Furuno RC-1800F2 Series Installation Manual

Gmdss radio station
Hide thumbs Also See for RC-1800F2 Series:
Table of Contents

Advertisement

Quick Links

See also: Operator's Manual
SAFETY INSTRUCTIONS ............................................................................ i
SYSTEM CONFIGURATION ....................................................................... ii
EQUIPMENT LISTS.................................................................................... iv
1. MOUNTING .........................................................................................1-1
1.1
Mounting Considerations..........................................................................................1-1
1.2
Mounting the Channel Base and Rack Console........................................................1-3
1.3
Mounting the Rack Console Table, Keyboard ...........................................................1-5
1.4
Fixing the Slide Rail KC-252-20 ................................................................................1-6
1.5
Mounting the Printer PP-520 .....................................................................................1-7
1.6
Mounting the SSAS Alert Unit IC-307........................................................................1-7
1.7
Connection of Antenna Cable for DSC Function .......................................................1-8
1.8
Lamp Assembly (Option) ...........................................................................................1-9
2. WIRING ...............................................................................................2-1
2.1
Wiring Diagram..........................................................................................................2-1
2.2
Terminal Wiring .........................................................................................................2-2
2.3
Connection of External Equipment ............................................................................2-6
2.4
Charger Unit BC-6158-SS .........................................................................................2-8
2.5
JIS (Japan Industrial Standards) Cable Data ..........................................................2-11
3. CHECKING OPERATION ...................................................................3-1
3.1
Checking Operation of Equipment.............................................................................3-1
3.2
General Check...........................................................................................................3-1
3.3
Instructions for Cancelling Distress Alert...................................................................3-5
PACKING LISTS...................................................................................... A-1
OUTLINE DRAWINGS............................................................................. D-1
INTERCONNECTION DIAGRAMS.......................................................... S-1
All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
INSTALLATION MANUAL
GMDSS Radio Station
www.furuno.com
RC-1800F2
Model

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RC-1800F2 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Furuno RC-1800F2 Series

Summary of Contents for Furuno RC-1800F2 Series

  • Page 1: Table Of Contents

    3. CHECKING OPERATION ..............3-1 Checking Operation of Equipment................3-1 General Check......................3-1 Instructions for Cancelling Distress Alert..............3-5 PACKING LISTS..................A-1 OUTLINE DRAWINGS................D-1 INTERCONNECTION DIAGRAMS............S-1 www.furuno.com All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
  • Page 2 The paper used in this manual is elemental chlorine free. ・FURUNO Authorized Distributor/Dealer 9-52 Ashihara-cho, Nishinomiya, 662-8580, JAPAN A : MAY 2008 Printed in Japan All rights reserved. Q : SEP . 13, 2018 Pub. No. IME-56640-Q ( ETMI ) RC-1800F2...

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS WARNING WARNING CAUTION CAUTION ELECTRICAL SHOCK HAZARD Ground the equipment to Do not open the equipment prevent electrical shock and unless totally familiar with mutual interference. electrical circuits and service manual. Observe the following safe compass distances to prevent deviation of Only qualified personnel should work inside the a magnetic compass:...
  • Page 4 SYSTEM CONFIGURATIONS RC-1800F2-1S/2S/5S RC-1800F2-1S: FS-1575, one FELCOM 18 RC-1800F2-2S: FS-2575, one FELCOM 18 RC-1800F2-5S: FS-5075, one FELCOM 18 ARD-1/AJB1-1A (option) Whip Antenna SSB Antenna 04S4176 Antenna Antenna Coupler Switch Inmarsat-C AT-1575 AS-102 Antenna Unit (for FS-1575) IC-118 AT-5075 (for FS-2575/5075) Preamp FAX-5 -Distress Alert/Received...
  • Page 5 SYSTEM CONFIGURATIONS RC-1800F2-1D/2D/5D RC-1800F2-1D: FS-1575, two FELCOM 18 RC-1800F2-2D: FS-2575, two FELCOM 18 RC-1800F2-5D: FS-5075, two FELCOM 18 ARD-1/AJB1-1A (option) Antenna Coupler AT-1575 SSB Antenna (for FS-1575) AT-5075 Inmarsat-C Antenna Switch (for FS-2575/5075) Antenna Unit AS-102 IIC-118 Whip Antenna 04S4176 Preamp FAX-5 -Alarm Unit IC-306...

  • Page 6: Equipment Lists

    EQUIPMENT LISTS Standard Supply Name Type Code No. Remarks Rack Console RC-1800F2 See table below Antenna Unit IC-118 1 or 2 Two units are supplied for 1D/2D/5D Antenna Coupler AT-1575 For FS-1575 AT-5075 For FS-2575/5075 Printer PP-520 Distress Alert/ IC-305 1 or 2 Two units are supplied for 1D/2D/5D Received Call Unit Alarm Unit...
  • Page 7 Option Name Type Code No. Remarks FS-2575C For FS-1575/2575/5075 Control Unit Preamp Unit FAX-5 w/cable 1/15m BK Interface BK-300 Antenna Unit IC-118 For FELCOM 18 Distress Alert/Received IC-305 Call Unit Alarm Unit IC-306 SSAS Alert Unit IC-307 Terminal Unit IB-585-A 000-020-895 For NBDP External Loudspeaker...
  • Page 8 Name Type Code No. Remarks Antenna Base OP16-72 001-313-420 For IC-118 w/Hose Clamp Antenna Base OP16-73 001-313-430 w/Mount Pipe Antenna Base w/U Bolt OP16-74 001-313-440 Antenna Base OP16-75 001-313-450 Installation Materials CP24-00151 005-931-190 For PR-240 CP05-09010 001-388-190 10 m cable set CP05-09020 001-388-250 25 m cable set...
  • Page 9 Name Type Code No. Remarks Whip Antenna FAW-6D 000-572-128 3-110682-00 FAW-6RP2 000-572-109 04S4176 001-153-112 WH-027-10M 001-139-400-10 10 m FAW-6R2 000-572-108 FAW-6R2A 000-107-921 WH-027-8M 001-138-110-10 WH-027-8M02 001-138-120-10 WH-027-8M03 001-138-140-10 Strain Insulator YT-180 #18 000-166-342-10 Manual Tilting Mechanism WH-027-KD 001-139-410-10 WH-027-KD2 001-141-850-10 5P Cable 05S0793 000-125-984-10 10 m...
  • Page 10 Name Type Code No. Remarks Coaxial Cable RG-8A/U 000-167-213-10 10 m 000-167-214-10 20 m 000-169-060-10 30 m 000-169-062-10 40 m 000-169-064-10 50 m Cable Assy. DSUB15-5P 001-146-850-10 For FS-1575/2575/5075, 5 m 001-146-860-10 For FS-1575/2575/5075, 10 m 001-146-870-10 For FS-1575/2575/5075, 20 m 001-146-880-10 For FS-1575/2575/5075, 30 m 001-146-890-10 For FS-1575/2575/5075, 40 m 001-146-900-10 For FS-1575/2575/5075, 50 m...
  • Page 11 Name Type Code No. Remarks Hose Clamp OP16-76-1 001-443-450 Nominal Diameter, Mast Diameter For 40A ( 48.6) OP16-76-2 001-443-460 Nominal Diameter, Mast Diameter For 65A to 80A ( 76.3 to 89.1) OP16-76-3 001-443-470 Nominal Diameter, Mast Diameter For 90A to 100A ( 101.6 to 114.3)
  • Page 12 This page is intentionally left blank.

  • Page 13: Mounting

    1. MOUNTING Mounting Considerations 1.1.1 Mounting considerations for RC-1800F2 As shown on the next page, the rack console is normally installed on the bridge. Install the rack console where the equipment can be easily operated, checked and serviced. Con- sult with shipyard personnel and ship’s officer-in-charge to determine best location. The location must satisfy the following points: •...
  • Page 14 NX-5...

  • Page 15: Mounting The Channel Base And Rack Console

    Mounting the Channel Base and Rack Console CAUTION Ground the equipment to prevent electrical shock and mutual interference. Handle copper plate carefully. An edge of it may harm your hand. Leave at least 100 mm of service space on the sides and at the rear of the console. Determine cable coming position and size and ground location by referring to the figure below.
  • Page 16 Grounding the copper plate Weld a steel plate with copper strap, and connect it to the rack console. Solder the point where the copper plate connects to the copper platge support, to prevent corrosion and to ensure tight connection. CAUTION Ground the equipment to prevent interference and electrical shock.

  • Page 17: Mounting The Rack Console Table, Keyboard

    Mounting the Rack Console Table, Keyboard 1. Fasten right and left side table brackets to the console frame with six M5x20 bolts supplied as accessories. 2. Lay the rack console table on the top of the table brackets. 3. Fasten the rack console table with five M6x15 flat head screws. Rack Console Table Flat Head Screw...

  • Page 18: Fixing The Slide Rail Kc-252-20

    3. Unfasten two hex. bolts (M6) to open the front panel of the rack console. Note: Lock the stay at the left-hand side inside the rack console. OPEN LOCK LOCK Stay Rack console, opening the front panel 4. Connect the keyboard connector to the rear of the terminal unit. 5.

  • Page 19: Mounting The Printer Pp-520

    Mounting the Printer PP-520 1. Place the printers on the top of the rack console. Connect printer connector and printer power cord to printers. 2. Set the fixtures (left/right) onto the printer, and then fasten them with four binder head screws- F ( 4x10).

  • Page 20: Connection Of Antenna Cable For Dsc Function

    Connection of Antenna Cable for DSC Function 1.7.1 Installation of antenna FAX-5 Fix the FAX-5 (preamp unit) to the mounting mast (diameter 35 to 90 mm) with hose clamps (In- stallation material CP05-09301). Screw the whip antenna (04S4176) into the FAX-5. Coat connec- tion point with putty for waterproofing.

  • Page 21: Lamp Assembly (Option)

    Lamp Assembly (Option) The lamp assembly (type: L3/12-YLP2, code no.: 000-169-005-11) is optionally available. Mount it as follows. 1. Unfasten two M3 screws from the top of the rack console. 2. Unscrew two M3 screws to remove the bottom plate from the lamp assembly. 3.
  • Page 22 This page is intentionally left blank. 1-10...

  • Page 23: Wiring

    2. WIRING Wiring Diagram No.2 GPS No.1 GPS No.1 VHF WR No.1 VHF No.2 VHF ANT RC-1800F2-5S/5D DSC ANT 3D2V, Max.50 m RC-1800F2-2S/2D RC-1800F2-1S/1D TP5FBAW-5DFBB, 30 m Inmarsat C 8D-FB-CV 50 m, 12D-SFA-CV, 100 m...

  • Page 24: Terminal Wiring

    Terminal Wiring WAGO connectors have three cable holes respectively. You can use any hole to connect the ca- ble. Touse the WAGO connector, see the figure shown below. WAGO connector 1 2 3 4 5 1) Insert the slot-head driver, and press it upward.
  • Page 25 Terminal wiring for power system (TB101, 102) Crimp-on lug (local supply) Internal diameter: min. 8 External diameter: max. 22.2 12 13 14 TB 101 18 19 20 DC Power Terminal 9 to 10 mm TB 102 10 11 AC Power Crimp-on lug (local supply) Terminal Internal diameter: min.
  • Page 26 Terminal wiring for Inmarsat-C (TB103) TB 103 12 13 14 IC-307/ No.1 No.2 IC-307 IC-305/306 IC-307 IC-305/306 DMC-5 No.1 Inmarsat-C No.2 Inmarsat-C 9 to 10 mm Terminal wiring for battery system (TB104) TB 104 12 13 14 8 to 9 mm to Battery Monitor...
  • Page 27 Terminal wiring for SSB (TB105) TB 105 (Continued below.) To Alarm unit To Antenna coupler IC-350 (for FS-1575/2575/5075) FS-1575T, FS-5075T When conncted to AS-102 8 to 9 mm To Antenna switch External BK AS-102 (for FS-1575/2575/5075)

  • Page 28: Connection Of External Equipment

    Connection of External Equipment 2.3.1 BK connection Receiver unit Transceiver unit Relay BK control current Max. 1A Transceiver unit Receiver unit Relay K control current Max. 1A...
  • Page 29 2.3.2 AF LINE OUT connection...

  • Page 30: Charger Unit Bc-6158-Ss

    Charger Unit BC-6158-SS According to the battery used, set the output voltage of the charger unit to 26.7 VDC (default set- ting) or 28 VDC. This section shows how to change the output voltage from 26.7 VDC to 28 VDC. Battery Output Voltage Valve-regulated lead-acid battery, maintenance free...
  • Page 31 4. Fill the “MES“ checkbox with white paint, and then check the “SS (TICK)“ checkbox. 5. Attach the panel with bolts removed at step 1. 6. Remove two screws (M4x10) to remove the front cover. M4x10 M4x10 screw screw M6 bolt M6 bolt Front cover 7.
  • Page 32 8. Remove the 05P0606 board on the rear side of the battery moniter panel. Fixing plate Battery monitor panel Rear side of the battery monitor panel (After removing the 05P0606 board) 9. Remove the screw on the battery monitor panel to remove the SW panel and fixing plate. Remove this screw.

  • Page 33: Jis (Japan Industrial Standards) Cable Data

    JIS (Japanese Industrial Standards) Cable Data 2-11...
  • Page 34 2-12...
  • Page 35 2-13...
  • Page 36 This page is intentionally left blank. 2-14...

  • Page 37: Checking Operation

    3. CHECKING OPERATION Checking Operation of Equipment This section covers checking of the equipment for proper operation. Refer to the respective Instal- lation Manuals shown below. A password is required to do the initial setting. Under no circum- stances shall the operator do the initial setting. •...
  • Page 38 Check point Procedure FS-1575/2575/5075 Make group call and 1) Arrange the group message as below. confirm that the Message type: GROUP MSG TO: 011111111 equipment transmits PRIORITY: ROUTINE DSC message COMM MODE: TELEPHONE COMM FREQ: Any setting is available. DSC FREQ: Tx: 2177.0 kHz, Rx: 2177.0 kHz 2) Select “GO TO CALL”...
  • Page 39 Check point Procedure FELCOM 18 Check Distress Alert 1. Press the F7, 8, 4 and Enter in order. Unit IC-305 for The distress Alert Button Test mode screen appears. proper operation. 2. Open the cover on DISTREESS button. 3. Long-press the DISTRESS button. 4.

  • Page 40: Instructions For Cancelling Distress Alert

    Instructions for Cancelling Distress Alert Procedure Sample message VHF DSC 1) Switch off transmitter immediately. All Stations, All Stations, All Stations 2) Switch equipment on and set to Channel 16. This is NAME, CALLSIGN, DSC NUMBER, 3) Make broadcast to “ALL Stations” giving your POSITION.
  • Page 50 27/May/2013 H.MAKI...
  • Page 51 27/May/2013 H.MAKI...
  • Page 52 July 14'03 July 14'03...
  • Page 53 Dec. 20, '02 Dec. 20, '02...
  • Page 54 Y. NISHIYAMA Y. NISHIYAMA 6/Oct/2010 6/Oct/2010...
  • Page 56 26/Jul/2016 H.MAKI 26/Jul/2016 H.MAKI...
  • Page 57 26/Jul/2016 H.MAKI 26/Jul/2016 H.MAKI...
  • Page 58 26/Jul/2016 H.MAKI 26/Jul/2016 H.MAKI...
  • Page 59 26/Jul/2016 H.MAKI 26/Jul/2016 H.MAKI...
  • Page 60 26/Jul/2016 H.MAKI 26/Jul/2016 H.MAKI...
  • Page 61 26/Jul/2016 H.MAKI 26/Jul/2016 H.MAKI...
