1. C
ONNECTION
1. Connect the 3.5m black coaxial cable from the antenna to the connector marked as "Antenna".
2. Connect the serial white cable from the connector marked "Host" to any serial port (COM) on
your PC or the reader "R-IN 1300 MID" can be connected to the LAN just like a PC (Ethernet
cable & RJ-45 connectors).
3. Connect the power cord to 110 – 240 V AC.
2. O
PERATION
A. Terminal
1. For operation with terminal use any kind of terminal, e.g. Windows HyperTerminal with the
following settings:
• Bits per second 115200
• Data bits 8
• Parity None
• Stop bits 1
• Flow control None
R-IN1300 MID – UM001061 – v.3.0 – January 2019
1 (5)
