  • Page 1 APOLLO MEDICAL APOLLO MEDICAL F MEDICAL 1000 T ELECTRONIC WALL MOUNTED FAUCET INSTALLAT ION AND MAIN TENA NCE GU I DE...
  • Page 2: Table Of Contents

    SERVICE CHECK LIST The information in this document reflects products at the date of printing. Stern Engineering Ltd reserves the right, subject to all applicable laws, at any time, at its sole discre- tion, and without notice, to discontinue or change the features, designs, materials and other specifications of its products, and to either permanently or temporarily withdraw any of the forgoing from the market.
  • Page 3: Technical Data

    TECHNICAL DATA G-3/4” G-3/4” G-3/4” G-3/4” APOLLO MEDICAL B APOLLO MEDICAL E 314500 314510 G-3/4” G-3/4” G-3/4” G-3/4” APOLLO MEDICAL FB 314530 APOLLO MEDICAL FE 314540 G-3/4” G-3/4” MEDICAL 1000 TE 314600 Internally mounted 9V battery or 9V Power supply...
  • Page 4 PACK CONTENTS APOLLO MEDICAL B / E Familiarize yourself with the part names and confirm that the parts are included. 1 x Faucet body 1 x Spout 1 x 2 mm Allen key 1 x 2.5 mm Allen key 2 x Eccentric unions...
  • Page 5 PACK CONTENTS APOLLO MEDICAL FB / FE Familiarize yourself with the part names and confirm that the parts are included. 1 x Spout 1 x Faucet body 1 x 2 mm Allen key 1 x 2.5 mm Allen key 2 x Eccentric unions...
  • Page 6 PACK CONTENTS MEDICAL 1000TE Familiarize yourself with the part names and confirm that the parts are included. 1 x Faucet body 1 x Spout 1 x 2 mm Allen key 2 x Fixation accessories (rosettes) 1 x 2.5 mm Allen key 2 x Eccentric unions...
  • Page 7: Pre-Installation Info

    PRE-INSTALLATION INFO Check contents Separate all parts from the packaging and check each part with the “Pack contents” section. Pay attention to the different models variations. Make sure all parts are accounted for before discarding any packaging material. If any parts are missing, do not attempt to install your electronic faucet until you obtain the missing parts.
  • Page 8 FAUCET INSTALLATION STEP 1 – INSTALLING THE FAUCET Shut off the water supply. NOTE: The standard distance between the water supply pipes centers is 150 mm. Two eccentric unions are provided to allow variations from 130mm to 170mm. Mount the eccentric unions on the water supply pipes.
  • Page 9 FAUCET INSTALLATION Proceed to mounting the faucet on the eccentric unions. Tighten the nuts carefully with a 30mm wrench. Mount the spout to its location in the faucet body, and tighten the Allen screw/s using the Allen key provided in the packaging. STEP 2 –...
  • Page 10: Adjusting The Water Temperature

    ADJUSTING THE WATER TEMPERATURE The faucet has been factory calibrated to 38°C under ideal installation conditions. Due to variations in site conditions, the mixed water temperature may need adjustments to match the site conditions and make sure that it is safe. Unscrew the regulation knob screw and remove the regulation knob.
  • Page 11 SETTINGS ADJUSTMENT DETECTION DELAY OUT TIME RANGE TEMPORARY OFF DELAY IN TIME FUNCTION SECURITY TIME RESET HYGIENE FLUSH ADJUSTING THE SETTINGS WITH THE REMOTE CONTROL If necessary, the sensor settings can be adjusted as following: Shut off the water supply. In order to adjust the sensor with the remote control, hold the remote control straight in front of the sensor in a distance of about 6-8”...
  • Page 12 SETTINGS ADJUSTMENT NOTE: Once you have changed the detection range with the remote control, this distance will be remembered by the sensor, even if the power source is disconnected. SECURITY TIME: The Security time prevents continuous running of water due to reflections or vandalism. By default, if the sensor is covered for more than 90 seconds the water flow will shut automatically.
  • Page 13 BATTERY REPLACEMENT LOW BATTERY INDICATOR The product has an advanced battery level management system consisting of 2 steps. In the first step, the battery still has enough power to open and close the solenoid valve and allows the solenoid valve to open. In the second step the battery might not have enough power to open and close the solenoid valve.
  • Page 14 BATTERY REPLACEMENT Replace the used battery with a new 9V battery (a Lithium battery is recommended), and NEW BATTERY connect the connector between the battery and the electronic unit. Put the battery protection cover NEW BATTERY back on. COVER Place the cap back into place and tighten the Allen screw.
  • Page 15: Maintenance

    MAINTENANCE FILTER CLEANING INSTRUCTIONS The system is provided with two stainless steel filters preventing foreign particles to enter the lines. It is recommended to clean the filters every six (6) months. If the water flow has decreased, this may be because the filters are clogged. The filters can be cleaned as follows: 1.
  • Page 16 07210075 Sensor Kit battery Version 10-Pack 07220277 Sensor Kit transformer version 10-Pack 07220304 Thermostatic Cartridge Kit 07240021 Thermostatic Handle 07110018 Stern Interoperable solenoid valve 10-Pack 07230049 Adapter for Handle 07055067 Nut for Thermostat 07055070 Spout 07015035 Cover kit battery version...
  • Page 17 SPARE PARTS LIST MEDICAL 1000TE Seals and Screws Kit 07210159 Sensor Kit 10-Pack 07220305 Thermostatic Cartridge Kit 07240021 Thermostatic Handle 07110018 Stern Interoperable solenoid valve 10-Pack 07230049 Adapter for Handle 07055067 Nut for Thermostat 07055070 Spout kit 07271024 Cover kit 07270079...
  • Page 18: Warranty

    If a defect is found in normal use, Y. Stern Engineering Ltd. will, at its discretion, repair, provide a replacement part or product, or make appropriate adjustments.
  • Page 19: Service Check List

    SERVICE CHECK LIST PROBLEM INDICATOR CAUSE SOLUTION No water 1.Sensor flashes coming out continuously of the faucet: when user’s Low battery. Replace battery hands are within the sensor’s range. 2. Red light in 1. Range is too short. Increase the range the sensor does not flash once 2.
  • Page 20 15 Gan Rave Blvd., 81222 Gan Rave, Yavne, Israel Tel: 972-8-9326000, Fax: 972-8-9326025, export@sternfaucets.com www.sternfaucets.com 05.15 015314500-B...
