Functions - TechLogix Networx SSF Single Mode Light Source Manual

Handheld Optical Light Source
1
2
Label Area: Light Source will read SM (Single Mode)
SM/
or MM (Multimode) depending on model. Choose
1
MM
SM for single mode testing (1310/1550nm) or MM
for multimode testing (850/1300nm).
Power On/Off: Press and hold for 1 second to turn
the unit on or off.
Auto Shut-Off Selection: While unit is on, press this
2
key quickly to turn the auto shut-off function on or
off. When auto shut-off is active the unit will auto-
matically shut off after ten minutes idle.
Wavelength Selection:
3
the wavelength, shown in top left corner of screen.
Modulation
between continuous and modulated light.
4
Modulated light frequency: 0.27, 1.00, 2.00 KHZ.
Continuous light mode displays --- KHz (0 KHz).

Functions

Press this key to change
: Press this key to switch modulation
7
3
4
