TechLogix Networx SSF Single Mode Light Source Manual page 8

1
2
Wavelength: (nm)
nm
1
1310/1550: Single mode fiber testing
850/1300: Multimode fiber testing
Battery Indicator: displays when battery power in
2
use. The capacity shown will decrease with battery
power. Replace batteries as needed.
Auto Shut-off: The light source will automatically
shut off when idle for ten minutes. Press power
3
button
or off.
Frequency: (KHz)
KHz
4
0.27, 1.00, or 2.00 KHz. Dashed line indicates
Continuous Wave Mode (CW)
dBm
5
Output Power: (dBm)
Handheld Optical Light Source
3
( ) quickly to turn Auto-Off function on
4
8
5
(SSF-LS100SM)
(SSF-LS100MM)
