Heath Zenith SL-6005 User Manual

Model SL-6005
• Eight selectable channels available, so multiple remotes can be used in the
same home.
• Car visor clip included for convenience.
Car Visor Clip
Channel 1, DIM
Channel 1, ON
Channel 1, OFF
Remote Control
Eight selectable channels allow the user to operate several
systems at different locations in your home. If purchasing
more than one wireless control system, select different
operating channels for each system or they will interact with
each other.
1. Install alkaline 12-volt remote battery (A23 type).
Remove cover from back of transmitter by pressing on
it with your thumb and sliding it off as shown in Figure
1. Using outline of battery chamber as a guide, align
battery with chamber and insert battery into remote.
Slide cover back onto transmitter.
2. Remote Control Functions.
Channel 1/2 ON: Turns ON any devices set to the same
channel as this remote control.
Channel 1/2 OFF: Turns OFF any devices set to the
same channel as this remote control.
Channel 1/2 DIM: Activates the DIM feature for any devices used with this
remote control that have the DIM feature built-in.
© 2001 DESA International

Features

LED Indicator Light
Channel 2, DIM
Channel 2,ON
Channel 2, OFF

Operation

Wireless 6-Button
Remote Control
12-Volt (A23 Type)
Battery (Included)
Positive
Terminal
Jumpers
ON
1 2 3 4
Battery
Battery Cover
Figure 1
598-1116-00
