Summary of Contents for NEUTRIK NA2-IO-DLINE
- Page 1 User Manual NA2-IO-DLINE Line I/O to Dante Interface ™...
- Page 2 This user manual is protected by copyright. The user manual must not be duplicated, reproduced, microfilmed or translated, or converted to be saved and processed in IT systems, neither as excerpts nor in full, without the express written authorization of Neutrik. Copyright by: © Neutrik® AG...
-
Page 3: Table Of Contents
4.4 Controlling the Dante adapter with the Dante controller ..............13 4.4.1 Enabling a Dante link ........13 4.5 How to update your Neutrik Dante device via Firmware Update Manager ........13 5 After operation ............16 5.1 Dismounting devices ........... 16 5.2 Transporting ............ -
Page 4: About This Document
Pass this user manual on to every user, e.g., by lending it, or to the future owner of the product. If this user manual is lost or damaged, a copy of it can be downloaded from the Neutrik's website (www.neutrik.com). -
Page 5: Explanation Of Symbols
Carry out the action steps in the order they are presented. 1.4 Target group This user manual is addressed to sound engineers, musicians and personnel who have comprehensive experience in sound and event technology. User manual – Dante adapter NA2-IO-DLINE | BDA 537-V2 2018/12... -
Page 6: Safety
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. User manual – Dante adapter NA2-IO-DLINE | BDA 537-V2 2018/12... -
Page 7: Declaration Of Conformity
Safety w NOTICE Changes or modifications made to this equipment not expressly approved by Neutrik may void the FCC authorization to operate this equipment. 2.3.1 Declaration of conformity The device meets all the relevant EU directives and therefore has the CE marking. The Declaration of Conformity may be consulted at www.neutrik.com/en/approvals-and-certificates. -
Page 8: Description Of Product
With optional mounting brackets or a rack panel, the box can be mounted below tables, in floor boxes, or in equipment racks. 3.2 Device Pos. Description Sheet metal housing Rubber protection (removable) Connections and displays 3.3 Connections and displays User manual – Dante adapter NA2-IO-DLINE | BDA 537-V2 2018/12... - Page 9 Indicates the device's system status. been identified via the identification function of LED lights up red: system is starting. • the Dante™ Controller. • LED lights up green: system is ready. User manual – Dante adapter NA2-IO-DLINE | BDA 537-V2 2018/12...
-
Page 10: Operation
Check the packaging and Dante adapter for visible damage. When visible damage to the packaging and/or delivered parts is detected: Contact the salesperson or Neutrik sales partner. Do not use damaged devices under any circumstances. 4.2 Connecting devices with the Dante... -
Page 11: Connection Diagram Using A Switch With Poe Support
Non-compliant PoE injectors can damage the Dante adapter. The warranty is invalidated in this case. Only use a PoE injector that complies with IEEE 802.3af or 802.3at. Injector LINE OUT LINE IN 100 / 240 V User manual – Dante adapter NA2-IO-DLINE | BDA 537-V2 2018/12... -
Page 12: Applications
Switch with Headphone PoE support amplifier NA2-IO-DLINE LINE OUT LINE OUT LINE IN Using the Dante adapter, the two applications described above can also be operated simultaneously (= mixed mode). User manual – Dante adapter NA2-IO-DLINE | BDA 537-V2 2018/12... -
Page 13: Controlling The Dante
During operation, the computer and the "Dante Controller" software can be disconnected from the network, since all relevant information remains saved on the involved devices. 4.5 How to update your Neutrik Dante device via Firmware Update Manager Updates are important part of every device. They contain fixes, improvements and/or new functions. - Page 14 3. Choose the Network Adapter on which your device is connected to your PC. Click Next. 4. Click Update Dante Firmware 5. Browse to the firmware file (.dnt) and click Open 6. Click Next User manual – Dante adapter NA2-IO-DLINE | BDA 537-V2 2018/12...
- Page 15 7. Wait until your device(s) appear and select 8. Press Start and confirm 9. After successful update, the message appears informing you about the status. Now after rebooting the device(s), they are up-to-date. User manual – Dante adapter NA2-IO-DLINE | BDA 537-V2 2018/12...
-
Page 16: After Operation
Only have the Dante adapter repaired by a specialist dealer authorized by Neutrik. Check the Dante adapter regularly for visible damage to the housings, controls, connections, cables and plugs. -
Page 17: Disposal
Dispose of packaging and packaging elements in accordance with the applicable local regulations. Take device components made of plastic, metal or other recyclables for reclamation in accordance with the applicable local regulations. User manual – Dante adapter NA2-IO-DLINE | BDA 537-V2 2018/12... -
Page 18: Appendix
L = 151 mm (5.9 inches) (without rubber protection) B = 66 mm (2.6 inches) H = 41 mm (1.6 inches) Operating environment Indoor Operating temperature –5°C to +70°C Storage temperature –40°C to +150°C User manual – Dante adapter NA2-IO-DLINE | BDA 537-V2 2018/12... - Page 19 Appendix User manual – Dante adapter NA2-IO-DLINE | BDA 537-V2 2018/12...
- Page 20 LIECHTENSTEIN (HEADQUARTERS) Neutrik AG, Im alten Riet 143, 9494 Schaan T +423 237 24 24, F +423 232 53 93, neutrik neutrik.com GERMANY / NETHERLANDS / DENMARK / AUSTRIA Neutrik Vertriebs GmbH, Felix-Wankel-Strasse 1, 85221 Dachau, Germany T +49 8131 28 08 90, neutrik neutrik.de...
