42" Snow Plow/Dozer Blade

ASSEMBLY

1. Place the blade on a flat surface.
2. install two bar stops (A, figure 2) using the two
screw on 5/16 nut (B) only far enough so that it is
flush with the end of the eyebolt.
4. Hook the spring (C) into the pivot frame (D).
Stretch the spring with a pliers to hook springs on
eyebok (A).
5. Repeat steps 3 and 4 for the other spring
expose about 3/4" (19 mm) of thread.
first nut (B) secure with a wrench and tighten the
second nut (E) securely on each eyebok.
Figure 2. Bar Stop
A. Bar Stop
B. Taptite Screw, 5/l 6-l 8 x 1
Figure 3. Tension Springs
A. Eyebolt
0. Nut, 5116
C. Spring
D. Pivot Frame
E. Nut, 5/16
