Monoprice Adjustable Tilt/Swivel Flat Panel Wall Mount
Model MLB-13/MLB-17
(PID# 3610/3611/4114/4116)
VESA Compliant: Up to 750x450 for MLB-13 and 450x250 for MLB-17
Max Weight: 165lbs
Carefully open the carton, remove the contents and lay them out on cardboard or other protective surface to avoid
damage.
Check the contents against the supplied parts list on the next page to assure that all components were received
undamaged. Do not use any damaged or defective parts.
Install and use this device with care. Please read this entire manual before attempting installation and carefully follow all
instructions contained herein. Use proper safety equipment during installation.
Please call a qualified installation contractor for help if you:
Don't understand the instructions in this manual or have any doubts about the safety of the installation.
You are uncertain about the nature of your wall.
Do not use this product for any purpose or in any configuration not explicitly specified in these instructions. Monoprice
hereby disclaims any and all liability for injury or damage arising from incorrect assembly, incorrect mounting or any
incorrect use of this product.
WARNING

Tools Required

Note: The mounting components and hardware supplied in this package are not designed for installation to wall with
steel studs or to cinder block walls. If the hardware you need for your installation is not included, please consult your local
hardware store for proper mounting hardware for this application.
Installation Instruction

UNPACKING INSTRUCTIONS

IMPORTANT SAFETY INFORMATION

This TV mount must be securely attached to the vertical wall. If the mount
is not properly installed it may fall, resulting in possible injury and/or
damage.
3/16" Drill Bit
Phillips Screwdriver
CAUTION!
1/2" Masonry Bit
Stud Finder
Wrench or Socket Set
Carpenter's Level

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MLB-13 and is the answer not in the manual?

Questions and answers

Summary of Contents for Monoprice MLB-13

  • Page 1 You are uncertain about the nature of your wall. Do not use this product for any purpose or in any configuration not explicitly specified in these instructions. Monoprice hereby disclaims any and all liability for injury or damage arising from incorrect assembly, incorrect mounting or any incorrect use of this product.
  • Page 2 (4) M5x14mm Screw-d (4) M6x14mm Screw-e (4) M8x20mm Screw-f (4) M6x30mm Screw-g (4) Washer-i (8) small spacer-j (4) big spacer-k (4) M8x30mm Screw-h (6) Concrete Anchor - m (6)8mm Lag Bolt-l (6) D8 Washer-n Step 1 Mounting the Wall Plate to the Wall Brick, Solid Concrete and Concrete Block Mounting: Use the Wall Plate (part a) as a template to mark 6 hole locations on the wall.
  • Page 3 Step 3 Hang the TV onto the Wall Plate Warning: Some TVs may require two people to lift! Monoprice is not responsible for personal injury or product damage. First hook the Monitor Bracket (parts b & c) over the top of the wall plate (part a). Then, let the bottom of the monitor brackets rotated to the bottom of the wall plate as shown in Diagram 3-A.
