Simplicity ZT4000 Parts Manual page 5

Main Frame & Front Suspension Group
REF NO. PART NO.
1 5021072SM
2 5025303SM
3 5025057SM
4 5025165SM
5 5025156SM
6 5025013X14SM
7 5025394SM
8 5025013X32SM
9 5025265X52SM
10 5025160SM
11 5025284SM
12 5023483SM
13 5402539CSM
14 5020884SM
15 5402536CSM
16 5047489SM
17 5022852SM
18 5100358SM
19 5100882SM
20 5100930SM
21 5403394CSM
22 5025449SM
23 5025448SM
24 5020883SM
25 5025457SM
Footnotes
The above parts group applies to the following Mfg. Nos.:
5900707 - ZT4000B24
5900765 - ZT4000B26
Briggs and Stratton Yard Power Products Group
Copyright © 2009 by Briggs and Stratton Corporation
Milwaukee, WI, USA. All rights reserved
QTY. DESCRIPTION
2 SEAL, GREASE
4 SCREW, 5/16-18 X 1 FLAT HD SC
4 NUT, 5/16-18 HEX NYLON LOCK
6 WASHER, 3/8 FENDER
4 WASHER, 3/8 SAE
2 BOLT, 3/8-16 X 1-3/4 GD5
4 NUT, 3/8-16 HEX NYLOCK FLANGE
2 BOLT, 3/8-16 X 4 GD5 YZ
1 BOLT, 3/4-16 X 6-1/2 YZ GD5
4 WASHER, 3/4" SAE
1 NUT, 3/4-16 HEX NYLON LOCK
2 SHOCK, SPRING ASSEMBLY
2 WELD, CASTER YOKE, IS500Z - ORG
4 BEARING, TAPERED ROLLER, 1"
1 WELD, FRONT PIVOT, CITATION - ORG
1 SPACER, .75 X 1.00 X 2.38
1 PIVOT BEARING, 1.00" X 1.125" OD X 1.50"
1 PIVOT BEARING, 1.00 X 1.125 OD X .50
2 CAP, CASTER SPINDLE, LOW PROFILE
2 PAD, FRICTION, .375 X 1.25 X 4.00
1 WELD, IS500 MAIN FRAME - ORG
4 WASHER, BELLEVILLE - 1.500 X .755
2 NUT, 3/4-16, HEX JAM NYLON LOCK
4 BEARING CUP
2 BOLT, 1/4-28 X 1/2, GD5 YZ
5
TP 400-7340-M-50-S
