iPECS LIP-9071 User Manual

LIP-9071 Button Layout
1. 7" Touchscreen 2.
5.
6.
7.
8.
9.
15. Soft keys
16.

Touch

Home screen display
Telephone icon from home screen

Dealing with calls

Incoming calls
External calls
Internal calls
Placing a call on hold
Rejecting a call
3. Ring LED
Camera
4.
10.
11.
12.
13.
14.
Volume
17. Speakerphone
The home button will display icons on the right handside,
messaging, a telephone icon which once pressed will direct
you to call options, contacts, call log and apps. This is the
default view, until an icon is pressed. To return to the default
screen, press the home key.
To make a call press the speakerphone button or to reach the
full feature set press the telephone icon from the default home
screen. This guide is based upon the display after you have
pressed the telephone icon from the default home display.
To answer the call, lift the handset or press the speakerphone button.
LIP-9071 has a "'live dial pad' which means you do not need to lift the handset or press the
Speakerphone button to start a call. To place a call, dial the desired number. Outgoing calls can
also be placed from the contacts, logs as well as speed dial.
press Hold button, the button will light to indicate there is a held call.
Press the DND button when a call comes in.
Button Guide
1.
Touchscreen: displays features such as extension numbers.
NFC tagging
video call, recent calls, and applications.
2.
Camera: built-in HD camera used to take photos and for use
during video calls.
3.
Ring LED: Flashing light indicates phone ringing and
voicemails.
4.
NFC
Communications touch point.
5.
Home: return to the Home screen.
6.
Menu: access the settings for your phone, such as changing
7.
Back: return to the previous screen.
8.
ECO:
9.
Transfer: used to transfer a call to another destination.
10.
DND (Do-Not-Disturb): blocks incoming calls. You can also
activate Do-Not-Disturb while the phone is ringing - this
terminates the call and the caller will get a fast busy tone.
11.
Message: access your voicemail box.
12.
Hold: place a call on hold – dependent on PBX set up, the
caller will receive on-hold music.
13.
Headset: if a headset is plugged in this button allows you to
toggle between the headset and handset.
14.
Mute: mute the call so that the caller cannot hear your voice.
15.
Soft keys: Soft keys are interactive, changing function based
on the phones status.
18.
16.
Volume control: adjust the Ring, Headset, Handset, and
Speaker volume.
Microphone
17.
Speakerphone:
(speaker
a call. The button will automatically illuminate when the phone
phone)
is in menu mode.
18.
Microphone: Use to receive speech during handsfree call.
tagging: tap your phone on
y assigned to the contact.
the Near Field
