8. Assemble the chain (A, figure 4) to the tractor as
follows:
a. On left-hand side, remove the upper self-tapping
screw that holds bumper to frame. This is the hole
used for installing chain in the following steps,
using one 5/16-18x l-114 capscrew
washers (D), and one 5/16 locknut.
b. Place one 5/16 washer onto the screw. Then place
the chain on the capscrew, and then the other
inside frame, install 5/16 locknut onto capscrew.
Tighten snug only at this time. The spring (C) will
be installed in "Installation" section (step 6), and
hardware will be tightened.

INSTALLATION

1. Drive the tractor over the push bar until rear of
push bar is under front hitch.
engine, remove key and set parking brake.
the bracket (J, figure 5) to the two rear
holes in the tractor hitch with the four pins (F) and
safety clips (G) provided. Insert the pins from the
outside. Make sure the push bar mounting holes
(in the bracket) are toward the front.
the push bar to the bracket, using the two
provided.
(B), two 5/16
Figure 4. Chain
A. Chain
B. Capscrew
C. Spring
D. Flat Washer
gure 5. Hitch and Lift Rod
Lift Rod
Front Set Collar
Spring Clip
Spring
Rear Set Collar
Pin
42" Snow Plow/Dozer Blade
G. Safety Clip
H. Capscrew. 3/8-16x
I. Locknut, 3/S-16
J. Bracket
K. Push Bar
