KING KCV SERIES Installation Instructions

DANGER
ELECTRIC SHOCK OR FIRE HAZARD
Read all wire sizing, voltage
requirements and safety data
to avoid personal injury and
property damage.
It is extremely important to verify the electrical power supply is the same voltage as the heater being
installed. 240 and 120 Volt heaters are not interchangeable. Powering a 240 Volt unit with 120 Volt supply
wires will reduce heater output by approximately 75%. Powering a 120 Volt unit with 240 Volt supply
wires will destroy the heater and voids all guarantees and warranties.
CAUTION: Turn off power source supplying heater before attempting any installation, maintenance
or repairs. Lock or tag circuit breaker/fuse panel door. Failure to do so could result in serious
electrical shock, burns or possible death.
WARNINGS: To insure proper operation of this heater it should be a minimum of 6 feet above the
fl oor and no closer than 2½" below drywall ceiling (6" vinyl or drop ceilings). Draperies should clear
the front and top of this heater by 6". Draperies hung below the heater should have a 2½" clearance.
Do not block the heater in any manner. Never paint the heater.
Following the guidelines herein listed will result in a maintenance-free heater. There are no moving parts or motors to
maintain. Periodic dusting of the front panel is all that is suggested.
The KCV Cove Heater carries a one (1) year warranty from date of installation. Please refer to the manufacturer's war-
ranty statement for further information.
Sectional heaters are completely assembled and pre-wired. To prepare the heater for installation, carefully check the volt-
age to be used is the same as stated on the rating nameplate. Operating voltage can not exceed 5% of nameplate voltage.
Operating heater above listed voltage ratings voids all guarantees and warranties.
