB free disk space for installing the driver and utilities. -
Page 11: Product View
>>> 1.6 Product View Golden Finger ACT LED - GREEN, indicating the Antenna networking status by: ON - The PC54AG (MS-6845) is connected. Flash - The PC54AG (MS-6845) is searching for available Access Point or receiving/ transmitting data over the wireless network. -
Page 12: Hardware Installation
NOTE: Turn off your system and disconnect the power cable before installing the PC54AG (MS-6845). Step 2. Put the PC54AG (MS-6845) directly over the PCI slot and press it into the slot firmly. Do not hold the PC54AG (MS-6845) on the golden finger while installing;... - Page 13 Wireless 11a/b/g PCI Card PC54AGUser’s Guide Step 3. Put the antenna through hole of the removed bracket. Step 4. Screw up the PCI card on the PC. Step 5. Install the antenna. Step 6. Adjust the direction of the antenna for better signal receiving.
