APPENDIX
Mechanical Installation : 60Cell Model
Fig.1 Bolting Type
①
②
②
①
① : 200mm
② : 300mm
Fig.3 Clamping Type
A : 200mm
B : 400mm
Fig.5 Clamping Type
C
A : 200mm
B : 400mm
C : 120mm
Note) All mechanical installation methods(Fig.1 to Fig.6) in this appendix were not tested by VDE.
It is evaluated by LG internal test.
①
②
②
①
Front : 5400Pa
Rear : 4000Pa
A
B
B
A
Front : 4000Pa
Rear : 4000Pa
C
A
B
B
A
Front : 5400Pa
Rear : 4000Pa
Front : 5400Pa
Rear : 1800Pa
Fig.2 Clamping Type
A : 200mm
B : 400mm
Fig.4 Clamping Type
A
A : 200mm
B : 200mm
Fig.6 Clamping Type
①
②
①
A : 120mm
*4point(①)
A : 120mm
6point(①+②)
B : 843 ±100mm
A
B
B
A
Front : 5400Pa
Rear : 4000Pa
A
B
B
Front : 1800Pa
Rear : 1800Pa
Front : 2400Pa
Rear : 2400Pa
A
①
B
②
①
Front : 1800Pa
Rear : 1800Pa
Front : 5400Pa
Rear : 4000Pa
13
