MP54G5 (MS-6833B)
Wireless 11g MiniPCI Card
User's Guide
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MP54G5 (MS-6833B) and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MSI MP54G5 (MS-6833B)

  • Page 1 MP54G5 (MS-6833B) Wireless 11g MiniPCI Card User’s Guide...
  • Page 2: Fcc Caution

    FCC Caution 1. The device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 3: Important Safety Precautions

    Manual Information for End Users The end user must not have manual instructions to remove or install device. The user manual for end users must include the following information in a prominent location: “IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located operating in conjunction with any other antenna or transmitter.”...
  • Page 4 Introduction >>> 1.1 MP54G5 (MS-6833B) - MiniPCI Card MSI MP54G5, the Wireless 11g miniPCI Card, is a Type IIIB card, which can be used to integrate with such systems as notebook, mini-barebone and portable PC. With MSI MP54G5 embedded inside, a system could provide users with the ability and flexibility to connect up to Internet wirelessly via 802.11g...
  • Page 5 >>> 1.2 How MP54G5 Works 1.2.1 In WLAN Environment Ad-hoc Mode : An Ad-hoc network is a local area network or other small network, especially one with wireless or temporary plug-in connections, in which some of the network devices are part of the network only for the duration of a communications session.
  • Page 6 Infrastructure Mode : The difference between Infrastructure network and Ad-hoc network is that the former one includes an Access Point. In an Infrastructure network, the Access Point can manage the bandwidth to maximize bandwidth utilization. Addi- tionally, the Access Point enables users on a wireless LAN to access an existing wired network, allowing wireless users to take advantage of the wired networks resources, such as Internet, email, file transfer, and printer sharing.
  • Page 7: Specifications

    >>> 1.3 Specifications Hardware Form Factor 32-bit Type IIIB Specification Operation voltage 3.3V Antenna Connector Two antenna connectors Operating System Microsoft ® Windows ® 98SE/ME/2000 Environmental - Operating Temperature: 0 ~ 55 - Operating Humidity: 10 ~ 90%, non-condensing Dimensions (WxDxH) 59.75 x 44.6 x 3.5mm Network Standard IEEE 802.11;...
  • Page 8 Channel IEEE 802.11g: Ch. 1-11 – N. America Ch. 1-13 – Japan Ch. 1-13– Europe ETSI Ch. 10-11 – Spain Ch. 10-13 – France IEEE 802.11b: Ch. 1-11 – N. America Ch. 1-13 – Japan Ch. 1-13– Europe ETSI Ch. 10-11 – Spain Ch.
  • Page 9: System Requirements

    >>> 1.4 System Requirements Before installing MP54G5, your PC should meet the following items: - One desktop/notebook PC with an available MiniPCI slot. - Windows ® 98SE/ME/2000/XP operating system. - Minimum 5MB free disk space for installing the driver and utilities.
  • Page 10 >>> 1.6 Product View WLAN 11g antenna connectors Connect to external antennas for enhanced data transmission and reception. The external antennas are well designed on the desktop or note- book computers. Golden Finger...
  • Page 11: Hardware Installation

    Hardware Installation The following diagrams provide you a basic installation for your MP54G5. The instruction below is suitable for most computers with MiniPCI slot. For more information about the MiniPCI module, please refer to your computer’s manual. Installing MP54G5: Locate the MiniPCI slot on the mainboard.Place your MP54G5 over the MiniPCI slot (at an angle of 30 degrees).
  • Page 12: Software Installation

    Software Installation This chapter describes the procedures of installing the driver and utility. Follow the instruction step by step to finish the installation. If you use Windows ® 98SE/ME, please prepare the Windows ® Setup CD at hand before installing the driver; because the system will ask you to insert the Setup CD to copy files during the installation.
  • Page 13 Insert the software CD into your CD-ROM drive, and the Setup ST EP program should launch automatically. If the Autorun program doesn’t launch automatically, click Start E:\setup.exe at the taskbar and select Run..Type (where your CD-drive) in the Open box and click OK to launch the Setup program manually.
